REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
C3196 4030017680 S.CER C1005 CH 1H 820J-T B 73.7/31.9
C3201 4030019990 S.CER C1005 JB 1C 104K-T T 43.3/51.0
C3202 4030019990 S.CER C1005 JB 1C 104K-T T 50.6/48.9
C3203 4030019560 S.CER GRM21BB31C106KE15L B 58.3/49.2
C3204 4030019120 S.CER GRM188B31E105KA75D T 58.2/47.0
C3205 4030019120 S.CER GRM188B31E105KA75D T 66.0/50.9
C3206 4030019120 S.CER GRM188B31E105KA75D T 66.0/52.1
C3207 4030019120 S.CER GRM188B31E105KA75D B 66.5/47.7
C3208 4030019120 S.CER GRM188B31E105KA75D B 56.0/52.5
C3209 4030017640 S.CER C1005 CH 1H 150J-T B 55.9/50.2
C3210 4030019120 S.CER GRM188B31E105KA75D T 70.6/57.7
C3211 4030019120 S.CER GRM188B31E105KA75D T 65.9/57.0
C3212 4030019120 S.CER GRM188B31E105KA75D T 65.9/55.4
C3213 4030019120 S.CER GRM188B31E105KA75D T 64.5/53.7
C3214 4030019990 S.CER C1005 JB 1C 104K-T T 66.9/49.0
C3215 4030019990 S.CER C1005 JB 1C 104K-T T 69.7/49.0
C3216 4030019120 S.CER GRM188B31E105KA75D B 55.1/58.6
C3217 4030019990 S.CER C1005 JB 1C 104K-T B 51.7/53.4
C3218 4030019990 S.CER C1005 JB 1C 104K-T B 70.1/45.4
C3221 4030017660 S.CER C1005 CH 1H 330J-T B 49.3/56.5
C3222 4030017630 S.CER C1005 CH 1H 120J-T B 48.0/56.0
C3223 4030017510 S.CER C1005 CH 1H 680J-T B 48.0/56.9
C3224 4030017620 S.CER C1005 CH 1H 100C-T B 46.5/56.5
C3225 4030018070 S.CER C1005 CH 1H 300J-T B 47.0/57.9
C3231 4030019990 S.CER C1005 JB 1C 104K-T T 50.3/63.8
C3233 4030019990 S.CER C1005 JB 1C 104K-T T 43.4/65.2
C3234 4030019990 S.CER C1005 JB 1C 104K-T T 43.4/63.2
C3235 4030019990 S.CER C1005 JB 1C 104K-T T 33.8/59.9
C3236 4030019990 S.CER C1005 JB 1C 104K-T T 32.1/67.4
C3237 4030016790 S.CER C1005 JB 1E 103K-T T 32.1/68.5
C3238 4030017360 S.CER C1005 CH 1H 030B-T T 39.7/67.5
C3239 4030017360 S.CER C1005 CH 1H 030B-T T 37.5/59.7
C3240 4030017600 S.CER C1005 CH 1H 080C-T T 37.8/64.4
C3241 4030017460 S.CER C1005 JB 1H 102K-T T 47.7/69.3
C3242 4030019990 S.CER C1005 JB 1C 104K-T T 50.3/70.0
C3243 4030017390 S.CER C1005 CH 1H 180J-T T 50.3/68.8
C3244 4030017570 S.CER C1005 CH 1H 040B-T B 47.8/82.4
C3245 4030017350 S.CER C1005 CH 1H 020B-T B 49.1/82.1
C3246 4030017570 S.CER C1005 CH 1H 040B-T B 48.7/83.3
C3251 4030019990 S.CER C1005 JB 1C 104K-T T 31.0/72.3
C3252 4030016790 S.CER C1005 JB 1E 103K-T T 31.0/74.0
C3253 4030017460 S.CER C1005 JB 1H 102K-T B 36.8/77.4
