19
CONTROL COMMAND
19-13
Remote control (CI-V) information (Continued)
• Scope Sweep speed settings
Command : 27 1A
0 0 X X
00=FAST
01=MID
02=SLOW
Fixed
• Scope VBW (Video Band Width) settings
Command : 27 1D
0 0 X X
00=Narrow
01=Wide
Fixed
• Scope Fixed edge frequency settings
Command : 27 1E
q
0 XX X X
w e r t y u i o !0 !1 !2
X X X X X X X 0 0 X X X X X X X X 0 0
10 Hz digit: 0–9 1 Hz digit: 0–9 1 kHz digit: 0–9 100 Hz digit: 0–9 100 kHz digit: 0–9 10 kHz digit: 0–9 10 MHz digit: 0–6 1 MHz digit: 0–9 1000 MHz digit: 0 (fixed) 100 MHz digit: 0 (fixed) 10 Hz digit: 0–9 1 Hz digit: 0–9 1 kHz digit: 0–9 100 Hz digit: 0–9 100 kHz digit: 0–9 10 kHz digit: 0–9 10 MHz digit: 0–6 1 MHz digit: 0–9 1000 MHz digit: 0 (fixed)
100 MHz digit: 0 (fixed)
Frequency range
Lower edge Higher edge
Edge number: 01–03
L Entry of 100 Hz or smaller digits are ignored.
q Selectable Frequency ranges
Data Frequency range (Hz)
01 0.03 – 1.60
02 1.60 – 2.00
03 2.00 – 6.00
04 6.00 – 8.00
05 8.00 – 11.00
06 11.00 – 15.00
07 15.00 – 20.00
08 20.00 – 22.00
09 22.00 – 26.00
10 26.00 – 30.00
11 30.00 – 45.00
12 45.00 – 60.00
13 60.00 – 74.80
w Selectable Edge number: 01 = 1, 02 = 2, 03 = 3
