5 - 34
M.=Mounted side (T: Mounted on the Top side B: Mounted on the Bottom side)
[CTRL BOARD]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
C211 4030006880 S.CER C1608 JB 1H 472K-T B 59.1/67.4
C212 4030006880 S.CER C1608 JB 1H 472K-T B 60.7/49
C213 4030006880 S.CER C1608 JB 1H 472K-T B 65.4/56.6
C214 4030007170 S.CER C1608 CH 1H 221J-T B 56.7/64.1
C215 4030007170 S.CER C1608 CH 1H 221J-T B 56.7/52.3
C216 4030011340 S.CER C1608 CH 1H 471J-T B 56/61.9
C217 4030011340 S.CER C1608 CH 1H 471J-T B 56/54.5
C218 4030006880 S.CER C1608 JB 1H 472K-T B 65.4/59.7
C221 4030009530 S.CER C1608 CH 1H 030B-T T 51.2/45.7
C222 4030009910 S.CER C1608 CH 1H 040B-T T 49.9/45.7
C251 4030011020 S.CER GRM31M4C2H1R0CY21L B 88.3/32.5
C253 4030006880 S.CER C1608 JB 1H 472K-T B 76.3/25.9
C254 4030006880 S.CER C1608 JB 1H 472K-T B 76.3/39.2
C255 4030011090 S.CER GRM31M2C2H7R0DV01L B 107.7/49.3
C301 4010005520 CER HM60SJ SL 010C 500V
[USA], [EUR], [UK]
4030011020 S.CER GRM31M4C2H1R0CY21L
[FRA], [ITR], [ESP], [KOR]
C302 4030007030 S.CER C1608 CH 1H 150J-T T 82.1/51.7
C303 4030007050 S.CER C1608 CH 1H 220J-T T 82.1/49.1
C304 4030017810 S.CER C1608 CH 1H 102J-T B 85.7/55.1
C305 4030017810 S.CER C1608 CH 1H 102J-T B 86.5/57.7
C307 4030006880 S.CER C1608 JB 1H 472K-T T 86.5/60.5
C308 4030011600 S.CER C1608 JB 1E 104K-T B 78.5/55.1
C309 4030011600 S.CER C1608 JB 1E 104K-T T 78.4/55.1
C310 4030009530 S.CER C1608 CH 1H 030B-T T 82.1/50.4
C311 4030012600 S.CER C2012 JB 1A 105M-T T 86.2/55.4
C417 4510008540 S.ELE EEE1CA100SR T 22.6/77.6
C418 4510008540 S.ELE EEE1CA100SR T 40.6/85.6
C419 4030011600 S.CER C1608 JB 1E 104K-T T 19.6/78.7
C420 4030011600 S.CER C1608 JB 1E 104K-T T 38.4/79.2
C425 4030018790 S.CER C3225 JB 2E 104K-T B 77.4/12.1
C426 4030018790 S.CER C3225 JB 2E 104K-T B 60.3/17
C427 4030006860 S.CER C1608 JB 1H 102K-T B 67.1/7.9
C428 4030006860 S.CER C1608 JB 1H 102K-T B 50.1/7.9
C429 4030011600 S.CER C1608 JB 1E 104K-T B 68.9/7.9
C430 4030011600 S.CER C1608 JB 1E 104K-T B 48.3/7.9
C431 4030006880 S.CER C1608 JB 1H 472K-T B 70.7/7.9
C432 4030018790 S.CER C3225 JB 2E 104K-T B 86/12.3
C433 4030018790 S.CER C3225 JB 2E 104K-T B 82.7/11.7
C434 4030006880 S.CER C1608 JB 1H 472K-T T 92.7/11.7
C435 4030011600 S.CER C1608 JB 1E 104K-T B 20.5/80.1
C436 4030011600 S.CER C1608 JB 1E 104K-T B 19.5/101.6
RL252 6330001460 RLY FTR-F1CA012V
RL253 6330001460 RLY FTR-F1CA012V
RL254 6330001770 RLY SIP-1A-12Y
CP1 6910009670 S.CHK HK3-S-T T 67.7/100.1
CP101 6910009670 S.CHK HK3-S-T T 5/83.4