C3254 4030017460 S.CER C1005 JB 1H 102K-T T 47.0/74.2
C3255 4030016790 S.CER C1005 JB 1E 103K-T T 37.3/78.6
C3256 4030016790 S.CER C1005 JB 1E 103K-T T 50.2/75.4
C3257 4030019990 S.CER C1005 JB 1C 104K-T B 29.8/50.0
C3258 4030019990 S.CER C1005 JB 1C 104K-T T 28.4/81.8
C3261 4030017570 S.CER C1005 CH 1H 040B-T B 23.7/76.5
C3262 4030017340 S.CER C1005 CH 1H 010B-T B 24.2/77.9
C3263 4030017590 S.CER C1005 CH 1H 070C-T B 24.6/76.5
C3264 4030017570 S.CER C1005 CH 1H 040B-T B 25.4/78.3
C3265 4030017580 S.CER C1005 CH 1H 060C-T B 26.4/75.5
C3266 4030017610 S.CER C1005 CH 1H 090C-T B 27.6/75.9
C3267 4030017360 S.CER C1005 CH 1H 030B-T B 28.9/76.3
C3271 4030017370 S.CER C1005 CH 1H 3R5B-T B 19.9/76.5
C3272 4030017550 S.CER C1005 CH 1H 1R5B-T B 19.9/77.4
C3273 4030017370 S.CER C1005 CH 1H 3R5B-T B 21.2/77.8
C3275 4030019990 S.CER C1005 JB 1C 104K-T T 21.9/83.6
C3276 4030016790 S.CER C1005 JB 1E 103K-T B 20.3/81.6
C3277 4030019990 S.CER C1005 JB 1C 104K-T B 18.5/83.6
C3301 4030020190 S.CER GRM32EB31C476KE15L T 78.2/38.2
C3303 4030019990 S.CER C1005 JB 1C 104K-T T 80.1/56.6
C3304 4030019990 S.CER C1005 JB 1C 104K-T T 80.3/29.4
C4001 4030016790 S.CER C1005 JB 1E 103K-T B 37.0/81.3
C4002 4030019990 S.CER C1005 JB 1C 104K-T B 36.0/85.1
C4005 4030017600 S.CER C1005 CH 1H 080C-T B 36.6/90.3
C4006 4030019990 S.CER C1005 JB 1C 104K-T B 38.6/89.0
C4007 4030017590 S.CER C1005 CH 1H 070C-T B 35.6/92.2
C4008 4030016790 S.CER C1005 JB 1E 103K-T B 41.1/94.5
C4009 4030017460 S.CER C1005 JB 1H 102K-T B 35.6/96.3
C4010 4030017460 S.CER C1005 JB 1H 102K-T B 30.8/98.1
C4052 4030016790 S.CER C1005 JB 1E 103K-T T 30.9/86.1
C4053 4030017460 S.CER C1005 JB 1H 102K-T T 34.3/86.3
C4054 4030016790 S.CER C1005 JB 1E 103K-T T 31.8/87.5
C4055 4030017460 S.CER C1005 JB 1H 102K-T T 35.9/89.2
C4056 4030017460 S.CER C1005 JB 1H 102K-T T 36.8/89.2
C4057 4030017460 S.CER C1005 JB 1H 102K-T B 33.5/91.8
C4101 4030016790 S.CER C1005 JB 1E 103K-T B 31.7/99.7
C4102 4030017460 S.CER C1005 JB 1H 102K-T T 34.4/97.1
C4103 4030017360 S.CER C1005 CH 1H 030B-T T 39.0/96.2
C4104 4030017620 S.CER C1005 CH 1H 100C-T T 39.0/97.2
C4105 4030018120 S.CER C1005 CH 1H 110J-T T 42.3/103.4
C4106 4030017620 S.CER C1005 CH 1H 100C-T T 38.5/109.5
C4107 4030017360 S.CER C1005 CH 1H 030B-T T 38.5/110.4
C4108 4030017460 S.CER C1005 JB 1H 102K-T T 38.5/111.3
C4109 4030016790 S.CER C1005 JB 1E 103K-T B 33.2/109.2
