Icom IC-7700

5 - 29
M.=Mounted side (T: Mounted on the Top side B: Mounted on the Bottom side)
[PA200W BOARD]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
IC2 1180001541 S.IC TA78L08F (TE12L,F) T 58.8/15.1
Q1 1520000531 S.TR 2SB1119S-TD-E T 42.8/19.2
Q2 1590000680 S.TR DTC114EUA T106 T 45.8/13.5
Q101 1560001241 S.FET RD01MUS1-T113 T 5.9/66.4
Q201 1590003051 S.FET PD55003-E T 20.5/53.1
Q301 1590003840 FET MRF148A T 64/45.8
Q401 1560001211 FET MRF150 (SRFJ150MP) M/A
D1 1730000561 S.ZEN RD2.7M-T2B-A B1 T 100.6/22.8
D401 1750000271 S.DIO 1SS301 (TE85L,F) T 116.8/99.1
D402 1750000271 S.DIO 1SS301 (TE85L,F) T 118.3/35.9
D403 1750000271 S.DIO 1SS301 (TE85L,F) T 104/98.3
D404 1750000271 S.DIO 1SS301 (TE85L,F) T 104/35.7
D551 1790000491 S.DIO HSM88ASTR-E T 150.1/35.3
L1 6200005011 S.COL NLV25T-100J T 14.7/18
L2 6200005011 S.COL NLV25T-100J T 14.7/20.5
L3 6200005011 S.COL NLV25T-100J T 14.7/23
L4 6200005011 S.COL NLV25T-100J T 14.7/29
L6 6200005011 S.COL NLV25T-100J T 14.7/25.5
L7 6200010881 S.COL CDRH124NP-330MC T 77.3/11
L101 6200005131 S.COL NLC453232T-101K-PF T 5.6/59.6
L102 6200007220 S.COL EXCCL4532U1 T 6/38.4
L201 6180001240 COL LAL 04NA 820K
L202 6140004350 COL LR-475
L301 6200003261 S.COL NLV32T-101J T 46.1/36.4
L303 6200001831 S.COL NLV32T-100J T 86.9/26.2
L304 2040000490 COL EXC-ELDR25C
L305 2040000490 COL EXC-ELDR25C
L306 6140004340 COL LR-474
L307 6200001831 S.COL NLV32T-100J T 75.7/100.2
L401 6200003261 S.COL NLV32T-101J T 100.4/98.3
L402 6200003261 S.COL NLV32T-101J T 100.1/35.8
L403 6140002590 COL LR-296 (TR18X8X8 D12A)
L404 6140000720 COL LR-95 T 166.4/67
L501 6140002030 COL LR-230 (SK-10M-15Y 120)
R1 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 42.8/12.8
R2 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 42.8/14.2
R3 7510001740 TMR DTN-C103F3H-STS-40
R4 7030000380 S.RES MCR10EZHJ 1 k T 39.7/22.5
R5 7030008061 S.RES ERA3YED 222V (2.2 k) T 104.3/23.1
R6 7030007210 S.RES ERA3YEB 102V (1 k) T 103.6/16.5
R7 7030007210 S.RES ERA3YEB 102V (1 k) T 103.6/17.8
R101 7030003370 S.RES ERJ3GEYJ 271 V (270) T 6/87.2
R102 7030003220 S.RES ERJ3GEYJ 150 V (15) T 3.9/86.1
R103 7030003370 S.RES ERJ3GEYJ 271 V (270) T 6/85
R104 7030003360 S.RES ERJ3GEYJ 221 V (220) T 4.8/71.3
R105 7030003430 S.RES ERJ3GEYJ 821 V (820) T 6/73.3
R106 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) T 9.2/73.8
R107 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 2.2/64.7
R108 7030003200 S.RES ERJ3GEYJ 100 V (10) T 9.2/68.3