J1 6510023771 S.CNR 52793-2470 (2490) T 101.8/99.6
J2 6510023761 S.CNR S10B-PH-SM4-TB (LF) (SN) T 148.3/82.8
J51 6510023771 S.CNR 52793-2470 (2490) T 43.9/99.6
J52 6510022031 S.CNR B10B-ZR-SM4-TF (LF) (SN) T 133/2.9
J53 6510021431 S.CNR S8B-ZR-SM4A-TF (LF) (SN) T 134.6/65
J101 6510017920 CNR 1811P342
J251 6510017920 CNR 1811P342
J252 6510017920 CNR 1811P342
J301 6510017920 CNR 1811P342
J351 6510007020 CNR TMP-J01X-V6
W1 9029804001 WIR 72/99/040/X98/X98
EP1 9040902903 TUB IRRAX 0.7 (d) L=22 mm
EP3 6910014690 S.BEA MPZ1608S221A-T B 115.7/68.2
EP4 6910014690 S.BEA MPZ1608S221A-T B 113.5/62.3
EP5 6910014730 S.BEA MPZ2012S331A-T B 117.9/95.2
EP6 6910014730 S.BEA MPZ2012S331A-T T 109.7/91.2
EP7 6910014730 S.BEA MPZ2012S331A-T T 106.7/91.2
EP8 6910014730 S.BEA MPZ2012S331A-T T 103.8/91.2
EP9 6910014690 S.BEA MPZ1608S221A-T T 94/91.7
EP10 6910014730 S.BEA MPZ2012S331A-T T 90.8/90.6
EP12 6910015970 S.BEA MMZ1608B 301CT-AS B 95.2/63.3
EP13 6910015970 S.BEA MMZ1608B 301CT-AS T 79.4/63.1
EP14 6910014730 S.BEA MPZ2012S331A-T B 56.3/95.6
EP15 6910014730 S.BEA MPZ2012S331A-T B 44.6/97.9
EP16 6910014730 S.BEA MPZ2012S331A-T T 28.7/95.5
EP401 6910014690 S.BEA MPZ1608S221A-T B 28.1/100.9
EP402 6910014690 S.BEA MPZ1608S221A-T B 21.9/100.9
S.=Surface mount
[NETWORK BOARD]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
Q300 1520000561 S.TR 2SB1123 T-TD-E T 205.7/10.5
Q301 1590000680 S.TR DTC114EUA T106 T 201.4/9.1
L50 6110003950 COL LA-598
L60 6110003910 COL LA-593
L70 6110003050 COL LA-492
L80 6110003050 COL LA-492
L90 6110003060 COL LA-493
L100 6110003070 COL LA-494
L110 6110003920 COL LA-594
L120 6140004460 COL LR-504
L130 6140004470 COL LR-505
L131 6140004470 COL LR-505
L300 6180000990 COL LAL 04NA 101K
R300 7030000420 S.RES MCR10EZHJ 2.2 k T 202.8/6.9
R301 7030000420 S.RES MCR10EZHJ 2.2 k T 201.5/11.3
R302 7030000420 S.RES MCR10EZHJ 2.2 k T 206.2/6.9
R303 7030009800 S.RES ERJ12YJ121U (120) T 209.7/5
C1 4620000120 VAR UV44 150P
C2 4620000120 VAR UV44 150P
C3 4010007580 CER HT20SJ SL 201J 3KV
C4 4010007580 CER HT20SJ SL 201J 3KV
C5 4010007580 CER HT20SJ SL 201J 3KV
C6 4010007580 CER HT20SJ SL 201J 3KV
C7 4010007580 CER HT20SJ SL 201J 3KV
C8 4010007580 CER HT20SJ SL 201J 3KV
C9 4010007580 CER HT20SJ SL 201J 3KV
C10 4010007580 CER HT20SJ SL 201J 3KV
C18 4030006880 S.CER C1608 JB 1H 472K-T T 92.6/102.4
C19 4030006880 S.CER C1608 JB 1H 472K-T T 95.2/1.3
C20 4010007570 CER HT15SJ SL 151J 3KV
C21 4010007570 CER HT15SJ SL 151J 3KV
C22 4010007570 CER HT15SJ SL 151J 3KV