C4110 4030017460 S.CER C1005 JB 1H 102K-T B 31.5/108.5
C4111 4030017460 S.CER C1005 JB 1H 102K-T T 29.9/109.2
C4151 4030016790 S.CER C1005 JB 1E 103K-T T 45.6/97.6
C4152 4030017580 S.CER C1005 CH 1H 060C-T B 43.6/97.8
C4153 4030017340 S.CER C1005 CH 1H 010B-T B 44.0/100.9
C4154 4030017400 S.CER C1005 CH 1H 220J-T B 44.0/101.8
C4155 4030017340 S.CER C1005 CH 1H 010B-T B 43.6/104.2
C4156 4030017400 S.CER C1005 CH 1H 220J-T B 45.4/105.1
C4157 4030017340 S.CER C1005 CH 1H 010B-T B 44.5/105.1
C4158 4030017580 S.CER C1005 CH 1H 060C-T B 43.6/105.8
C4159 4030016790 S.CER C1005 JB 1E 103K-T T 45.8/104.6
C4201 4030016790 S.CER C1005 JB 1E 103K-T T 33.5/114.0
C4202 4030017580 S.CER C1005 CH 1H 060C-T B 32.6/113.4
C4203 4030017560 S.CER C1005 CH 1H 2R5B-T B 40.4/115.5
C4204 4030017600 S.CER C1005 CH 1H 080C-T B 41.5/115.5
C4205 4030017460 S.CER C1005 JB 1H 102K-T B 41.9/119.2
C4206 4030017460 S.CER C1005 JB 1H 102K-T T 40.2/114.6
C4207 4030016790 S.CER C1005 JB 1E 103K-T B 45.1/115.8
C4208 4030017560 S.CER C1005 CH 1H 2R5B-T B 46.1/116.4
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
C4209 4030017360 S.CER C1005 CH 1H 030B-T B 47.2/119.0
C4210 4030016790 S.CER C1005 JB 1E 103K-T B 47.2/114.6
C4211 4030016790 S.CER C1005 JB 1E 103K-T T 48.5/117.5
C4212 4030017460 S.CER C1005 JB 1H 102K-T B 48.4/124.0
C4251 4030016790 S.CER C1005 JB 1E 103K-T T 32.9/119.0
C4252 4030017460 S.CER C1005 JB 1H 102K-T B 31.3/121.1
C4253 4030017510 S.CER C1005 CH 1H 680J-T B 30.8/122.4
C4254 4510008630 S.ELE 16 CE 47 FE T 36.0/124.4
C4255 4030017540 S.CER C1005 CH 1H R75B-T B 41.1/123.8
C4256 4030016790 S.CER C1005 JB 1E 103K-T B 40.4/125.7
C4257 4030016790 S.CER C1005 JB 1E 103K-T B 42.6/125.4
C4258 4030019990 S.CER C1005 JB 1C 104K-T B 44.3/121.9
C4259 4030017460 S.CER C1005 JB 1H 102K-T T 43.9/124.6
C4260 4030017460 S.CER C1005 JB 1H 102K-T B 47.3/122.5
C4261 4030016790 S.CER C1005 JB 1E 103K-T T 46.6/123.0
C4262 4030017340 S.CER C1005 CH 1H 010B-T B 44.8/125.7
C4301 4030017500 S.CER C1005 CH 1H 560J-T T 45.8/137.1
C4302 4030017500 S.CER C1005 CH 1H 560J-T T 46.7/139.7
C4303 4030017690 S.CER C1005 CH 1H 121J-T T 49.2/139.2
C4351 4030018590 S.CER C1608 CH 1H 122J-T T 42.7/138.8
C4352 4030019990 S.CER C1005 JB 1C 104K-T T 36.9/153.1
C4353 4030016790 S.CER C1005 JB 1E 103K-T T 41.1/152.0
