The underlined parts have been updated from the addendum of the previous version, or from the original page.
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=
Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
REF
NO.
PARTS
NO.
DESCRIPTION M
.
H/V
LOCATION
REF
NO.
PARTS
NO.
DESCRIPTION M
.
H/V
LOCATION
5-4a
(Amended page)
June 2019
[MAIN UNIT] [MAIN UNIT]
R540 7030016020 S.RES RMC1/16S-104JTH (100 k) T 118.8/110.2
R541 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 134.3/121.5
R543 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 132.8/114.5
R545 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 136.3/121.5
R547 7030016020 S.RES RMC1/16S-104JTH (100 k) T 122.0/105.5
R548 7030016020 S.RES RMC1/16S-104JTH (100 k) T 122.0/104.5
R551 7030016250 S.RES RMC1/16S-220JTH (22) T 125.0/106.5
R552 7030016150 S.RES RMC1/16S-100JTH (10) T 125.0/108.5
R553 7030016150 S.RES RMC1/16S-100JTH (10) T 125.0/110.5
R554 7410001240 S.ARR EXB28V220JX T 125.0/98.0
R555 7410001240 S.ARR EXB28V220JX T 125.0/100.5
R556 7030016250 S.RES RMC1/16S-220JTH (22) T 139.9/112.5
R558 7030015910 S.RES RMC1/16S-101JTH (100) T 121.1/109.5
R559 7030015910 S.RES RMC1/16S-101JTH (100) T 121.1/110.4
R571 7030016800 S.RES RMC1/16SK104FTH (100 k) T 133.6/112.5
R572 7030016020 S.RES RMC1/16S-104JTH (100 k) T 130.9/112.5
R573 7030016020 S.RES RMC1/16S-104JTH (100 k) T 131.8/112.5
R574 7030016020 S.RES RMC1/16S-104JTH (100 k) T 135.4/112.5
R575 7030016020 S.RES RMC1/16S-104JTH (100 k) T 136.3/112.5
R576 7030016020 S.RES RMC1/16S-104JTH (100 k) T 129.1/112.5
R577 7030016040 S.RES RMC1/16S-224JTH (220 k) T 121.4/100.6
R578 7030016040 S.RES RMC1/16S-224JTH (220 k) T 121.4/101.5
R579 7030016040 S.RES RMC1/16S-224JTH (220 k) T 121.4/99.7
R580 7030016040 S.RES RMC1/16S-224JTH (220 k) T 121.4/98.8
R583 7030016040 S.RES RMC1/16S-224JTH (220 k) T 121.4/102.4
R584 7030016040 S.RES RMC1/16S-224JTH (220 k) T 122.0/103.5
R1002 7030015910 S.RES RMC1/16S-101JTH (100) T 77.9/134.5
R1004 7030017120 S.RES RGC1/16SC103DTH (10.0 k) T 77.9/137.4
R1005 7030016840 S.RES RGC1/16SC682DTH (6.80 k) T 79.2/136.9
R1006 7030018480 S.RES RGC1/16SC563DTH (56.0 k) T 77.9/139.2
R1007 7030016380 S.RES RMC1/16S-183JTH (18 k) T 77.9/140.1
R1008 7030016560 S.RES RMC1/16SJPTH T 76.6/140.5
R1011 7030016560 S.RES RMC1/16SJPTH T 108.2/140.8
R1012 7030016910 S.RES RGC1/16SC393DTH (39 k) T 107.2/140.3
R1013 7030016880 S.RES RGC1/16SC223DTH (22.0 k) T 107.2/142.0
R1021 7030016110 S.RES RMC1/16S-473JTH (47 k) T 143.8/125.0