C23 4010007570 CER HT15SJ SL 151J 3KV
C24 4010007570 CER HT15SJ SL 151J 3KV
C25 4010007570 CER HT15SJ SL 151J 3KV
C26 4010007570 CER HT15SJ SL 151J 3KV
C27 4010007570 CER HT15SJ SL 151J 3KV
C28 4030006880 S.CER C1608 JB 1H 472K-T T 84.3/102.4
C29 4030006880 S.CER C1608 JB 1H 472K-T T 85.3/1.3
C30 4010007550 CER HT11SJ SL 820J 3KV
C31 4010007550 CER HT11SJ SL 820J 3KV
C32 4010007550 CER HT11SJ SL 820J 3KV
C33 4010007550 CER HT11SJ SL 820J 3KV
C34 4010007550 CER HT11SJ SL 820J 3KV
C35 4010007550 CER HT11SJ SL 820J 3KV
C36 4010007550 CER HT11SJ SL 820J 3KV
C37 4010007550 CER HT11SJ SL 820J 3KV
C38 4030006880 S.CER C1608 JB 1H 472K-T T 65.7/102.4
C39 4030006880 S.CER C1608 JB 1H 472K-T T 71.8/1.3
C40 4010008550 CER DEA1X3F390JC3B
C41 4010008550 CER DEA1X3F390JC3B
C42 4010008550 CER DEA1X3F390JC3B
C43 4010008550 CER DEA1X3F390JC3B
C44 4010008550 CER DEA1X3F390JC3B
C45 4010008550 CER DEA1X3F390JC3B
C46 4010008550 CER DEA1X3F390JC3B
C47 4010008550 CER DEA1X3F390JC3B
C48 4030006880 S.CER C1608 JB 1H 472K-T T 106.1/102.4
C49 4030006880 S.CER C1608 JB 1H 472K-T T 112.1/1.3
C50 4030006880 S.CER C1608 JB 1H 472K-T T 140.7/12
C60 4030006880 S.CER C1608 JB 1H 472K-T T 154.1/12
C70 4030006880 S.CER C1608 JB 1H 472K-T T 167.5/16.1
C80 4030006880 S.CER C1608 JB 1H 472K-T T 181.9/21.5
C90 4030006880 S.CER C1608 JB 1H 472K-T T 195.3/21.3
C100 4030006880 S.CER C1608 JB 1H 472K-T T 204.4/20.7
C110 4030006880 S.CER C1608 JB 1H 472K-T T 205.8/20.7
C120 4030006880 S.CER C1608 JB 1H 472K-T T 207.2/20.6
C211 4030006880 S.CER C1608 JB 1H 472K-T T 196.2/16.4
C212 4030006880 S.CER C1608 JB 1H 472K-T T 194.1/18.9
C213 4030006880 S.CER C1608 JB 1H 472K-T T 192.1/19.6
C214 4030006880 S.CER C1608 JB 1H 472K-T T 190.7/19.6
C301 4030006880 S.CER C1608 JB 1H 472K-T T 210.5/10.1
C303 4030006880 S.CER C1608 JB 1H 472K-T T 199.3/9
RL10 6330001200 RLY VS-12MBU-UC
RL11 6330001200 RLY VS-12MBU-UC
RL20 6330001200 RLY VS-12MBU-UC
RL21 6330001200 RLY VS-12MBU-UC
RL30 6330001200 RLY VS-12MBU-UC
RL31 6330001200 RLY VS-12MBU-UC
RL40 6330001200 RLY VS-12MBU-UC
RL41 6330001200 RLY VS-12MBU-UC
RL50 6330001460 RLY FTR-F1CA012V
RL60 6330001200 RLY VS-12MBU-UC
RL70 6330001200 RLY VS-12MBU-UC
RL80 6330001200 RLY VS-12MBU-UC
RL90 6330001200 RLY VS-12MBU-UC
RL100 6330001200 RLY VS-12MBU-UC
RL110 6330001200 RLY VS-12MBU-UC
RL120 6330001200 RLY VS-12MBU-UC
J1 6510021561 S.CNR 52808-2470 (2490) T 184.9/7.4
J2 6510017930 CNR 1771P145-20
J3 6510017930 CNR 1771P145-20
J4 6510003521 CNR S04B-EH-S (LF) (SN)
