Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=
Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
(Amended page)
REF
NO.
PART
NO.
DESCRIPTION M
.
H/V
LOCATION
REF
NO.
PART
NO.
DESCRIPTION M
.
H/V
LOCATION
March 2019
[LOGIC UNIT] (for #11, #12, #21, #22, and #31) [LOGIC UNIT] (for #11, #12, #21, #22, and #31)
5-2a
R875 7030016190 S.RES RMC1/16S-273JTH (27 k) [#11] B 40.8/4.3
7030016190 S.RES RMC1/16S-273JTH (27 k) [#12]
R876 7030016160 S.RES RMC1/16S-820JTH (82) T 33.0/35.2
R878 7030015920 S.RES RMC1/16S-221JTH (220) T 13.2/14.6
R879 7030016020 S.RES RMC1/16S-104JTH (100 k) [#11] B 41.3/5.5
7030016020 S.RES RMC1/16S-104JTH (100 k) [#12]
R881 7030016110 S.RES RMC1/16S-473JTH (47 k) B 27.9/18.5
R882 7030015970 S.RES RMC1/16S-103JTH (10 k) B 29.6/16.9
R883 7030016380 S.RES RMC1/16S-183JTH (18 k) B 30.9/17.3
R884 7030016360 S.RES RMC1/16S-123JTH (12 k) B 30.9/14.1
R885 7030015970 S.RES RMC1/16S-103JTH (10 k) B 39.2/28.6
R886 7030016380 S.RES RMC1/16S-183JTH (18 k) B 38.0/28.1
R887 7030016560 S.RES RMC1/16SJPTH B 38.0/30.2
R888 7030015970 S.RES RMC1/16S-103JTH (10 k) B 42.8/31.9
R901 7030014460 S.RES MCR006YZPJ 101 (100) B 30.3/43.5
R902 7030014460 S.RES MCR006YZPJ 101 (100) B 23.5/43.3
R903 7030014460 S.RES MCR006YZPJ 101 (100) B 30.2/61.4
R906 7030014460 S.RES MCR006YZPJ 101 (100) B 23.5/62.3
R907 7030014460 S.RES MCR006YZPJ 101 (100) B 39.2/50.1
R908 7030016060 S.RES RMC1/16S-105JTH (1 M) B 37.1/52.9
R909 7030016150 S.RES RMC1/16S-100JTH (10) B 35.8/53.0
R910 7030016360 S.RES RMC1/16S-123JTH (12 k) B 39.3/57.6
R911 7030016090 S.RES RMC1/16S-223JTH (22 k) B 39.3/56.7
R912 7030016360 S.RES RMC1/16S-123JTH (12 k) B 42.0/58.4
R913 7030015960 S.RES RMC1/16S-472JTH (4.7 k) B 26.0/67.7
R914 7030016020 S.RES RMC1/16S-104JTH (100 k) B 25.0/68.2
R917 7030016020 S.RES RMC1/16S-104JTH (100 k) T 24.1/21.2
R920 7030016020 S.RES RMC1/16S-104JTH (100 k) T 23.7/20.0
R925 7030015970 S.RES RMC1/16S-103JTH (10 k) B 44.4/52.9
R926 7030016560 S.RES RMC1/16SJPTH [#11] B 9.9/16.2
7030016560 S.RES RMC1/16SJPTH [#12]
R927 7030016560 S.RES RMC1/16SJPTH [#11] B 20.7/15.3
7030016560 S.RES RMC1/16SJPTH [#12]
R928 7030016560 S.RES RMC1/16SJPTH [#11] B 21.3/26.2
7030016560 S.RES RMC1/16SJPTH [#12]
R929 7030014460 S.RES MCR006YZPJ 101 (100) [#11] B 24.6/50.9
7030014460 S.RES MCR006YZPJ 101 (100) [#12]
R930 7030014460 S.RES MCR006YZPJ 101 (100) [#11] B 24.0/51.9
7030014460 S.RES MCR006YZPJ 101 (100) [#12]
R931 7030016020 S.RES RMC1/16S-104JTH (100 k) B 23.8/49.3
R932 7030016020 S.RES RMC1/16S-104JTH (100 k) B 23.4/50.5
R933 7030015970 S.RES RMC1/16S-103JTH (10 k) B 22.1/69.6
R934 7030015960 S.RES RMC1/16S-472JTH (4.7 k) B 26.0/69.8
R935 7030015960 S.RES RMC1/16S-472JTH (4.7 k) B 35.3/54.5
R937 7030016560 S.RES RMC1/16SJPTH B 30.3/27.6
R940 7030016020 S.RES RMC1/16S-104JTH (100 k) B 28.4/61.3
R943 7030016020 S.RES RMC1/16S-104JTH (100 k) B 35.6/44.1
R944 7030016020 S.RES RMC1/16S-104JTH (100 k) B 36.5/47.0
R945 7030016020 S.RES RMC1/16S-104JTH (100 k) [#11] B 19.2/86.6
7030016020 S.RES RMC1/16S-104JTH (100 k) [#12]
R946 7030016020 S.RES RMC1/16S-104JTH (100 k) [#11] B 20.3/79.6
