Icom IC-A220T

26
7
INFORMATION
06
07
• Channel spacing: 25 kHz (Actual frequency is displayed.)
Operating Frequency
(MHz)
Channel spacing
(kHz)
Channel ID
(Displayed Frequency)
118.0000 25 118.000
118.0250 25 118.025
118.0500 25 118.050
118.0750 25 118.075
118.1000 25 118.100
• Channel spacing: 8.33 kHz
Operating Frequency
(MHz)
Channel spacing
(kHz)
Channel ID
(Displayed Frequency)
118.0000 8.33 118.005
118.0083 8.33 118.010
118.0167 8.33 118.015
118.0250 8.33 118.030
118.0333 8.33 118.035
118.0417 8.33 118.040
118.0500 8.33 118.055
118.0583 8.33 118.060
118.0667 8.33 118.065
118.0750 8.33 118.080
118.0833 8.33 118.085
118.0917 8.33 118.090
118.1000 8.33 118.105
These tables show just the display example between 118.0000
MHz and 118.1000 MHz. Not show all frequencies in the band are
shown.
■ TSO Deviation list
TSO/ETSO Deviation
TSO-C128a
1. Icom was granted a deviation from the TSO
to mark the exterior of the unit with the serial
number instead of the date of manufacture.
2. Icom was granted a deviation from the TSO
to use RTCA/DO-160G instead of the earlier
version as the standard for environmental
conditions and tests.
3. Icom was granted a deviation from the TSO
to use RTCA/DO-178C instead of the earlier
version to demonstrate compliance for the
verication and validation of computer software.
TSO-C169a
1. Icom was granted a deviation from the TSO
to mark the exterior of the unit with the serial
number instead of the date of manufacture.
2. Icom was granted a deviation from the TSO
to use RTCA/DO- 160G instead of the earlier
version as the standard for environmental
conditions and tests.
3. Icom was granted a deviation from the TSO
to use RTCA/DO-178C instead of the earlier
version to demonstrate compliance for the
verication and validation of computer software.
• FCC Grant of Equipment Authorization
Model FCC ID IC ID
IC-A220 AFJ297410 202D-297410
■ VFO channel ID list
