Icom IC-7300 Full Manual

iii
ABOUT THE TOUCH SCREEN
D Touch operation
In the Full manual or Basic manual, the touch
operation is described as shown below.
Touch
If the display is touched briey, one short beep
sounds.
Touch for 1 second
If the display is touched for 1 second, one
short and one long beep sound.
D Touch screen precautions
• The touch screen may not properly work when the
LCD protection lm or sheet is attached.
• Touching the screen with your nger nails, sharp
topped object and so on, or touching the screen
hard may damage it.
• Tablet PC’s operations such as ick, pinch in and
pinch out cannot be performed on this touch screen.
D Touch screen maintenance
• If the touch screen becomes dusty or dirty, wipe it
clean with a soft, dry cloth.
• When you wipe the touch screen, be careful not to
push it too hard or scratch it with your nger nails.
Otherwise you may damage the screen.
The following items are included on the CD.
• Full manual (English)
Instructions for full operations, the same as this
manual.
• Basic manual (English)
Instructions for basic operations, the same manual
supplied with the transceiver.
• Basic manual
(German, Spanish, French, Italian, and other)
Instructions for basic operations in German,
Spanish, French, Italian, and other languages.
This manual may not be included, depending on the
transceiver version.
• Schematic diagram
Includes the schematic and block diagrams.
• HAM radio Terms
A glossary of HAM radio terms.
• Adobe
®
Reader
®
Installer
Installer for Adobe
®
Reader
®
.
A PC with the following Operating System is required.
• Microsoft
®
Windows
®
10
• Microsoft
®
Windows
®
8.1
• Microsoft
®
Windows
®
7
• Microsoft
®
Windows Vista
®
To read the manuals or Schematic diagram, Adobe
®
Reader
®
is required. If you have not installed it,
please install the Adobe
®
Reader
®
on the CD or
download it from Adobe Systems Incorporated’s
website.
Starting the CD
1. Insert the CD into the CD drive.
2. Double click “Menu.exe” on the CD.
• Depending on the PC setting, the menu screen shown
below is automatically displayed.
3. Click the desired button to open the file.
L To close the Menu screen, click [Quit].
Closes the Menu screenInstalls the Adobe
®
Reader
®
Opens the
Full manual
(this manual)
Opens the
Schematic
diagram
Opens the
Glossary
ABOUT THE SUPPLIED CD
Opens the English
Basic manual
Opens the multi-
language Basic manual
L Different types of menu screen may be displayed,
depending on the transceiver version.

Icom IC-7300 Specifications

General

Product type	Portable CB radio
Product color	Black
Housing material	Steel
Input voltage	13.8 V
Microphone included	Yes
Output power	100 W
Frequency range	0.5 - 70 MHz
Channels quantity	101 channels
Compatible products	AH-2B; AH-4; AH-5NV; AH-710; AH-740; CT-17; HM-219; MB-118; MB-123; OPC-2321; OPC-420; OPC-599; PS-126; RC-28; SM-30; SM-50; SP-23; SP-33; SP-34; SP-35; SP-35L; SP-38; SP-41;
Display type	LCD

Weight and Dimensions

Depth	238 mm
Width	240 mm
Height	94 mm