R1041 7030016560 S.RES RMC1/16SJPTH T 90.9/136.5
R1044 7030016890 S.RES RGC1/16SC363DTH (36 k) T 88.5/134.3
R1045 7030016910 S.RES RGC1/16SC393DTH (39 k) T 88.5/133.4
R1046 7030016890 S.RES RGC1/16SC363DTH (36 k) T 88.5/136.1
R1047 7030016030 S.RES RMC1/16S-154JTH (150 k) T 88.1/138.1
R1048 7030016050 S.RES RMC1/16S-102JTH (1 k) T 89.7/135.5
R1051 7030016110 S.RES RMC1/16S-473JTH (47 k) T 177.9/22.2
R1052 7030016050 S.RES RMC1/16S-102JTH (1 k) T 177.4/24.0
R1053 7030016110 S.RES RMC1/16S-473JTH (47 k) T 180.3/24.7
R1071 7030006200 S.RES ERJ12YJ2R7U (2.7) T 98.8/124.6
R1091 7030010410 S.RES ERJ1TYJ 220U (22) T 29.3/122.0
R1093 7030016110 S.RES RMC1/16S-473JTH (47 k) T 33.8/120.0
R1094 7030016290 S.RES RMC1/16S-222JTH (2.2 k) T 27.5/125.3
R1101 7030015910 S.RES RMC1/16S-101JTH (100) T 63.0/134.1
R1103 7030016290 S.RES RMC1/16S-222JTH (2.2 k) T 61.5/135.0
R1104 7030018480 S.RES RGC1/16SC563DTH (56.0 k) T 63.0/135.0
R1105 7030016810 S.RES RGC1/16SC392DTH (3.90 k) T 63.0/136.8
R1106 7030016810 S.RES RGC1/16SC392DTH (3.90 k) T 63.0/137.7
R1111 7030016560 S.RES RMC1/16SJPTH T 65.9/126.0
R1114 7030016890 S.RES RGC1/16SC363DTH (36 k) T 66.8/128.1
R1115 7030018480 S.RES RGC1/16SC563DTH (56.0 k) T 65.9/128.1
R1116 7030016910 S.RES RGC1/16SC393DTH (39 k) T 65.0/128.1
R1117 7030016030 S.RES RMC1/16S-154JTH (150 k) T 67.7/124.8
R1118 7030016050 S.RES RMC1/16S-102JTH (1 k) T 67.3/126.9
R1119 7030015970 S.RES RMC1/16S-103JTH (10 k) T 66.2/112.7
R1202 7030015910 S.RES RMC1/16S-101JTH (100) T 87.2/120.1
R1204 7030016610 S.RES RGC1/16SC683DTH (68.0 k) T 89.0/120.1
R1205 7030016810 S.RES RGC1/16SC392DTH (3.90 k) T 90.3/121.0
R1206 7030017060 S.RES RGC1/16SC162DTH (1.6 k) T 89.4/121.9
R1212 7030015910 S.RES RMC1/16S-101JTH (100) T 62.2/122.9
R1214 7030016610 S.RES RGC1/16SC683DTH (68.0 k) T 58.8/128.5
R1215 7030018480 S.RES RGC1/16SC563DTH (56.0 k) T 60.6/128.5
R1216 7030016840 S.RES RGC1/16SC682DTH (6.80 k) T 61.5/128.5
R1221 7030010470 S.RES ERJ1TYJ 5R6U (5.6) T 18.2/123.0
R1222 7030010470 S.RES ERJ1TYJ 5R6U (5.6) T 22.6/123.0
R1261 7030013780 S.RES RCC16R020FTP T 5.0/21.2
R1262 7030015910 S.RES RMC1/16S-101JTH (100) T 7.2/22.6
R1263 7030008071 S.RES ERA3YED 273V (27 k) T 5.0/17.3
R1264 7030008071 S.RES ERA3YED 273V (27 k) T 6.3/18.1
R1265 7030006581 S.RES ERA3YED 122V (1.2 k) T 7.6/18.1
R1321 7030010580 S.RES ERJ1TYJ 1R5U (1.5) B 57.6/60.0
R1331 7030016470 S.RES RMC1/16S-390JTH (39) T 70.6/65.8