R110 7030000230 S.RES MCR10EZHJ 56 (560) T 11.3/56.6
R111 7030003420 S.RES ERJ3GEYJ 681 V (680) T 13.3/58.6
R112 7030003510 S.RES ERJ3GEYJ 392 V (3.9 k) T 12.6/60.6
R113 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) T 6.8/75.2
R115 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) T 13.1/40.8
R117 7030003530 S.RES ERJ3GEYJ 562 V (5.6 k) T 7.7/76.5
R118 7030003550 S.RES ERJ3GEYJ 822 V (8.2 k) T 11.7/40.8
R119 7030008240 S.RES ERJ12Y0R00U T 5/49.6
R201 7030004050 S.RES ERJ3GEYJ 1R0 V (1) T 13.8/48.6
R202 7030003410 S.RES ERJ3GEYJ 561 V (560) T 23.1/43.1
R203 7030010800 S.RES ERJ1TYJ 2R7U (2.7) T 18.4/65.5
R205 7030006260 S.RES ERJ12YJ471U (470) T 30.3/55.7
R301 7310005210 TRI VM5CK-PVB 20 k
R302 7030008180 S.RES ERJ12YJ331U (330) T 48.3/40.6
R305 7030003530 S.RES ERJ3GEYJ 562 V (5.6 k) T 49.6/43.5
R307 7070000830 RES ERG3SJ 101 (100)
R309 7030010570 S.RES ERJ1TYJ 4R7U (4.7) T 80/45.8
R310 7310005200 TRI VM5CK-PVB 2 k
R312 7070000830 RES ERG3SJ 101 (100)
R401 7030010960 S.RES ERJ1TYJ 120U (12) T 89.8/90.7
R402 7030010960 S.RES ERJ1TYJ 120U (12) T 93.5/90.7
R403 7030010960 S.RES ERJ1TYJ 120U (12) T 97.2/90.7
R404 7030010960 S.RES ERJ1TYJ 120U (12) T 90.8/43.3
R405 7030010960 S.RES ERJ1TYJ 120U (12) T 94.5/43.3
R406 7030010960 S.RES ERJ1TYJ 120U (12) T 98.2/43.3
R407 7310005230 TRI VM5CK-PVB 10 k
R408 7030000420 S.RES MCR10EZHJ 2.2 k T 116.3/96
R409 7030000420 S.RES MCR10EZHJ 2.2 k T 116.3/38
R410 7310005230 TRI VM5CK-PVB 10 k
R411 7030010520 S.RES ERJ1TYJ 101U (100) T 107.6/93.9
R412 7030010520 S.RES ERJ1TYJ 101U (100) T 107.5/40.2
R413 7030010520 S.RES ERJ1TYJ 101U (100) T 111.3/93.9
R414 7030010520 S.RES ERJ1TYJ 101U (100) T 111.2/40.2
R416 7070000890 RES ERG3SJ 150 (15)
R418 7070001190 RES ERG3SJ180 (18)
R420 7070000890 RES ERG3SJ 150 (15)
R422 7070001190 RES ERG3SJ180 (18)
R423 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k) T 95.9/98.4
R424 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k) T 99.4/33.6
R425 7310005200 TRI VM5CK-PVB 2 k
R426 7310005200 TRI VM5CK-PVB 2 k
R427 7070001200 RES ERG3SJ100P (10)
R501 7070000890 RES ERG3SJ 150 (15)
R502 7070000890 RES ERG3SJ 150 (15)
R503 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) T 171.8/16.7
R504 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) T 169.9/15.9
R507 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) T 139.1/17.9
R508 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) T 137.3/19.2
R511 7070000890 RES ERG3SJ 150 (15)
R512 7070000890 RES ERG3SJ 150 (15)
