5 - 35
M.=Mounted side (T: Mounted on the Top side B: Mounted on the Bottom side)
[NETWORK BOARD]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
EP2 6910014730 S.BEA MPZ2012S331A-T T 198.2/3.3
EP3 6910014730 S.BEA MPZ2012S331A-T T 183.9/2.7
EP4 6910014730 S.BEA MPZ2012S331A-T T 170.7/4
EP202 6910015970 S.BEA MMZ1608B 301CT-AS T 187.4/11.9
EP203 6910015970 S.BEA MMZ1608B 301CT-AS T 188.4/14.6
EP204 6910015970 S.BEA MMZ1608B 301CT-AS T 189.4/11.9
EP205 6910015970 S.BEA MMZ1608B 301CT-AS T 190.4/14.6
EP206 6910015970 S.BEA MMZ1608B 301CT-AS T 191.4/11.9
EP207 6910015970 S.BEA MMZ1608B 301CT-AS T 192.4/14.6
EP208 6910015970 S.BEA MMZ1608B 301CT-AS T 193.4/11.9
EP209 6910015970 S.BEA MMZ1608B 301CT-AS T 194.4/14.6
EP252 6910015970 S.BEA MMZ1608B 301CT-AS T 175.4/11.8
EP253 6910015970 S.BEA MMZ1608B 301CT-AS T 176.4/14.2
EP254 6910015970 S.BEA MMZ1608B 301CT-AS T 177.4/11.8
EP255 6910015970 S.BEA MMZ1608B 301CT-AS T 178.4/14.2
EP256 6910015970 S.BEA MMZ1608B 301CT-AS T 179.4/11.8
EP257 6910015970 S.BEA MMZ1608B 301CT-AS T 180.4/14.2
EP258 6910015970 S.BEA MMZ1608B 301CT-AS T 181.4/11.8
EP259 6910015970 S.BEA MMZ1608B 301CT-AS T 182.4/14.2
EP300 6910015970 S.BEA MMZ1608B 301CT-AS T 185/11.8
S.=Surface mount
[OSC UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
IC10 1180002610 S.REG BA12FP-E2 T 59.9/37.5
IC1091 1190002001 S.IC AD5260BRUZ50 T 26.8/12
IC1092 1130005721 S.IC TC7W04F (TE12L,F) T 23.7/6.1
Q1010 1590000680 S.TR DTC114EUA T106 T 30.7/17.9
Q1011 1590000680 S.TR DTC114EUA T106 T 24.9/36.4
Q1012 1590000680 S.TR DTC114EUA T106 T 44.4/32.8
Q1013 1590000680 S.TR DTC114EUA T106 T 41.8/32.8
Q1021 1530002060 S.TR 2SC4081 T106 R T 11.3/6.3
Q1022 1530002601 S.TR 2SC4215-O (TE85R,F) T 10.4/17.8
Q1023 1590000680 S.TR DTC114EUA T106 T 13.1/11
Q1042 1530002601 S.TR 2SC4215-O (TE85R,F) T 18.8/18.8
Q1043 1590000680 S.TR DTC114EUA T106 T 19.7/11.7
Q1061 1530002060 S.TR 2SC4081 T106 R T 29.8/29.6
Q1062 1530002060 S.TR 2SC4081 T106 R T 24/32
Q1070 1530002060 S.TR 2SC4081 T106 R T 18.3/41.3
Q1101 1530002700 S.TR 2SC4097 T106Q T 66.1/17.8
D1010 1790001250 S.DIO MA2S111-(TX) T 30.5/16
D1011 1790001250 S.DIO MA2S111-(TX) T 21.7/37.4
D1071 1750000381 S.DIO 1SS312 (TE85L,F) T 32.4/27
D1072 1750000381 S.DIO 1SS312 (TE85L,F) T 32.7/30.4
X10 6050012210 XTL CR-772.OCVXO-148A
L1020 6200005491 S.COL NLV32T-331J T 14.7/1.9
L1021 6200003261 S.COL NLV32T-101J T 7.7/10.9
L1022 6200003261 S.COL NLV32T-101J T 6.2/16
L1023 6200003051 S.COL NLV32T-R82J T 6.9/20.3
L1024 6200003051 S.COL NLV32T-R82J T 6.2/23.8
L1041 6200003261 S.COL NLV32T-101J T 15.3/13.7
L1042 6200003261 S.COL NLV32T-101J T 14.7/17.2
L1043 6200003051 S.COL NLV32T-R82J T 15.3/22.4
L1044 6200003051 S.COL NLV32T-R82J T 18.8/24.2
L1061 6150004170 COL LS-476
L1062 6150004170 COL LS-476
R1011 7030003200 S.RES ERJ3GEYJ 100 V (10) T 32.7/17
R1012 7030003200 S.RES ERJ3GEYJ 100 V (10) T 23.8/38.4