C4354 4030019990 S.CER C1005 JB 1C 104K-T B 35.6/153.6
C4401 4030016790 S.CER C1005 JB 1E 103K-T B 35.6/159.3
C4402 4030020970 S.CER C1005 CH 1H 681JT B 35.2/162.5
C4403 4030019990 S.CER C1005 JB 1C 104K-T B 33.4/166.3
C4404 4030020970 S.CER C1005 CH 1H 681JT B 35.2/161.6
C4405 4030019990 S.CER C1005 JB 1C 104K-T B 34.1/167.8
C4406 4030016790 S.CER C1005 JB 1E 103K-T B 38.3/166.1
C4407 4030016790 S.CER C1005 JB 1E 103K-T B 37.3/169.3
C4408 4030016790 S.CER C1005 JB 1E 103K-T B 43.0/170.0
C4501 4030016790 S.CER C1005 JB 1E 103K-T B 38.2/157.0
C4502 4030017460 S.CER C1005 JB 1H 102K-T B 38.2/162.0
C4503 4030019990 S.CER C1005 JB 1C 104K-T B 40.8/158.9
C4504 4030019990 S.CER C1005 JB 1C 104K-T T 38.0/158.1
C4505 4030019990 S.CER C1005 JB 1C 104K-T B 39.7/163.2
C4506 4030020990 S.CER C1005 CH 1H 561JT B 40.2/162.0
C4507 4030020990 S.CER C1005 CH 1H 561JT B 42.2/159.0
C4508 4030019990 S.CER C1005 JB 1C 104K-T T 45.5/156.4
C4509 4030019120 S.CER GRM188B31E105KA75D B 48.2/156.0
C4510 4030019120 S.CER GRM188B31E105KA75D T 50.3/160.9
C4511 4030019990 S.CER C1005 JB 1C 104K-T T 47.1/160.1
C4512 4030019560 S.CER GRM21BB31C106KE15L T 50.6/164.7
C4513 4030016790 S.CER C1005 JB 1E 103K-T B 49.3/160.7
C4514 4030019560 S.CER GRM21BB31C106KE15L B 49.3/165.7
C4515 4030019990 S.CER C1005 JB 1C 104K-T T 47.8/169.4
C4516 4030019990 S.CER C1005 JB 1C 104K-T T 50.5/173.1
C4517 4030019120 S.CER GRM188B31E105KA75D B 51.6/172.7
C4518 4030017690 S.CER C1005 CH 1H 121J-T B 55.9/159.5
C4519 4030019120 S.CER GRM188B31E105KA75D B 57.0/156.5
C4520 4030017640 S.CER C1005 CH 1H 150J-T B 58.1/159.9
C4521 4030019560 S.CER GRM21BB31C106KE15L T 61.1/154.5
C4522 4030019990 S.CER C1005 JB 1C 104K-T T 61.0/148.1
C4523 4030019120 S.CER GRM188B31E105KA75D B 60.6/147.7
C4524 4030019560 S.CER GRM21BB31C106KE15L B 64.5/148.9
C4525 4030019990 S.CER C1005 JB 1C 104K-T B 54.1/159.5
C4603 4030016790 S.CER C1005 JB 1E 103K-T T 59.3/144.2
C4604 4030019990 S.CER C1005 JB 1C 104K-T T 54.5/146.6
C4605 4030019990 S.CER C1005 JB 1C 104K-T B 55.3/145.0
C4606 4030016790 S.CER C1005 JB 1E 103K-T T 53.9/145.4
C4607 4030016790 S.CER C1005 JB 1E 103K-T T 46.2/152.1
C4608 4030016790 S.CER C1005 JB 1E 103K-T T 48.0/152.1
C4609 4030016790 S.CER C1005 JB 1E 103K-T T 47.1/152.1
C4610 4030017460 S.CER C1005 JB 1H 102K-T B 56.1/147.8
C4611 4030016790 S.CER C1005 JB 1E 103K-T B 51.8/151.6
