Icom IC-A110 Service Manual

[MAIN UNIT][MAIN UNIT]
S.=Surface mount
C288 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C289 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C290 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C292 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C293 4030010760 S.CERAMIC C1608 CH 1H 331J-T-A
C295 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C298 4510006660 S.ELECTROLYTIC ECEV1HA330P
C299 4030006890 S.CERAMIC C1608 JF 1H 103Z-T-A
C300 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C301 4510004540 S.ELECTROLYTIC ECEV0JA470SR
C308 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C309 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C312 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C313 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C314 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C315 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C316 4030011180 S.CERAMIC GRM42-6 CH 220J 500PT
C317 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C318 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C319 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
[USA/-1] only
C320 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C321 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C322 4510005630
S.ELECTROLYTIC ECEV1EA330SP
C323 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C324 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C325 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C326 4550006560 S.TANTALUM ECST1CY225R
C327 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C328 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C329 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C330 4030011110 S.CERAMIC GRM42-6 CH 090D 500PT
C331 4030011160 S.CERAMIC GRM42-6 CH 150J 500PT
C332 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
[USA/-1] only
C333 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C337 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C338 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C339 4030008470 S.CERAMIC C1608 JB 1H 272K-T-A
C340 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C341 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C342 4030006950 S.CERAMIC C1608 CH 1H 040C-T-A
C343 4510006220 S.ELECTROLYTIC ECEV1CA101UP
C344 4030009500 S.CERAMIC C1608 CH 1H 0R5B-T-A
C346 4030006960 S.CERAMIC C1608 CH 1H 050C-T-A
[USA/-1] only
C347 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C348 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C349 4030008650 S.CERAMIC C1608 JB 1H 332K-T-A
C353 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C354 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C358 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C359 4030007050 S.CERAMIC C1608 CH 1H 220J-T-A
C360 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C361 4030006950 S.CERAMIC C1608 CH 1H 040C-T-A
[USA/-1] only
C362 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C366 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C374 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C378 4030006870 S.CERAMIC C1608 JB 1H 222K-T-A
C379 4550006300 S.TANTALUM ECST1AY475R
C380 4550006150 S.TANTALUM ECST1CY105R
C381 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C382 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C383 4550006390 S.TANTALUM TEMSVA 1C 335M-8L
C384 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C385 4030008900 S.CERAMIC C1608 JB 1C 333K-T-A
C387 4510006670 S.ELECTROLYTIC ECEV1CA471P
C388 4510005750 S.ELECTROLYTIC ECEV1EA220SP
C389 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C390 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C391 4030009500 S.CERAMIC C1608 CH 1H 0R5B-T-A
C392 4030007020 S.CERAMIC C1608 CH 1H 120J-T-A
[USA/-1] only
C395 4030006950 S.CERAMIC C1608 CH 1H 040C-T-A
C396 4030012610 S.CERAMIC C2012 JB 1C 474K-T-A
C397 4030012610 S.CERAMIC C2012 JB 1C 474K-T-A
C398 4030009000 S.CERAMIC C2012 JB 1C 224K-T-A
C399 4510006220
S.ELECTROLYTIC ECEV1CA101UP
C400 4510004640 S.ELECTROLYTIC ECEV1CA470SP
C401 4510004640 S.ELECTROLYTIC ECEV1CA470SP
C402 4030008980 S.CERAMIC C2012 JB 1C 154K-T-A
C403 4030012600 S.CERAMIC C2012 JB 1A 105M-T-A
C404 4030012610 S.CERAMIC C2012 JB 1C 474K-T-A
C405 4030009350 S.CERAMIC C1608 CH 1H 3R5B-T-A