R1013 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 16.9/11.6
R1020 7030003240 S.RES ERJ3GEYJ 220 V (22) T 11.3/1.8
R1021 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 11.1/4.4
R1022 7030003370 S.RES ERJ3GEYJ 271 V (270) T 15.5/7.9
R1023 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7) T 11.4/14
R1024 7030003370 S.RES ERJ3GEYJ 271 V (270) T 12.3/17.7
R1025 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) T 10.1/14.2
R1026 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) T 13/9.1
R1027 7030003360 S.RES ERJ3GEYJ 221 V (220) T 8.8/14.3
R1028 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 10.2/11.9
R1043 7030003240 S.RES ERJ3GEYJ 220 V (22) T 19.7/14.2
R1044 7030003370 S.RES ERJ3GEYJ 271 V (270) T 20.7/18.6
R1045 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) T 17.9/15.1
R1046 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) T 19.5/9.8
R1047 7030003290 S.RES ERJ3GEYJ 560 V (56) T 16.8/17.9
R1061 7030003240 S.RES ERJ3GEYJ 220 V (22) T 27.8/28.4
R1062 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 29.6/27.7
R1063 7030003380 S.RES ERJ3GEYJ 331 V (330) T 29.9/31.5
R1064 7030003280 S.RES ERJ3GEYJ 470 V (47) T 25.2/34
R1065 7030003400 S.RES ERJ3GEYJ 471 V (470) T 24.3/27.5
R1067 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 24.3/30.1
R1068 7030003550 S.RES ERJ3GEYJ 822 V (8.2 k) T 26/32.2
R1071 7030003340 S.RES ERJ3GEYJ 151 V (150) T 32.9/33.7
R1072 7030003270 S.RES ERJ3GEYJ 390 V (39) T 34.8/32.8
R1073 7030003340 S.RES ERJ3GEYJ 151 V (150) T 32.9/32.4
R1074 7030003320 S.RES ERJ3GEYJ 101 V (100) T 24.2/41
R1075 7030003280 S.RES ERJ3GEYJ 470 V (47) T 26.2/41.8
R1077 7030003320 S.RES ERJ3GEYJ 101 V (100) T 11.8/41.7
R1078 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) T 16.4/41.2
R1079 7030003590 S.RES ERJ3GEYJ 183 V (18 k) T 15.1/41.2
R1080 7030003360 S.RES ERJ3GEYJ 221 V (220) T 21.6/41
R1091 7030006091 S.RES ERA3YED 822V (8.2 k) T 19.4/7.2
R1092 7030005341 S.RES ERA3YED 332V (3.3 k) T 19.5/8.5
R1093 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 25.6/1.4
R1094 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k) T 25.6/2.7
R1095 7030003320 S.RES ERJ3GEYJ 101 V (100) T 22.4/16.7
R1096 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 32/13.6
R1097 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 32/12.1
R1098 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 27.4/16
R1099 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) T 22.4/10.1
R1100 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 27.2/6.4
R1101 7030003360 S.RES ERJ3GEYJ 221 V (220) T 66/15.9
R1102 7030005981 S.RES ERA3YED 333V (33 k) T 32/8.8
R2016 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 48.5/36.1
R2017 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 45.1/35.7
R2018 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 42.5/35.7
C1004 4030006880 S.CER C1608 JB 1H 472K-T T 29.9/8.4
