Icom IC-A110 Service Manual

5 - 3
S.=Surface mount
L36 6140000670 COIL LR-89
L39 6200004480 S.COIL MLF1608D R82K-T
L40 6200009080 S.COIL MC152-E558CN-100025=P3
L41 6200004850 S.COIL MC152-E558CN-100024
L42 6200004480 S.COIL MLF1608D R82K-T
L43 6200004480 S.COIL MLF1608D R82K-T
L48 6110001600 COIL LA-243
L49 6150005000 S.COIL LS-527
L50 6110001730 COIL LA-262
L52 6200004480 S.COIL MLF1608D R82K-T
L53 6190001500 COIL HK-08S070-1310
L54 6200007000 S.COIL ELJRE 82NG-F
L55 6200003310 S.COIL ELJFC R33M-F
L56 6200003310 S.COIL ELJFC R33M-F
L57 6200003310 S.COIL ELJFC R33M-F
L60 6200005010 S.COIL NL 252018T-100J
L61 6190001510 COIL HK-10S080-1210
L62 6190001500 COIL HK-08S070-1310
L63 6190001500 COIL HK-08S070-1310
L64 6190001500 COIL HK-08S070-1310
L65 6200005010 S.COIL NL 252018T-100J
L67 6200008760 S.COIL 0.26-0.9-9TR 30N
L68 6200009120 S.COIL 0.20-0.7-4TR 8.8N
L69 6200008270 S.COIL 0.26-1.0-5TL 17N
L70 6110001520 COIL LA-232
L71 6110002110 COIL LA-382
L72 6200002040 S.COIL NL 252018T-101J
L73 6200002040 S.COIL NL 252018T-101J
L75 6200004480 S.COIL MLF1608D R82K-T
L77 6200009140 S.COIL NL 252018T-6R8J
L78 6190001520 S.COIL ZBFS5101-PT
L79 6190001520 S.COIL ZBFS5101-PT
L80 6190001520 S.COIL ZBFS5101-PT
L81 6190001520 S.COIL ZBFS5101-PT
L82 6200004450 S.COIL ELJFC 6R8M-F
L83 6200004880 S.COIL ELJFC 3R3K-F
L84 6200004880 S.COIL ELJFC 3R3K-F
L85 6200004450 S.COIL ELJFC 6R8M-F
L86 6190001520 S.COIL ZBFS5101-PT
L87 6200006990 S.COIL ELJRE 56NG-F
R1 7030006070 S.RESISTOR ERJ12YJ101U (100 Ω)
R2 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R3 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R9 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R11 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R12 7030003730 S.RESISTOR ERJ3GEYJ 274 V (270 kΩ)
R13 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R14 7030003770 S.RESISTOR ERJ3GEYJ 564 V (560 kΩ)
R15 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
R17 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
R18 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R19 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R20 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R21 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R24 7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ)
R25 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R26 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R27 7030003470 S.RESISTOR ERJ3GEYJ 182 V (1.8 kΩ)
R28 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R30 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R31 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R34 7030003470 S.RESISTOR ERJ3GEYJ 182 V (1.8 kΩ)
R35 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R36 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R37 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ)
R38 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R40 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R41 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R42 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R43 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R45 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ)
R46 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R48 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ)
R49 7030003750 S.RESISTOR ERJ3GEYJ 394 V (390 kΩ)
R50 7030003430 S.RESISTOR ERJ3GEYJ 821 V (820 Ω)
R59 7310003600 S.TRIMMER EVM-1XSX50 B54 (503)
R61 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R62 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R63 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R64 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R65 7030003220 S.RESISTOR ERJ3GEYJ 150 V (15 Ω)
R66 7030003220 S.RESISTOR ERJ3GEYJ 150 V (15 Ω)
R67 7030003220 S.RESISTOR ERJ3GEYJ 150 V (15 Ω)
R68 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R69 7030003700 S.RESISTOR ERJ3GEYJ 154 V (150 kΩ)
R70 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R71 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
R72 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ)
R73 7030003370 S.RESISTOR ERJ3GEYJ 271 V (270 Ω)
R74 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ)
R75 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R76 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R77 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R78 7030003300 S.RESISTOR ERJ3GEYJ 680 V (68 Ω)
R79 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R80 7030003300 S.RESISTOR ERJ3GEYJ 680 V (68 Ω)
R85 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R86 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R87 7030003330 S.RESISTOR ERJ3GEYJ 121 V (120 Ω)
R95 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R99 7030003270 S.RESISTOR ERJ3GEYJ 390 V (39 Ω)
R101 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R108 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R110 7310003610 S.TRIMMER EVM-1XSX50 B14 (103)
R111 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R112 7030003270 S.RESISTOR ERJ3GEYJ 390 V (39 Ω)
R113 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R114 7510001100 S.THERMISTOR NTCCM1608 4LH 104KC
R115 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R116 7030003770 S.RESISTOR ERJ3GEYJ 564 V (560 kΩ)
R117 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R118 7030003690 S.RESISTOR ERJ3GEYJ 124 V (120 kΩ)
R119 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R120 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R121 7310003580 S.TRIMMER EVM-1XSX50 B15 (104)
R122 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ)
R123 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ)
R124 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ)
R126 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R127 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R128 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R131 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R132 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R148 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R149 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R150 7310003610 S.TRIMMER EVM-1XSX50 B14 (103)
R151 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R152 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R153 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R174 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ)
R181 7030003700 S.RESISTOR ERJ3GEYJ 154 V (150 kΩ)
R182 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R183 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R184 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R186 7030003700 S.RESISTOR ERJ3GEYJ 154 V (150 kΩ)
R187 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R188 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R192 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ)
R193 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R194 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ)
R208 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R209 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R211 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R212 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R218 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R219 7030000210 S.RESISTOR MCR10EZHJ 39 Ω (390)
R220 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ)
R221 7030000520 S.RESISTOR MCR10EZHJ 15 kΩ
R223 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R224 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R225 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R226 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R228 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R229 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R230 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
[USA/-1] only
R231 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
[USA/-1] only
R232 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R233 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R234 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R235 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
REF ORDER
DESCRIPTION
NO. NO.
[MAIN UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[MAIN UNIT]

Icom IC-A110 Specifications

General

Frequency Range	118.000–136.975 MHz
Channel Spacing	25 kHz / 8.33 kHz
Power Supply Requirement	13.75 V DC ±15%
Output Power	36W (PEP), 9W (carrier)
Dimensions	150 × 50 × 180 mm (W × H × D)
Modulation	AM
Operating Temperature Range	-20°C to +55°C –4°F to +131°F