C4612 4030016970 S.CER C1005 JB 1E 223K-T B 52.4/156.2
C4613 4030016790 S.CER C1005 JB 1E 103K-T T 50.6/155.3
C4614 4030019560 S.CER GRM21BB31C106KE15L T 51.3/156.7
C4615 4030019120 S.CER GRM188B31E105KA75D B 53.2/154.8
C4616 4030020990 S.CER C1005 CH 1H 561JT B 54.9/155.1
C4617 4030017700 S.CER C1005 CH 1H 151J-T B 57.5/153.1
C4619 4030017570 S.CER C1005 CH 1H 040B-T T 54.3/153.6
C4620 4030019560 S.CER GRM21BB31C106KE15L T 51.3/158.5
C5001 4550007200 S.TAN F930J476MBABMA T 118.1/156.5
C5002 4550007200 S.TAN F930J476MBABMA B 113.9/155.2
C5003 4550007200 S.TAN F930J476MBABMA B 117.7/127.9
C5004 4550007200 S.TAN F930J476MBABMA T 117.5/122.6
C5005 4550007200 S.TAN F930J476MBABMA T 143.5/122.6
C5006 4550007200 S.TAN F930J476MBABMA B 138.6/128.9
C5007 4550007200 S.TAN F930J476MBABMA B 136.3/152.8
C5008 4550007200 S.TAN F930J476MBABMA T 145.2/151.3
C5009 4030019990 S.CER C1005 JB 1C 104K-T B 136.6/132.1
C5010 4030019990 S.CER C1005 JB 1C 104K-T B 137.8/133.0
C5011 4030019990 S.CER C1005 JB 1C 104K-T B 135.4/135.8
C5012 4030019990 S.CER C1005 JB 1C 104K-T T 144.2/139.3
C5013 4030019990 S.CER C1005 JB 1C 104K-T T 142.4/140.7
C5014 4030019990 S.CER C1005 JB 1C 104K-T T 142.8/142.3
C5015 4030019990 S.CER C1005 JB 1C 104K-T T 142.8/144.8
C5016 4030019990 S.CER C1005 JB 1C 104K-T T 142.3/146.8
C5017 4030019990 S.CER C1005 JB 1C 104K-T T 143.1/150.8
C5018 4030019990 S.CER C1005 JB 1C 104K-T B 151.0/145.4
C5019 4030019990 S.CER C1005 JB 1C 104K-T T 117.3/153.6
C5020 4030019990 S.CER C1005 JB 1C 104K-T T 121.2/153.6
C5021 4030019990 S.CER C1005 JB 1C 104K-T T 122.8/154.3
C5022 4030019990 S.CER C1005 JB 1C 104K-T T 123.8/154.3
C5023 4030019990 S.CER C1005 JB 1C 104K-T T 125.8/154.3
C5024 4030019990 S.CER C1005 JB 1C 104K-T T 126.8/154.3
C5025 4030019990 S.CER C1005 JB 1C 104K-T T 127.8/154.3
C5026 4030019990 S.CER C1005 JB 1C 104K-T T 128.8/154.3
C5027 4030019990 S.CER C1005 JB 1C 104K-T T 130.8/154.3
C5028 4030019990 S.CER C1005 JB 1C 104K-T T 132.2/153.6
C5029 4030019990 S.CER C1005 JB 1C 104K-T T 132.7/154.5
C5030 4030019990 S.CER C1005 JB 1C 104K-T T 134.8/154.1
C5031 4030019990 S.CER C1005 JB 1C 104K-T T 136.3/154.3
C5032 4030019990 S.CER C1005 JB 1C 104K-T T 137.8/154.3
Eqv.= This component is equivalent to the REF No. component listed above, and
may be substituted on parts orders and repairs.
To Next Page
Loading...