C1005 4550007670 S.TAN F931C105MAABMA T 29.2/3.2
C1006 4030006880 S.CER C1608 JB 1H 472K-T T 33/4
C1007 4550007670 S.TAN F931C105MAABMA T 31.3/3.2
C1008 4030011600 S.CER C1608 JB 1E 104K-T T 17.3/2.1
C1010 4510008680 S.ELE EEE1EA220SP T 52.8/35.2
C1011 4030011600 S.CER C1608 JB 1E 104K-T T 58.3/32
C1012 4030011600 S.CER C1608 JB 1E 104K-T T 65.1/34.7
C1013 4030006880 S.CER C1608 JB 1H 472K-T T 63.8/34.7
C1014 4510008680 S.ELE EEE1EA220SP T 69/31.2
C1015 4030006880 S.CER C1608 JB 1H 472K-T T 60.9/32
C1016 4030011600 S.CER C1608 JB 1E 104K-T T 28.7/16
[ANT-SW BOARD]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
IC11 1130011510 S.IC BU2099FV-E2 T 160.6/33.6
IC12 1180002391 S.REG S-812C33AMC-C2N-G T 152.4/28.7
Q11 1590001001 S.TR RN2427 (TE85L,F) T 156.9/38.6
Q12 1590001001 S.TR RN2427 (TE85L,F) T 152.3/36.9
Q13 1590001001 S.TR RN2427 (TE85L,F) T 164.7/38.5
Q14 1590001001 S.TR RN2427 (TE85L,F) T 164.7/17.5
D51 1750000550 S.DIO 1SS355 TE-17 T 161.9/13.3
D61 1750000550 S.DIO 1SS355 TE-17 T 118.9/19.7
D71 1750000550 S.DIO 1SS355 TE-17 T 68.7/21.4
D81 1750000550 S.DIO 1SS355 TE-17 T 36.9/19.7
D83 1750000550 S.DIO 1SS355 TE-17 T 28.2/45.3
D84 1750000550 S.DIO 1SS355 TE-17 T 25.8/43
L2 6110001670 COL LA-253
R3 7540000130 ABS 2P-50A-301
R11 7030003320 S.RES ERJ3GEYJ 101 V (100) T 165.5/27.4
R12 7030003320 S.RES ERJ3GEYJ 101 V (100) T 164.2/27.4
R13 7030003320 S.RES ERJ3GEYJ 101 V (100) T 162.9/27.4
R14 7030003320 S.RES ERJ3GEYJ 101 V (100) T 166.2/33.9
R15 7030003320 S.RES ERJ3GEYJ 101 V (100) T 153.9/32.6
R17 7030003320 S.RES ERJ3GEYJ 101 V (100) T 154.7/39.4
R18 7030003320 S.RES ERJ3GEYJ 101 V (100) T 153.9/34
R20 7030003320 S.RES ERJ3GEYJ 101 V (100) T 152.1/39.1
R21 7030003320 S.RES ERJ3GEYJ 101 V (100) T 154.7/36.6
R23 7030003320 S.RES ERJ3GEYJ 101 V (100) T 162.3/39.1
R24 7030003320 S.RES ERJ3GEYJ 101 V (100) T 161/39.1
R26 7030003320 S.RES ERJ3GEYJ 101 V (100) T 162.7/15.6
C1 4010005610 CER HM60SJ SL 100D 500V
C2 4010005660 CER HM60SJ SL 220J 500V
C11 4030011600 S.CER C1608 JB 1E 104K-T T 160.7/29.4
C12 4030011600 S.CER C1608 JB 1E 104K-T T 154.9/27.9
C51 4030006880 S.CER C1608 JB 1H 472K-T T 163.5/13.6
C61 4030006880 S.CER C1608 JB 1H 472K-T T 119.2/21.3
C71 4030006880 S.CER C1608 JB 1H 472K-T T 69/19.9
C81 4030006880 S.CER C1608 JB 1H 472K-T T 37.2/21.3
C83 4030006880 S.CER C1608 JB 1H 472K-T T 26.6/45.6
C84 4030006880 S.CER C1608 JB 1H 472K-T T 25/45.6
RL51 6330001460 RLY FTR-F1CA012V
RL61 6330001460 RLY FTR-F1CA012V
RL71 6330001460 RLY FTR-F1CA012V
RL81 6330001460 RLY FTR-F1CA012V
RL83 6330001780 RLY FTR-MYAA012D
RL84 6330001780 RLY FTR-MYAA012D
J1 6510017930 CNR 1771P145-20
J3 6510007020 CNR TMP-J01X-V6
J4 6510019971 S.CNR 52808-1071 T 153/22
J51 6510000410 CNR MR-DS-E 02
J61 6510000410 CNR MR-DS-E 02
J71 6510000410 CNR MR-DS-E 02
J81 6510000410 CNR MR-DS-E 02
EP2 6910014730 S.BEA MPZ2012S331A-T T 151.5/26.1
