Icom IC-7700

5 - 28
M.=Mounted side (T: Mounted on the Top side B: Mounted on the Bottom side)
[LOGIC UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
C936 4030006860 S.CER C1608 JB 1H 102K-T B 223.7/106.1
C937 4030006860 S.CER C1608 JB 1H 102K-T T 222.7/94.6
C938 4030006860 S.CER C1608 JB 1H 102K-T B 217.7/106.1
C939 4030006860 S.CER C1608 JB 1H 102K-T T 216.7/94.6
C940 4030006860 S.CER C1608 JB 1H 102K-T B 215.7/106.1
C941 4030006860 S.CER C1608 JB 1H 102K-T T 214.7/94.6
C942 4030006860 S.CER C1608 JB 1H 102K-T B 213.7/106.1
C943 4030006860 S.CER C1608 JB 1H 102K-T T 212.8/94.6
C944 4030006860 S.CER C1608 JB 1H 102K-T B 211.7/106.1
C945 4030006860 S.CER C1608 JB 1H 102K-T T 211.5/94.6
C946 4030006860 S.CER C1608 JB 1H 102K-T B 209.7/106.1
C947 4030006860 S.CER C1608 JB 1H 102K-T T 59.9/16.2
C948 4030006860 S.CER C1608 JB 1H 102K-T T 58.6/16.2
C949 4030006860 S.CER C1608 JB 1H 102K-T T 57.3/16.2
C950 4030006860 S.CER C1608 JB 1H 102K-T T 49.5/16.2
C951 4030006860 S.CER C1608 JB 1H 102K-T T 46.9/16.2
C952 4030006860 S.CER C1608 JB 1H 102K-T T 68.2/5.3
C953 4030006860 S.CER C1608 JB 1H 102K-T B 59.5/8.7
C954 4030006860 S.CER C1608 JB 1H 102K-T B 58/2.5
C955 4030006860 S.CER C1608 JB 1H 102K-T B 49.6/13.3
C963 4030006860 S.CER C1608 JB 1H 102K-T T 28.2/103.4
C964 4030006860 S.CER C1608 JB 1H 102K-T T 19.5/104.7
C965 4030006860 S.CER C1608 JB 1H 102K-T T 28.2/106
C966 4030006860 S.CER C1608 JB 1H 102K-T T 19.5/109.3
C967 4030006860 S.CER C1608 JB 1H 102K-T T 28.2/110.3
C968 4030006860 S.CER C1608 JB 1H 102K-T T 16.5/101.1
C969 4030006860 S.CER C1608 JB 1H 102K-T T 5.6/101.5
C970 4030006860 S.CER C1608 JB 1H 102K-T T 5.6/107.8
C971 4030006860 S.CER C1608 JB 1H 102K-T T 14.3/106.2
C977 4030006860 S.CER C1608 JB 1H 102K-T T 51.5/107.5
C979 4030006860 S.CER C1608 JB 1H 102K-T T 71.4/117.1
C980 4030006860 S.CER C1608 JB 1H 102K-T T 71.4/112.1
C991 4030006880 S.CER C1608 JB 1H 472K-T T 43.5/2.7
C998 4030006880 S.CER C1608 JB 1H 472K-T T 33.4/4.9
C999 4030006860 S.CER C1608 JB 1H 102K-T T 33.7/10.2
C1001 4030006880 S.CER C1608 JB 1H 472K-T T 15.1/100.9
C1002 4030006880 S.CER C1608 JB 1H 472K-T T 98.9/100.4
C2051 4030011600 S.CER C1608 JB 1E 104K-T T 262/82.3
C2052 4030011600 S.CER C1608 JB 1E 104K-T B 264.9/101.4
C2053 4030011600 S.CER C1608 JB 1E 104K-T T 265/95.7
C2054 4030008680 S.CER C2012 JF 1C 105Z-T T 270.5/89.5
C2055 4030008680 S.CER C2012 JF 1C 105Z-T T 273.6/88.5
C2056 4030008680 S.CER C2012 JF 1C 105Z-T T 279.9/91.2
C2057 4030008680 S.CER C2012 JF 1C 105Z-T T 279.9/95
C2058 4030008680 S.CER C2012 JF 1C 105Z-T T 274.6/100.7
J1 6510022490 S.CNR AXK5S30045P T 94/19.9
J2 6510019870 S.CNR AXK5S40045P T 94/64.9
J52 6510023261 S.CNR B6B-PH-SM4-TB (LF) (SN) T 153.9/103.6
J102 6510019981 S.CNR 52808-1671 (1690) T 153.6/65
J602 6510019971 S.CNR 52808-1071 T 218.9/57
J604 6510019971 S.CNR 52808-1071 T 224.1/82