R513 7070001000 RES ERG3SJ 821 (820)
S.=Surface mount
[PA200W BOARD]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
R514 7070001000 RES ERG3SJ 821 (820)
R521 7030011160 S.RES RL7520WT-R010-F T 165.2/20.2
R522 7030011160 S.RES RL7520WT-R010-F T 159.6/20.2
R523 7030011160 S.RES RL7520WT-R010-F T 154/20.2
R551 7030010650 S.RES ERJ12YJ823U (82 k) T 144.5/34.2
R552 7030008020 S.RES ERJ12YJ472U (4.7 k) T 141.2/28.3
R554 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 154.5/34.2
R563 7030008240 S.RES ERJ12Y0R00U T 137.5/28.9
R564 7030008240 S.RES ERJ12Y0R00U T 156.6/30
R565 7030008240 S.RES ERJ12Y0R00U T 146/29.4
C1 4030011600 S.CER C1608 JB 1E 104K-T T 18.9/18
C2 4030006880 S.CER C1608 JB 1H 472K-T T 18.9/20.5
C3 4030006880 S.CER C1608 JB 1H 472K-T T 18.9/23
C4 4030006880 S.CER C1608 JB 1H 472K-T T 18.9/29
C6 4030006880 S.CER C1608 JB 1H 472K-T T 18.9/25.5
C7 4030006900 S.CER C1608 JB 1H 103K-T T 70/6.8
C8 4030006880 S.CER C1608 JB 1H 472K-T T 42.8/15.6
C9 4030011600 S.CER C1608 JB 1E 104K-T T 57.6/11.4
C10 4510008520 S.ELE EEE1CA470SP T 52/15.5
C11 4030006900 S.CER C1608 JB 1H 103K-T T 60.4/11.4
C12 4510008520 S.ELE EEE1CA470SP T 64.9/15.5
C15 4030006880 S.CER C1608 JB 1H 472K-T T 104.3/20.4
C16 4030006880 S.CER C1608 JB 1H 472K-T T 103/23.1
C17 4510008550 S.ELE EEE1HA010SR T 95.9/22.8
C102 4030017810 S.CER C1608 CH 1H 102J-T T 4.1/76.2
C103 4030011600 S.CER C1608 JB 1E 104K-T T 9.2/72.5
C104 4030011600 S.CER C1608 JB 1E 104K-T T 9.5/75.2
C106 4030017320 S.CER GRM21BB11H104KA01L T 2.2/67.7
C107 4030011600 S.CER C1608 JB 1E 104K-T T 9.2/70.9
C108 4030017810 S.CER C1608 CH 1H 102J-T T 9.2/69.6
C109 4030017320 S.CER GRM21BB11H104KA01L T 8.1/62.6
C110 4030017810 S.CER C1608 CH 1H 102J-T T 9/64.2
C111 4030017810 S.CER C1608 CH 1H 102J-T T 9/56.4
C112 4030017320 S.CER GRM21BB11H104KA01L T 8.7/54.8
C113 4030011600 S.CER C1608 JB 1E 104K-T T 5.3/102.4
C114 4030011600 S.CER C1608 JB 1E 104K-T T 13.9/60.6
C201 4030017320 S.CER GRM21BB11H104KA01L T 18.2/43.1
C202 4030017810 S.CER C1608 CH 1H 102J-T T 15.7/61.3
C204 4030008490 S.CER C2012 JB 1H 682K-T T 31.2/61.6
C206 4030008700 S.CER GRM21BB11H473KA01L T 29.3/61.6
C207 4030008700 S.CER GRM21BB11H473KA01L T 34.4/36.7
C301 4030004760 S.CER C2012 JF 1H 104Z-T T 49.4/45.5
C303 4030011600 S.CER C1608 JB 1E 104K-T T 43.4/35.4
C305 4030004760 S.CER C2012 JF 1H 104Z-T T 44.4/42.6
C307 4030017810 S.CER C1608 CH 1H 102J-T T 39.7/31.7
C309 4030011600 S.CER C1608 JB 1E 104K-T T 41.1/31.7
C311 4030018750 S.CER C3225 CH 2J 682K-T T 54.1/58.9