R1332 7030016470 S.RES RMC1/16S-390JTH (39) T 70.6/64.9
R1333 7030016470 S.RES RMC1/16S-390JTH (39) T 70.6/64.0
R1501 7030016380 S.RES RMC1/16S-183JTH (18 k) T 186.8/142.9
R1502 7030015970 S.RES RMC1/16S-103JTH (10 k) T 186.8/144.2
R1503 7030016360 S.RES RMC1/16S-123JTH (12 k) T 182.4/141.2
R1504 7030016110 S.RES RMC1/16S-473JTH (47 k) T 182.4/143.1
R1505 7030016020 S.RES RMC1/16S-104JTH (100 k) T 172.9/145.7
R1511 7030016380 S.RES RMC1/16S-183JTH (18 k) T 186.8/148.9
R1512 7030015970 S.RES RMC1/16S-103JTH (10 k) T 186.8/150.2
R1513 7030016360 S.RES RMC1/16S-123JTH (12 k) T 182.4/147.2
R1514 7030016110 S.RES RMC1/16S-473JTH (47 k) T 182.4/149.1
R1515 7030016020 S.RES RMC1/16S-104JTH (100 k) T 172.9/147.4
R1516 7030016020 S.RES RMC1/16S-104JTH (100 k) T 182.2/144.4
R1517 7030016250 S.RES RMC1/16S-220JTH (22) T 181.2/143.5
R1518 7030016250 S.RES RMC1/16S-220JTH (22) T 172.5/148.3
R1521 7030016110 S.RES RMC1/16S-473JTH (47 k) T 175.3/140.1
R1531 7030016050 S.RES RMC1/16S-102JTH (1 k) T 172.8/129.5
R1532 7030016060 S.RES RMC1/16S-105JTH (1 M) T 171.9/130.4
R1533 7030016060 S.RES RMC1/16S-105JTH (1 M) T 158.8/130.6
R1534 7030015950 S.RES RMC1/16S-152JTH (1.5 k) T 161.4/134.0
R1535 7030015970 S.RES RMC1/16S-103JTH (10 k) T 155.7/130.8
R1551 7030016110 S.RES RMC1/16S-473JTH (47 k) T 145.3/138.0
R1552 7030016110 S.RES RMC1/16S-473JTH (47 k) T 148.3/137.9
R1553 7030016250 S.RES RMC1/16S-220JTH (22) T 145.9/139.9
R1554 7030016250 S.RES RMC1/16S-220JTH (22) T 146.8/139.9
R1555 7030016020 S.RES RMC1/16S-104JTH (100 k) T 145.0/139.9
R1556 7030016250 S.RES RMC1/16S-220JTH (22) T 149.9/137.9
R1557 7030016250 S.RES RMC1/16S-220JTH (22) T 144.1/138.4
R1558 7030016020 S.RES RMC1/16S-104JTH (100 k) T 147.7/139.9
R1559 7030015970 S.RES RMC1/16S-103JTH (10 k) T 148.6/139.9
R1560 7030015970 S.RES RMC1/16S-103JTH (10 k) T 142.5/141.6
R1561 7030016110 S.RES RMC1/16S-473JTH (47 k) T 143.8/148.3
R1562 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 147.9/148.2
R1563 7030015970 S.RES RMC1/16S-103JTH (10 k) T 147.9/147.3
R1571 7030016110 S.RES RMC1/16S-473JTH (47 k) T 154.6/127.5
R1572 7030016110 S.RES RMC1/16S-473JTH (47 k) T 154.4/131.2
R1573 7030016250 S.RES RMC1/16S-220JTH (22) T 152.9/128.7
R1574 7030016250 S.RES RMC1/16S-220JTH (22) T 152.9/129.7
R1575 7030016020 S.RES RMC1/16S-104JTH (100 k) T 152.9/127.7
R1576 7030016250 S.RES RMC1/16S-220JTH (22) T 154.4/133.5
R1577 7030016250 S.RES RMC1/16S-220JTH (22) T 154.6/126.3
R1578 7030016020 S.RES RMC1/16S-104JTH (100 k) T 152.9/130.7