J804 6510022031 S.CNR B10B-ZR-SM4-TF (LF) (SN) T 6.2/72
J805 6510020081 S.CNR 52808-2071 (2090) T 6.8/48
J806 6510022471 S.CNR 40FLT-SM2-TB (LF) (SN) T 6.9/21.1
J808 6510020001 S.CNR 52808-3071 (3090) T 217.2/114.8
J809 6510020001 S.CNR 52808-3071 (3090) T 217.2/101.7
J810 6510020251 S.CNR B9B-PH-SM4-TB (LF) (SN) T 113.9/115.9
J811 6510021561 S.CNR 52808-2470 (2490) T 50/6.8
J813 6510019991 S.CNR 52808-2271 (2291) T 23.9/99.5
J814 6510019981 S.CNR 52808-1671 (1690) T 10/101
J816 6510019981 S.CNR 52808-1671 (1690) T 60.2/112.4
J820 6510022801 S.CNR B10B-PH-SM4-TB (LF) (SN) T 232.5/23.3
J821 6510020251 S.CNR B9B-PH-SM4-TB (LF) (SN) T 214.8/22.3
J824 6510018971 S.CNR B4B-PH-SM4-TB (LF) (SN) T 244.6/21.7
J826 6510015541 S.CNR B4B-ZR-SM4-TF (LF) (SN) T 81.6/115.8
J2001 6510023720 CNR LGY6501-0600C
J2052 6510023120 CNR CD6109SA1J0 <CVI>
J2101 6510024040 CNR TM11R-5M2-88-LP
J2201 6450001941 CNR KEY-15S-2A3A (LF) (SN)
DS403 5040002930 S.LED SML-512MW T86 T 187.7/53.7
DS491 5040002930 S.LED SML-512MW T86 T 282.5/46.4
DS492 5040002930 S.LED SML-512MW T86 T 282.5/57.5
S51 2260002740 S.SW LS8J2M-T T 15.9/62.2
T401 5920000841 S.TSM H1102NL T 259.2/49.4
EP102 6910013310 S.BEA MMZ1608D121B T 159.4/33.3
EP103 6910013310 S.BEA MMZ1608D121B T 158.2/33.3
EP201 6910012350 S.BEA MMZ1608Y 102BT B 81.7/21.3
EP202 6910012350 S.BEA MMZ1608Y 102BT B 81.7/19.8
EP203 6910012350 S.BEA MMZ1608Y 102BT T 50.6/37.3
EP204 6910012350 S.BEA MMZ1608Y 102BT T 69.6/35.4
EP401 6910013310 S.BEA MMZ1608D121B T 184.1/53.7
EP402 6910013310 S.BEA MMZ1608D121B T 177.5/53.7
EP403 6910013310 S.BEA MMZ1608D121B T 186.5/53.7
EP801 6910013310 S.BEA MMZ1608D121B B 5.7/30.4
EP802 6910013310 S.BEA MMZ1608D121B B 8/29.4
EP803 6910013310 S.BEA MMZ1608D121B B 11.2/28.9
EP804 6910013310 S.BEA MMZ1608D121B B 5.7/28.4
EP805 6910013310 S.BEA MMZ1608D121B B 8/27.4
EP806 6910013310 S.BEA MMZ1608D121B B 11.2/26.9
EP807 6910013310 S.BEA MMZ1608D121B B 5.7/26.4
EP808 6910013310 S.BEA MMZ1608D121B B 8/25.4
EP809 6910013310 S.BEA MMZ1608D121B B 11.2/24.9
EP810 6910013310 S.BEA MMZ1608D121B B 5.7/24.4
EP811 6910013310 S.BEA MMZ1608D121B B 8/23.4
S.=Surface mount
[LOGIC UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
EP812 6910013310 S.BEA MMZ1608D121B B 11.2/22.9
EP813 6910013310 S.BEA MMZ1608D121B B 5.7/22.4
EP814 6910013310 S.BEA MMZ1608D121B B 8/21.4
EP815 6910013310 S.BEA MMZ1608D121B B 11.2/20.9
EP816 6910013310 S.BEA MMZ1608D121B B 5.7/20.4
EP817 6910013310 S.BEA MMZ1608D121B B 8/19.4
EP818 6910013310 S.BEA MMZ1608D121B B 11.2/18.9
EP819 6910013310 S.BEA MMZ1608D121B B 5.7/18.4
EP820 6910013310 S.BEA MMZ1608D121B B 8/17.4
EP821 6910015980 S.BEA MMZ1608S 181CT-AS T 224.4/28.9
EP822 6910015980 S.BEA MMZ1608S 181CT-AS T 224.4/27.7
EP824 6910014730 S.BEA MPZ2012S331A-T T 12/50.5
EP825 6910014730 S.BEA MPZ2012S331A-T T 12/46.5
