Icom IC-706MKIIG

11
2
INSTALLATION AND CONNECTIONS
■
RReeqquuiirreedd ccoonnnneeccttiioonnss
DC 13.8V
EXT SP
MIC
KEY
TUNER
ANT 1
ANT 2
GND
HF/VHF/UHF TRANSCEIVER
i706MK™G
AF
RIT/
SUB
MENU F-1 F-2 F-3
MODE
Y
Z
TS
DISPLAY
LOCK
RX
TX
M-CH
PHONES
TUNER/CALL
P.AMP/ATT
POWER
SHIFT
RF/SQL
BAND
BAND
MICROPHONE (p. 8)
HF/50 MHz ANTENNA
RTTY TERMINAL
UNIT
(p. 35)
2 m ANTENNA
PS-85
GROUND
(p. 9)
HM-103
See p. 13 for details.
CW KEY (p. 33)
Use the heaviest gauge wire or
strap available and make the
connection as short as possible.
Grounding prevents electrical
shocks, TVI and other
problems.
IC-706MKIIG.qxd 02.3.27 13:53 Page 11