R1579 7030015970 S.RES RMC1/16S-103JTH (10 k) T 152.9/131.7
R1580 7030015970 S.RES RMC1/16S-103JTH (10 k) T 150.4/133.3
R1581 7030016110 S.RES RMC1/16S-473JTH (47 k) T 144.4/127.6
R1582 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 143.9/132.0
R1583 7030015970 S.RES RMC1/16S-103JTH (10 k) T 144.9/132.0
R1601 7030016330 S.RES RMC1/16S-153JTH (15 k) T 152.8/139.7
R1602 7030016520 S.RES RMC1/16S-270JTH (27) T 152.8/140.6
R1603 7030016330 S.RES RMC1/16S-153JTH (15 k) T 152.8/142.4
R1604 7030016520 S.RES RMC1/16S-270JTH (27) T 152.8/141.5
R1605 7030016330 S.RES RMC1/16S-153JTH (15 k) T 158.5/134.4
R1606 7030016520 S.RES RMC1/16S-270JTH (27) T 158.1/135.6
R1607 7030016330 S.RES RMC1/16S-153JTH (15 k) T 156.2/135.6
R1608 7030016520 S.RES RMC1/16S-270JTH (27) T 157.2/135.6
R1609 7030016330 S.RES RMC1/16S-153JTH (15 k) T 162.7/136.0
R1610 7030016520 S.RES RMC1/16S-270JTH (27) T 161.4/135.6
R1611 7030016330 S.RES RMC1/16S-153JTH (15 k) T 160.1/134.4
R1612 7030016520 S.RES RMC1/16S-270JTH (27) T 160.5/135.6
R1613 7030015950 S.RES RMC1/16S-152JTH (1.5 k) T 165.8/149.5
R1614 7030016020 S.RES RMC1/16S-104JTH (100 k) T 160.7/149.5
R1615 7030016520 S.RES RMC1/16S-270JTH (27) T 163.7/149.9
R1616 7030016520 S.RES RMC1/16S-270JTH (27) T 164.6/149.9
R1617 7030015950 S.RES RMC1/16S-152JTH (1.5 k) T 165.8/143.0
R1618 7030016060 S.RES RMC1/16S-105JTH (1 M) T 165.8/144.6
R1621 7030016050 S.RES RMC1/16S-102JTH (1 k) T 154.1/154.0
R1622 7030016110 S.RES RMC1/16S-473JTH (47 k) T 155.2/148.9
R1901 7030015910 S.RES RMC1/16S-101JTH (100) T 149.5/37.8
R1902 7030015910 S.RES RMC1/16S-101JTH (100) T 149.5/38.7
R1903 7030015910 S.RES RMC1/16S-101JTH (100) T 149.5/39.6
R1904 7030015910 S.RES RMC1/16S-101JTH (100) T 149.5/40.5
R1905 7030015910 S.RES RMC1/16S-101JTH (100) T 149.5/41.4
R1906 7030015910 S.RES RMC1/16S-101JTH (100) T 149.5/42.3
R1907 7030015910 S.RES RMC1/16S-101JTH (100) T 149.5/43.2
R1908 7030015910 S.RES RMC1/16S-101JTH (100) T 149.5/44.1
R1909 7030016110 S.RES RMC1/16S-473JTH (47 k) T 145.6/45.9
R1916 7030015950 S.RES RMC1/16S-152JTH (1.5 k) T 148.1/44.5
R1917 7030016560 S.RES RMC1/16SJPTH T 148.1/46.2
R1918 7030016270 S.RES RMC1/16S-151JTH (150) T 144.1/37.3
R1919 7030016060 S.RES RMC1/16S-105JTH (1 M) T 144.8/38.2
R1921 7030015910 S.RES RMC1/16S-101JTH (100) T 144.7/45.9
R1922 7030015910 S.RES RMC1/16S-101JTH (100) T 141.7/45.2
R1924 7030015970 S.RES RMC1/16S-103JTH (10 k) T 142.1/36.9