EP826 6910012350 S.BEA MMZ1608Y 102BT B 12.5/44.5
EP827 6910012350 S.BEA MMZ1608Y 102BT B 12.5/41.8
EP828 6910012350 S.BEA MMZ1608Y 102BT B 12.5/40.5
EP829 6910012350 S.BEA MMZ1608Y 102BT B 12.5/43.2
EP832 6910014730 S.BEA MPZ2012S331A-T T 224.1/25.6
EP833 6910014730 S.BEA MPZ2012S331A-T T 224.1/23.9
EP834 6910014730 S.BEA MPZ2012S331A-T T 208.5/15.8
EP835 6910014730 S.BEA MPZ2012S331A-T T 206.8/15.8
EP836 6910014730 S.BEA MPZ2012S331A-T T 224.1/20.3
EP837 6910014730 S.BEA MPZ2012S331A-T T 224.1/16.2
EP838 6910014730 S.BEA MPZ2012S331A-T T 12/57.5
EP839 6910014730 S.BEA MPZ2012S331A-T T 12/53.5
EP840 6910014730 S.BEA MPZ2012S331A-T T 12/55.7
EP851 6910015970 S.BEA MMZ1608B 301CT-AS T 107.9/109.4
EP852 6910015970 S.BEA MMZ1608B 301CT-AS T 111.9/109.4
EP853 6910015970 S.BEA MMZ1608B 301CT-AS T 115.9/109.4
EP854 6910015970 S.BEA MMZ1608B 301CT-AS T 119.9/109.4
EP901 6910014730 S.BEA MPZ2012S331A-T T 65.6/7.9
EP902 6910014730 S.BEA MPZ2012S331A-T B 57.1/11.1
EP903 6910014730 S.BEA MPZ2012S331A-T B 55.1/5.1
EP904 6910014730 S.BEA MPZ2012S331A-T B 54.2/11.9
EP905 6910014730 S.BEA MPZ2012S331A-T T 35.4/5.9
EP907 6910015980 S.BEA MMZ1608S 181CT-AS T 57.3/13.4
EP908 6910015980 S.BEA MMZ1608S 181CT-AS T 56/13.4
EP909 6910015980 S.BEA MMZ1608S 181CT-AS T 54.7/13.4
EP910 6910015980 S.BEA MMZ1608S 181CT-AS T 53.4/13.4
EP911 6910015980 S.BEA MMZ1608S 181CT-AS T 52.1/13.4
EP912 6910015980 S.BEA MMZ1608S 181CT-AS T 50.8/13.4
EP918 6910014730 S.BEA MPZ2012S331A-T T 71.8/115.5
EP919 6910014730 S.BEA MPZ2012S331A-T T 71.8/113.7
EP920 6910014730 S.BEA MPZ2012S331A-T T 64.7/107.7
EP932 6910014690 S.BEA MPZ1608S221A-T T 229.7/106.1
EP933 6910014690 S.BEA MPZ1608S221A-T T 228.7/97.2
EP972 6910015970 S.BEA MMZ1608B 301CT-AS T 79.3/110.1
EP973 6910015970 S.BEA MMZ1608B 301CT-AS T 82.1/109.9
EP1113 6910014690 S.BEA MPZ1608S221A-T T 28.2/104.7
EP1114 6910014690 S.BEA MPZ1608S221A-T T 19.5/106
EP1116 6910014690 S.BEA MPZ1608S221A-T T 19.5/108
EP1117 6910014690 S.BEA MPZ1608S221A-T T 28.2/109
EP1123 6910015970 S.BEA MMZ1608B 301CT-AS T 14.4/98.8
EP1124 6910015970 S.BEA MMZ1608B 301CT-AS T 5.6/100.2
EP2001 6910012350 S.BEA MMZ1608Y 102BT T 276.2/70.7
EP2002 6910012350 S.BEA MMZ1608Y 102BT T 276.2/72.1
EP2051 6910014730 S.BEA MPZ2012S331A-T T 256.3/98.1
[MEMORY BOARD]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
IC1 1130014290 S.IC JS28F128J3D-75 (SX-3009A)
[EUR]
1130014291 S.IC JS28F128J3D-75 (SX-3009A-1)
[USA], [UK]
1130014292 S.IC JS28F128J3D-75 (SX-3009A-2)
[FRA], [ITR], [ESP], [KOR]
IC2 1130013480 S.IC JS28F128J3D-75
C1 4030011600 S.CER C1608 JB 1E 104K-T
C2 4030011600 S.CER C1608 JB 1E 104K-T
C3 4030011600 S.CER C1608 JB 1E 104K-T
C4 4030011600 S.CER C1608 JB 1E 104K-T
C5 4030011600 S.CER C1608 JB 1E 104K-T
C6 4030011600 S.CER C1608 JB 1E 104K-T
J1 6510024410 S.CNR AXK6S30545
J2 6510020120 S.CNR AXK6S40545P
