Icom IC-A110 Service Manual

5 - 4
S.=Surface mount
R236 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R237 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R238 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R239 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R240 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R241 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R242 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R243 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R251 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R256 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ)
R267 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R273 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R280 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R281 7030003750 S.RESISTOR ERJ3GEYJ 394 V (390 kΩ)
R288 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R289 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R295 7030003350 S.RESISTOR ERJ3GEYJ 181 V (180 Ω)
R297 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R301 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R321 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R322 7030004040 S.RESISTOR ERJ3GEYJ 4R7 V (4.7 Ω)
R323 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R325 7030003370 S.RESISTOR ERJ3GEYJ 271 V (270 Ω)
R327 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R328 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ)
R329 7030003690 S.RESISTOR ERJ3GEYJ 124 V (120 kΩ)
R330 7510001000 S.THERMISTOR TBPS1R154K475H5Q
R331 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R332 7030003690 S.RESISTOR ERJ3GEYJ 124 V (120 kΩ)
R333 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R334 7030003770 S.RESISTOR ERJ3GEYJ 564 V (560 kΩ)
R335 7030004050 S.RESISTOR ERJ3GEYJ 1R0 V (1 Ω)
R336 4610001530 S.TRIMMER EVM-1XSX50 B13 (102)
R338 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R340 7030003410 S.RESISTOR ERJ3GEYJ 561 V (560 Ω)
R342 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R355 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R356 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ)
R357 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R358 7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ)
R359 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R361 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R362 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ)
R363 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R364 7030003810 S.RESISTOR ERJ3GEYJ 125 V (1.2 MΩ)
R365 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R366 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R367 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R368 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R369 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R370 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R371 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R372 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R373 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R374 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R375 7030003530 S.RESISTOR ERJ3GEYJ 562 V (5.6 kΩ)
R376 7030003770 S.RESISTOR ERJ3GEYJ 564 V (560 kΩ)
R377 7030003240 S.RESISTOR ERJ3GEYJ 220 V (22 Ω)
R378 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R379 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R380 7030006060 S.RESISTOR ERJ12YJ100U (10 Ω)
R381 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R383 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R386 7030003700 S.RESISTOR ERJ3GEYJ 154 V (150 kΩ)
R387 7030003700 S.RESISTOR ERJ3GEYJ 154 V (150 kΩ)
R388 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R389 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ)
R390 7030003410 S.RESISTOR ERJ3GEYJ 561 V (560 Ω)
R391 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R392 7310003660 S.TRIMMER EVM-1XSX50 B55 (504)
R393 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R394 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R395 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ)
R396 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R397 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R398 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R399 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R400 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R401 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R403 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R404 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R405 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ)
R406 7030003470 S.RESISTOR ERJ3GEYJ 182 V (1.8 kΩ)
R407 7030003700 S.RESISTOR ERJ3GEYJ 154 V (150 kΩ)
R408 7030003700 S.RESISTOR ERJ3GEYJ 154 V (150 kΩ)
R409 7030004890 S.RESISTOR ERJ3GEYF 434 V (430 kΩ)
R410 7030004860 S.RESISTOR ERJ3GEYF 184 V (180 kΩ)
R411 7030005260 S.RESISTOR ERJ3GEYF 394 V (390 kΩ)
R412 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R413 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ)
R414 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ)
R415 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R417 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R418 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R419 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R420 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R422 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R423 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R424 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R425 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R426 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R427 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R428 7030003380 S.RESISTOR ERJ3GEYJ 331 V (330 Ω)
R429 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R430 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ)
R431 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R432 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ)
R433 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R434 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R435 7030000410 S.RESISTOR MCR10EZHJ 1.8 kΩ
R436 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R437 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R438 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
[USA/-1] only
R439 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
[USA/-1] only
R440 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R441 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R442 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R443 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R444 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R445 7030003430 S.RESISTOR ERJ3GEYJ 821 V (820 Ω)
R446 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ)
R447 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ)
R448 7030003420 S.RESISTOR ERJ3GEYJ 681 V (680 Ω)
R449 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
R450 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R451 7030004040 S.RESISTOR ERJ3GEYJ 4R7 V (4.7 Ω)
R452 7030003530 S.RESISTOR ERJ3GEYJ 562 V (5.6 kΩ)
R453 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R454 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R455 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ)
R456 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R457 7030003700 S.RESISTOR ERJ3GEYJ 154 V (150 kΩ)
R458 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R459 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R460 7030004040 S.RESISTOR ERJ3GEYJ 4R7 V (4.7 Ω)
R461 7030003530 S.RESISTOR ERJ3GEYJ 562 V (5.6 kΩ)
R462 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R463 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R464 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R465 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R466 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R467 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R468 7030006190 S.RESISTOR ERJ12YJ2R2U (2.2 Ω)
R470 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R471 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R472 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R473 7030001160 S.RESISTOR MCR50JZHJ 180 Ω (181)
R474 7030004040 S.RESISTOR ERJ3GEYJ 4R7 V (4.7 Ω)
R475 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R476 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R478 7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ)
R479 7510001100 S.THERMISTOR NTCCM1608 4LH 104KC
R484 7030003510 S.RESISTOR ERJ3GEYJ 392 V (3.9 kΩ)
C1 4030011210 S.CERAMIC GRM42-6 CH 330J 500PT
C2 4030011070 S.CERAMIC GRM42-6 CH 050C 500PT
C3 4030011230 S.CERAMIC GRM42-6 CH 390J 500PT
C4 4030011030 S.CERAMIC GRM42-6 CK 1R5C 500PT
C5 4030011180 S.CERAMIC GRM42-6 CH 220J 500PT
C6 4030011260 S.CERAMIC GRM42-6 W5R 102K 500PT
C7 4030011180 S.CERAMIC GRM42-6 CH 220J 500PT
REF ORDER
DESCRIPTION
NO. NO.
[MAIN UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[MAIN UNIT]

Icom IC-A110 Specifications

General

Frequency Range	118.000–136.975 MHz
Channel Spacing	25 kHz / 8.33 kHz
Power Supply Requirement	13.75 V DC ±15%
Output Power	36W (PEP), 9W (carrier)
Dimensions	150 × 50 × 180 mm (W × H × D)
Modulation	AM
Operating Temperature Range	-20°C to +55°C –4°F to +131°F
