Icom IC-7300 - Page 158

19
CONTROL COMMAND
19-5
Remote control (CI-V) information (Continued)
Cmd. Sub cmd. Data Description
1A* 05 0064 0000 to
0255
Send/read MOD input level from ACC
(0000=0% to 0255=100%)
0065 0000 to
0255
Send/read MOD input level from USB
(0000=0% to 0255=100%)
0066 00 to 03 Send/read MOD input connector during
DATA OFF
(00=MIC, 01=ACC, 02=MIC/ACC, 03=USB)
0067 00 to 03 Send/read MOD input connector during DATA
(00=MIC, 01=ACC, 02=MIC/ACC, 03=USB)
0068 00/01
Send/read the external keypad setting for
VOICE
*(00=OFF, 01=ON)
0069 00/01 Send/read the external keypad setting for
Memory KEYER (00=OFF, 01=ON)
0070 00/01 Send/read the external keypad setting for
RTTY Memory (00=OFF, 01=ON)
0071 00/01 Send/read the CI-V transceive setting
(00=OFF, 01=ON)
0072 0000 to
0223
Send/read the transceive CI-V Address for
USB to REMOTE in hexadecimal code
(0000=00h to 0223=DFh)
0073 00/01 Send/read the CI-V Output (for ANT)
capability (00=OFF, 01=ON)
0074 00/01 Send/read the CI-V USB port setting
(00=Link to [REMOTE], 01=Unlink to
[REMOTE]) (Read only)
0075 00/01 Send/read echo back setting for CI-V
operation from USB (00=ON, 01=OFF)
0076 00/01
Send/read the USB (serial port) function
setting
(00=CI-V, 01=RTTY Decode)
0077 00 to 03 Send/read data transfer speed for RTTY
decode output
( 00=4800 bps, 01=9600 bps, 02=19200 bps,
03=38400 bps)
0078 00 to 02 Send/read transmission control line setting
for USB
(00=OFF, 01=DTR, 02=RTS)
• Different line must be set from both CW
keying and RTTY (FSK)
0079 00 to 02 Send/read CW keying line setting for USB
(00=OFF, 01= DTR, 02=RTS)
• Different line must be set from both
transmisson control and RTTY (FSK)
0080 00 to 02 Send/read RTTY (FSK) line setting for USB
(00=OFF, 01=DTR, 02=RTS)
• Different line must be set from both CW
keying and transmission control"
0081 0000 to
0255
Send/read LCD unit backlight brightness
(0000=0% to 0255=100%)
0082 00/01 Send/read screen image type (00=A, 01=B)
0083 00/01 Send/read frequency readout font
(00=Basic, 01=Round)
0084 00/01 Send/read peak hold set for meter
*(00=OFF, 01=ON)
0085 00/01 Send/read memory name indication setting
(00=OFF, 01=ON)
0086 00/01 Send/read manual notch width pop-up
indication setting (00=OFF, 01=ON)
0087 00/01 Send/read PBT shifting value display setting
while rotating [TWIN PBT] (00=OFF, 01=ON)
0088 00/01 Send/read IF lter width and shifting value
display setting when the IF lter is switched
(00=OFF, 01=ON)
0089 00 to 03 Send/read screen saver function
( 00=OFF, 01=15 minutes, 02=30 minutes,
03=60 minutes)
0090 00/01 Send/read opening message indication
(00=OFF, 01=ON)
0091 p. 19-9 Send/read opening message contents
(up to 10-character)
0092 00/01 Send/read Power ON Check setting
(00=OFF, 01=ON)
Cmd. Sub cmd. Data Description
1A* 05 0093 00/01 Send/read Display Language
(00=English, 01=Japanese)
0094 20000101
to
20991231
Send/read date setting
( 20000101=2000/01/01 to
20991231=2099/12/31)
0095 0000 to
2359
Send/read time setting
(0000=00:00 to 2359=23:59)
0096 p. 19-11 Send/read UTC offset time
0097 00/01 Send/read scope indication during TX
(00=OFF, 01=ON)
0098 00 to 02 Send/read scope max. hold
(00=OFF, 01=ON)
0099 00 to 02 Send/read scope center frequency set
( 00=Filter center, 01=Carrier point center,
02=Carrier point center (Abs. Freq.)
0100 00/01 Send/read scope marker position setting
during x type scope
(00=Filter center, 01 Carrier point)
0101 00/01 Send/read external monitor signal width
(00=Narrow, 01=Wide)
0102 00 to 03 Send/read avaraging function for spectrum
scope (00=OFF, 01=2, 02=3, 03=4)
0103 00/01 Send/read spectrum display type
(00=Fill, 01=Fill+Line)
0104 p. 19-8 Send/read spectrum ll color
0105 p. 19-8 Send/read spectrum line color
0106 p. 19-8 Send/read spectrum color for peak hold
0107 00/01 Send/read waterfall set for spectrum scope
(00=OFF, 01=ON)
0108 00 to 02 Send/read waterfall speed
(00=Slow, 01=Mid, 02=Fast)
0109 00 to 02 Send/read waterfall height when expanded
scope is selected
(00=Small, 01=Mid, 02=Larger)
0110 00 to 07 Send/read peak color level set for waterfall of
the spectrum scope
( 00=Grid 1, 01=Grid 2, 02=Grid 3, 03=Grid 4,
04=Grid 5, 05=Grid 6, 06=Grid 7, 07=Grid 8)
0111 00/01 Send/read scope waterfall marker auto-hide
(00=OFF, 01=ON)
0112 p. 19-8 Send/read scope edge 1 frequencies for 0.03
to 1.60 MHz band
0113 p. 19-8 Send/read scope edge 2 frequencies for 0.03
to 1.60 MHz band
0114 p. 19-8 Send/read scope edge 3 frequencies for 0.03
to 1.60 MHz band
0115 p. 19-8 Send/read scope edge 1 frequencies for 1.60
to 2.00 MHz band
0116 p. 19-8 Send/read scope edge 2 frequencies for 1.60
to 2.00 MHz band
0117 p. 19-8 Send/read scope edge 3 frequencies for 1.60
to 2.00 MHz band
0118 p. 19-8 Send/read scope edge 1 frequencies for 2.00
to 6.00 MHz band
0119 p. 19-8 Send/read scope edge 2 frequencies for 2.00
to 6.00 MHz band
0120 p. 19-8 Send/read scope edge 3 frequencies for 2.00
to 6.00 MHz band
0121 p. 19-8 Send/read scope edge 1 frequencies for 6.00
to 8.00 MHz band
0122 p. 19-8 Send/read scope edge 2 frequencies for 6.00
to 8.00 MHz band
0123 p. 19-8 Send/read scope edge 3 frequencies for 6.00
to 8.00 MHz band
0124 p. 19-8 Send/read scope edge 1 frequencies for 8.00
to 11.00 MHz band
0125 p. 19-8 Send/read scope edge 2 frequencies for 8.00
to 11.00 MHz band
0126 p. 19-8 Send/read scope edge 3 frequencies for 8.00
to 11.00 MHz band
0127 p. 19-8 Send/read scope edge 1 frequencies for
11.00 to 15.00 MHz band
0128 p. 19-8 Send/read scope edge 2 frequencies for
11.00 to 15.00 MHz band
D Command table (Continued)
