D General
• Frequency coverage : (unit: MHz)
Version
A band B band
U.S.A. Tx: 144–148, 420–450*
1
Rx: 0.495–823.990*
1,
*
2
,
849–868.990,
894–999.990
Tx: 144–148, 420–450*
1
Rx: 118–174*
2
, 350–470*
1
CAN Tx: 144–148, 420–450*
1
Rx: 0.495–999.990*
1,
*
2
Tx: 144–148, 420–450*
1
Rx: 118–174*
2
, 350–470*
1
S.E.A.
CHN
EXP
Tx: 137–174*
2
, 400–470*
3
Rx: 0.495–999.990*
2,
*
3
Tx: 137–174 *
2
, 400–470*
3
Rx: 118–174*
2
, 350–470*
3
*
1
Guaranteed 440–450 MHz only, *
2
Guaranteed 144–148 MHz only,
*
3
Guaranteed 430–440 MHz only
• Mode : FM, FN-N, AM (Rx only), WFM (Rx only), DV
• No. of memory channels : 1304
(incl. 100 scan edges and 4 call channels)
• Usable temp. range : –20°C to +60°C; –4°F to +140°F
• Tuning steps : 5
‡
, 6.25
‡
, 8.33
‡
, 9
‡
, 10, 12.5, 15, 20,
25, 30, 50, 100, 125 and 200 kHz
• Frequency stability : ±2.5 ppm
(–20°C to +60°C; –4°F to +140°F)
• Power supply : 10.0–16.0 V DC for external DC power,
or specifi ed Icom’s battery pack
• Digital transmission speed : 4.8 kbps
• Voice coding speed : 2.4 kbps
• Current drain (at 7.4 V DC) :
Tx High 144 MHz 1.8 A typical
430/440 MHz 2.1 A typical
Tx Mid. 144 MHz 1.2 A typical
430/440 MHz 1.5 A typical
Tx Low 144 MHz 0.6 A typical
430/440 MHz 0.7 A typical
Tx S-Low 0.4 A typical
Rx Rated output 150 mA typical (single watch; FM)
180 mA typical (dualwatch; FM/FM)
200 mA typical (single watch; DV)
220 mA typical (dualwatch; FM/DV)
Power save 38 mA typical (single watch; FM)
(Duty 1:4)
43 mA typical (dualwatch; FM/FM)
47 mA typical (single watch; DV)
50 mA typical (dualwatch; FM/DV)
standby 65 mA typical (single watch; FM)
90 mA typical (dualwatch; FM/FM)
110 mA typical (single watch; DV)
130 mA typical (dualwatch; FM/DV)
• Antenna connector : SMA (50 Ω)
• Dimensions : 59(W)×112(H)×34.2(D) mm;
(projections not included) 2
5
⁄16(W)×4
13
⁄32(H)×1
11
⁄32(D) in
• Weight (approx.) : 325 g; 11.5 oz (with antenna and BP-256)
D Transmitter
• Modulation system :
FM Variable reactance freq. modulation
DV (Digital) GMSK reactance freq. modulation
• Output power (at 7.4 V DC)
(Typical) : High 5.0 W, Mid. 2.5 W, Low 0.5 W,
S-Low 0.1 W
• Max. frequency deviation : ±5.0 kHz (FM wide: approx.)
±2.5 kHz (FM narrow: approx.)
• Spurious emissions : Less than –60 dBc at High/Mid.
Less than –13 dBm at Low/Slow
• Ext. mic. impedance : 2 kΩ
‡
Selectable depending on the operating frequency band.