C313 4030011600 S.CER C1608 JB 1E 104K-T T 89.1/26.9
C314 4510008050 ELE 63 ME 220 CZ
C317 4030018790 S.CER C3225 JB 2E 104K-T T 76.8/34
C318 4030011600 S.CER C1608 JB 1E 104K-T T 77.2/96.7
C319 4030018790 S.CER C3225 JB 2E 104K-T T 70.4/79
C401 4030011790 S.CER GRM55RF52A684ZD01L T 92.4/82.2
C402 4030011790 S.CER GRM55RF52A684ZD01L T 92.4/51.8
C403 4030011600 S.CER C1608 JB 1E 104K-T T 79.9/100.1
C404 4030011600 S.CER C1608 JB 1E 104K-T T 88.6/30.3
C405 4030006900 S.CER C1608 JB 1H 103K-T T 79.9/98.8
C406 4030006900 S.CER C1608 JB 1H 103K-T T 88.6/31.6
C407 4030017810 S.CER C1608 CH 1H 102J-T T 79.9/97.5
C408 4030017810 S.CER C1608 CH 1H 102J-T T 88.6/32.9
C409 4030018790 S.CER C3225 JB 2E 104K-T T 111.3/100.2
C410 4030018790 S.CER C3225 JB 2E 104K-T T 111.2/33.9
C411 4030006880 S.CER C1608 JB 1H 472K-T T 114.9/99.1
C412 4030006880 S.CER C1608 JB 1H 472K-T T 116.3/35
C413 4030011600 S.CER C1608 JB 1E 104K-T T 97.8/99.1
C414 4030011600 S.CER C1608 JB 1E 104K-T T 97.4/36.5
C415 4030011790 S.CER GRM55RF52A684ZD01L T 102.8/88.8
C416 4030011790 S.CER GRM55RF52A684ZD01L T 103.8/49
C417 4030018760 S.CER C4532 CH 2A 104K-T T 190.2/82.6
C418 4030018760 S.CER C4532 CH 2A 104K-T T 193.9/82.6
C419 4030018760 S.CER C4532 CH 2A 104K-T T 190.2/53.4
C420 4030018760 S.CER C4532 CH 2A 104K-T T 193.9/53.4
C501 4030018790 S.CER C3225 JB 2E 104K-T T 178.5/30.3
C502 4030018780 S.CER C3225 JB 2J 473K-T T 178.5/33.7
C503 4030018770 S.CER C3216 CH 2J 102J-T T 178.4/36.8
C504 4510006830 ELE 63 ME 470CZ
C505 4510006830 ELE 63 ME 470CZ
C506 4030006880 S.CER C1608 JB 1H 472K-T T 173.7/15.9
C507 4030006880 S.CER C1608 JB 1H 472K-T T 137.2/17
C510 4030018790 S.CER C3225 JB 2E 104K-T T 170.2/13.6
C511 4030018780 S.CER C3225 JB 2J 473K-T T 170.2/10.6
C512 4030018770 S.CER C3216 CH 2J 102J-T T 169.9/7.2
C513 4510008050 ELE 63 ME 220 CZ
C514 4030011790 S.CER GRM55RF52A684ZD01L T 164.8/6.7
C515 4030011790 S.CER GRM55RF52A684ZD01L T 148.4/6.6
C551 4030018370 S.CER ERF22X 6C1H 102J D01L T 144.7/39.5
C553 4030006880 S.CER C1608 JB 1H 472K-T T 152.6/35.5
C554 4030006880 S.CER C1608 JB 1H 472K-T T 159.8/27.8
J1 6510007020 CNR TMP-J01X-V6
J2 6510023261 S.CNR B6B-PH-SM4-TB (LF) (SN) T 6/24
J5 6510020421 S.CNR S4B-PH-SM4-TB (LF) (SN) T 93/4.5
J401 6510017920 CNR 1811P342
J402 6910001040 CNR IPS-1136
W401 9025900670 WIR 23/05/060/B21/W07
W501 9040401001 JMP 74/98/050/X98/X98
EP501 6910011330 TER OT-009 M3
EP502 6910011330 TER OT-009 M3
EP503 6910000640 BEA FSRH090160RN000B