R1925 7030017180 S.RES RMC1/16K1212FTP (12.1 k) T 139.3/38.4
R1926 7030016660 S.RES RMC1/16SK49R9FTH (49.9) T 20.5/136.5
R1927 7030016660 S.RES RMC1/16SK49R9FTH (49.9) T 18.9/136.5
R1928 7030016660 S.RES RMC1/16SK49R9FTH (49.9) T 12.5/136.5
R1929 7030016660 S.RES RMC1/16SK49R9FTH (49.9) T 14.1/136.5
R1930 7030016560 S.RES RMC1/16SJPTH T 9.2/138.6
R1931 7030018740 S.RES RMC1/16S-750JTH (75) T 18.4/148.6
R1932 7030018740 S.RES RMC1/16S-750JTH (75) T 13.4/149.0
R1933 7030018740 S.RES RMC1/16S-750JTH (75) T 12.9/151.3
R1934 7030018740 S.RES RMC1/16S-750JTH (75) T 13.8/151.3
R1935 7030016560 S.RES RMC1/16SJPTH T 7.3/149.2
R1936 7030016370 S.RES RMC1/16S-271JTH (270) T 4.9/151.5
R1937 7030016370 S.RES RMC1/16S-271JTH (270) T 16.6/152.0
R2001 7030016560 S.RES RMC1/16SJPTH T 178.4/66.5
R2002 7410001240 S.ARR EXB28V220JX T 180.8/66.5
R2003 7410001240 S.ARR EXB28V220JX T 185.9/66.5
R2004 7030016040 S.RES RMC1/16S-224JTH (220 k) T 187.7/66.5
R2005 7030016560 S.RES RMC1/16SJPTH T 177.4/66.5
R2011 7030016560 S.RES RMC1/16SJPTH T 174.5/80.0
R2012 7030015910 S.RES RMC1/16S-101JTH (100) T 174.5/81.0
R2021 7030016430 S.RES RMC1/16S-392JTH (3.9 k) T 192.7/77.9
R2022 7030016050 S.RES RMC1/16S-102JTH (1 k) T 190.3/77.0
R2023 7030016360 S.RES RMC1/16S-123JTH (12 k) T 191.9/77.0
R2024 7030016430 S.RES RMC1/16S-392JTH (3.9 k) T 193.1/76.5
R2025 7030015910 S.RES RMC1/16S-101JTH (100) T 193.5/74.3
R2029 7030015910 S.RES RMC1/16S-101JTH (100) T 188.4/69.4
R2031 7030016430 S.RES RMC1/16S-392JTH (3.9 k) T 191.3/64.6
R2032 7030016050 S.RES RMC1/16S-102JTH (1 k) T 189.7/66.7
R2033 7030016360 S.RES RMC1/16S-123JTH (12 k) T 191.3/66.7
R2034 7030016430 S.RES RMC1/16S-392JTH (3.9 k) T 192.5/67.1
R2035 7030015910 S.RES RMC1/16S-101JTH (100) T 193.4/68.8
R2041 7030016420 S.RES RMC1/16S-182JTH (1.8 k) T 145.3/118.5
R2042 7030016050 S.RES RMC1/16S-102JTH (1 k) T 148.8/120.8
R2043 7030016080 S.RES RMC1/16S-822JTH (8.2 k) T 146.3/119.9
R2044 7030016500 S.RES RMC1/16S-562JTH (5.6 k) T 146.3/118.5
R2045 7030015910 S.RES RMC1/16S-101JTH (100) T 150.2/122.7
R2049 7030015910 S.RES RMC1/16S-101JTH (100) T 147.7/116.4
R2051 7030016480 S.RES RMC1/16S-821JTH (820) T 158.5/118.5
R2052 7030016050 S.RES RMC1/16S-102JTH (1 k) T 154.8/120.8
R2053 7030016430 S.RES RMC1/16S-392JTH (3.9 k) T 157.2/119.9
R2054 7030016080 S.RES RMC1/16S-822JTH (8.2 k) T 157.5/118.5
R2055 7030015910 S.RES RMC1/16S-101JTH (100) T 152.2/122.7
R2061 7030016480 S.RES RMC1/16S-821JTH (820) T 159.8/118.5
To Next Page
Loading...