C406 4030006960 S.CERAMIC C1608 CH 1H 050C-T-A
C407 4030009530 S.CERAMIC C1608 CH 1H 030B-T-A
C409 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C410 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C413 4550006160 S.TANTALUM ECST1CY155R
C415 4030007060 S.CERAMIC C1608 CH 1H 270J-T-A
C416 4030007030 S.CERAMIC C1608 CH 1H 150J-T-A
C417 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C418 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C419 4030001170 S.CERAMIC GRM42-6 B 102K 50PT
C420 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C421 4030007050 S.CERAMIC C1608 CH 1H 220J-T-A
C422 4030007070 S.CERAMIC C1608 CH 1H 330J-T-A
C423 4030006970 S.CERAMIC C1608 CH 1H 060D-T-A
C424 4030007100 S.CERAMIC C1608 CH 1H 560J-T-A
C425 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C426 4030009990 S.CERAMIC C1608 CH 1H 200J-T-A
C427 4030007080 S.CERAMIC C1608 CH 1H 390J-T-A
C428 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C429 4030009550 S.CERAMIC C1608 CH 1H 2R5B-T-A
C430 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C431 4510006220
S.ELECTROLYTIC ECEV1CA101UP
C433 4510004650
S.ELECTROLYTIC ECEV1EA4R7SR
C434 4030006960 S.CERAMIC C1608 CH 1H 050C-T-A
C436 4510004630
S.ELECTROLYTIC ECEV1CA100SR
C437 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C438 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C439 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C441 4510006220 S.ELECTROLYTIC ECEV1CA101UP
C442 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C443 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C444 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C445 4510006220 S.ELECTROLYTIC ECEV1CA101UP
C446 4030010760 S.CERAMIC C1608 CH 1H 331J-T-A
C447 4030012600 S.CERAMIC C2012 JB 1A 105M-T-A
C448 4510006220 S.ELECTROLYTIC ECEV1CA101UP
C449 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C450 4030010040 S.CERAMIC C1608 JB 1H 561K-T-A
C452 4510007230 ELECTROLYTIC 50 YXG 1000UF
C453 4510005870 S.ELECTROLYTIC ECEV1HA3R3SR
C454 4550003210 S.TANTALUM TEMSVD2 1D 226M-12R
C455 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C456 4030017070 S.CERAMIC GRM42-2 R 474K 50PT
C457 4030017070 S.CERAMIC GRM42-2 R 474K 50PT
C462 4030017070 S.CERAMIC GRM42-2 R 474K 50PT
C463 4030017070 S.CERAMIC GRM42-2 R 474K 50PT
C468 4030017070 S.CERAMIC GRM42-2 R 474K 50PT
C472 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C500 4030009650 S.CERAMIC C1608 CH 1H 240J-T-A
C501 4030007050 S.CERAMIC C1608 CH 1H 220J-T-A
C502 4030007110 S.CERAMIC C1608 CH 1H 680J-T-A
C503 4030006980 S.CERAMIC C1608 CH 1H 070D-T-A
C504 4030007150 S.CERAMIC C1608 CH 1H 151J-T-A
C505 4510007320 ELECTROLYTIC 50 YXG 470M
C506 4510004420 S.ELECTROLYTIC ECEV0JV330SR
C507 4030008960 S.CERAMIC C2012 JB 1C 104K-T-A
C508 4030010020 S.CERAMIC C1608 JB 1H 122K-T-A
C509 4030010020 S.CERAMIC C1608 JB 1H 122K-T-A
C512 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C513 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C514 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C515 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C516 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C517 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C518 4030016990 S.CERAMIC GRM42-2 R 105K 50PT
C519 4030011250 S.CERAMIC GRM42-6 W5R 471K 500PT
C520 4030011280 S.CERAMIC C1608 CH 1H 271J-T-A
C521 4510004650
S.ELECTROLYTIC ECEV1EA4R7SR
C522 4030007050 S.CERAMIC C1608 CH 1H 220J-T-A
C523 4030006870 S.CERAMIC C1608 JB 1H 222K-T-A
C524 4030008550 S.CERAMIC C2012 JF 1H 473Z-T-A
C525 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C529 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C530 4030008770 S.CERAMIC C1608 JB 1H 562K-T-A
C531 4510007390 ELECTROLYTIC 50 YK 220M
C533 4030009530 S.CERAMIC C1608 CH 1H 030B-T-A
C535 4510005520 ELECTROLYTIC 50 MV 330 HC
C536 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C537 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
5 - 6
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.

Icom IC-A110 Specifications

General

Frequency Range	118.000–136.975 MHz
Channel Spacing	25 kHz / 8.33 kHz
Power Supply Requirement	13.75 V DC ±15%
Output Power	36W (PEP), 9W (carrier)
Dimensions	150 × 50 × 180 mm (W × H × D)
Modulation	AM
Operating Temperature Range	-20°C to +55°C –4°F to +131°F
