Icom IC-A110 Service Manual

[MAIN UNIT]
S.=Surface mount
C538 4030007140 S.CERAMIC C1608 CH 1H 121J-T-A
C539 4030007010 S.CERAMIC C1608 CH 1H 100D-T-A
C540 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C541 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C542 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C543 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C544 4030007150 S.CERAMIC C1608 CH 1H 151J-T-A
C545 4030007020 S.CERAMIC C1608 CH 1H 120J-T-A
C546 4030007000 S.CERAMIC C1608 CH 1H 090D-T-A
C547 4030009650 S.CERAMIC C1608 CH 1H 240J-T-A
C548 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C549 4030016990 S.CERAMIC GRM42-2 R 105K 50PT
C550 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C551 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C552 4030009530 S.CERAMIC C1608 CH 1H 030B-T-A
C553 4550006540 S.TANTALUM ECST1CY475R
C554 4030011250 S.CERAMIC GRM42-6 W5R 471K 500PT
C555 4030009650 S.CERAMIC C1608 CH 1H 240J-T-A
C556 4030009650 S.CERAMIC C1608 CH 1H 240J-T-A
C557 4030004750 S.CERAMIC C2012 JB 1H 103K-T-A
C558 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C575 4030017070 S.CERAMIC GRM42-2 R 474K 50PT
J5 6510020510
S.CONNECTOR FH12-40S-0.5SV
J6 6510009400 CONNECTOR B7B-ZR
J7 6450000140 CONNECTOR HSJ0807-01-010
T1 5920000750 TRANSFORMER ST-82 (P)
W1 8900009210 CABLE OPC-905
W2 7120000470 JUMPER ERDS2T0
W3 7120000470 JUMPER ERDS2T0
W4 7120000470 JUMPER ERDS2T0
W15 7030003860 S.JUMPER ERJ3GE JPW V
W25 7030003860 S.JUMPER ERJ3GE JPW V [GEN/-1] only
W27 7030003860 S.JUMPER ERJ3GE JPW V
W28 7030003860 S.JUMPER ERJ3GE JPW V [GEN/-1] only
W29 7030007150 S.JUMPER MCR50JZHJ JPW (000)
W32 7030003860 S.JUMPER ERJ3GE JPW V
W33 7030003860 S.JUMPER ERJ3GE JPW V
W34 7030003970 S.JUMPER MCR18EZHJ JPW (000)
W35 7030007150 S.JUMPER MCR50JZHJ JPW (000)
W38 7030000010 S.JUMPER MCR10EZHJ JPW (000)
W39 7030003970 S.JUMPER MCR18EZHJ JPW (000)
W40 7030003970 S.JUMPER MCR18EZHJ JPW (000)
W41 7030003860 S.JUMPER ERJ3GE JPW V
W42 7030003860 S.JUMPER ERJ3GE JPW V
W43 7030003860 S.JUMPER ERJ3GE JPW V
W44 7030003860 S.JUMPER ERJ3GE JPW V
W46 7030003860 S.JUMPER ERJ3GE JPW V
W47 7030000010 S.JUMPER MCR10EZHJ JPW (000)
W48 7030003970 S.JUMPER MCR18EZHJ JPW (000)
W49 7030007150 S.JUMPER MCR50JZHJ JPW (000)
W51 7030003860 S.JUMPER ERJ3GE JPW V
W71 7030003860 S.JUMPER ERJ3GE JPW V
WS1 8970023550 AX2270 J LEAD SET (2) /MA
EP1 0910051545 PCB B 5318E
EP2 6910013270 BEAD 2643-625002
EP3 9040901901 TUBE IRRAX 0.7 (d) L=12 mm
EP4 9040901901 TUBE IRRAX 0.7 (d) L=12 mm
5 - 7
REF ORDER
DESCRIPTION
NO. NO.

Icom IC-A110 Specifications

General

Frequency Range	118.000–136.975 MHz
Channel Spacing	25 kHz / 8.33 kHz
Power Supply Requirement	13.75 V DC ±15%
Output Power	36W (PEP), 9W (carrier)
Dimensions	150 × 50 × 180 mm (W × H × D)
Modulation	AM
Operating Temperature Range	-20°C to +55°C –4°F to +131°F