7030016020 S.RES RMC1/16S-104JTH (100 k) [#12]
R947 7030016020 S.RES RMC1/16S-104JTH (100 k) [#11] T 15.9/9.8
7030016020 S.RES RMC1/16S-104JTH (100 k) [#12]
R949 7030016020 S.RES RMC1/16S-104JTH (100 k) T 21.1/21.2
R952 7030016020 S.RES RMC1/16S-104JTH (100 k) T 17.7/26.7
R962 7030016020 S.RES RMC1/16S-104JTH (100 k) [#11] B 39.1/7.1
7030016020 S.RES RMC1/16S-104JTH (100 k) [#12]
R963 7030016210 S.RES RMC1/16S-121JTH (120) T 13.2/16.2
R964 7030014400 S.RES MCR006YZPJ 100 (10) B 28.6/60.4
R965 7030014400 S.RES MCR006YZPJ 100 (10) B 30.9/59.6
R966 7030014400 S.RES MCR006YZPJ 100 (10) B 43.4/58.4
R967 7030014400 S.RES MCR006YZPJ 100 (10) B 34.7/47.9
R968 7030014400 S.RES MCR006YZPJ 100 (10) B 37.3/49.7
R969 7030014400 S.RES MCR006YZPJ 100 (10) B 37.3/51.8
R970 7030014400 S.RES MCR006YZPJ 100 (10) B 26.0/66.3
R971 7030014400 S.RES MCR006YZPJ 100 (10) B 25.0/66.8
R972 7030014400 S.RES MCR006YZPJ 100 (10) B 34.6/44.5
R973 7030014400 S.RES MCR006YZPJ 100 (10) B 35.6/47.1
R974 7030014400 S.RES MCR006YZPJ 100 (10) B 23.5/47.8
R975 7030014400 S.RES MCR006YZPJ 100 (10) B 29.3/47.9
R976 7030014400 S.RES MCR006YZPJ 100 (10) B 28.7/47.9
R977 7030014400 S.RES MCR006YZPJ 100 (10) B 27.5/47.9
R978 7030014400 S.RES MCR006YZPJ 100 (10) B 26.0/50.9
R979 7030014400 S.RES MCR006YZPJ 100 (10) B 33.0/44.0
R980 7030014400 S.RES MCR006YZPJ 100 (10) B 39.4/51.5
R981 7030014400 S.RES MCR006YZPJ 100 (10) B 26.0/48.8
R982 7030014400 S.RES MCR006YZPJ 100 (10) B 28.1/47.9
R983 7030014400 S.RES MCR006YZPJ 100 (10) B 26.3/47.9
R984 7030014400 S.RES MCR006YZPJ 100 (10) B 24.1/55.7
R985 7030014400 S.RES MCR006YZPJ 100 (10) B 37.3/50.6
R986 7030014400 S.RES MCR006YZPJ 100 (10) B 37.3/49.1
R987 7030014400 S.RES MCR006YZPJ 100 (10) B 33.1/47.9
R988 7030014400 S.RES MCR006YZPJ 100 (10) B 37.3/48.5
R989 7030014400 S.RES MCR006YZPJ 100 (10) B 32.3/47.9
R990 7030014400 S.RES MCR006YZPJ 100 (10) B 26.0/51.8
R991 7030014400 S.RES MCR006YZPJ 100 (10) B 26.0/53.0
R992 7030014400 S.RES MCR006YZPJ 100 (10) B 26.0/52.4
R993 7030014400 S.RES MCR006YZPJ 100 (10) B 33.5/46.2
R994 7030014400 S.RES MCR006YZPJ 100 (10) B 28.9/57.7
R995 7030014400 S.RES MCR006YZPJ 100 (10) B 23.7/58.8
R996 7030014400 S.RES MCR006YZPJ 100 (10) B 29.0/44.3
R997 7030014400 S.RES MCR006YZPJ 100 (10) B 28.4/43.5
R998 7030014400 S.RES MCR006YZPJ 100 (10) B 34.5/46.2
R999 7030014380 S.RES MCR006YZPJ 103 (10 k) B 31.3/42.9
R1000 7030014400 S.RES MCR006YZPJ 100 (10) B 26.0/42.5
R1001 7030014400 S.RES MCR006YZPJ 100 (10) B 26.7/42.5
R1002 7030014400 S.RES MCR006YZPJ 100 (10) B 26.9/47.9
R1003 7030014400 S.RES MCR006YZPJ 100 (10) B 26.0/50.0
R1004 7030014400 S.RES MCR006YZPJ 100 (10) B 37.3/47.9
R1005 7030014400 S.RES MCR006YZPJ 100 (10) B 32.7/46.2
R1006 7030014380 S.RES MCR006YZPJ 103 (10 k) B 31.5/47.9
R1007 7030014400 S.RES MCR006YZPJ 100 (10) B 24.1/47.2
R1008 7030014400 S.RES MCR006YZPJ 100 (10) B 26.0/49.4
R1009 7030014400 S.RES MCR006YZPJ 100 (10) B 35.1/46.2
R1010 7030014400 S.RES MCR006YZPJ 100 (10) B 33.9/47.9
R1011 7030014400 S.RES MCR006YZPJ 100 (10) B 31.9/46.2
R1012 7030014400 S.RES MCR006YZPJ 100 (10) B 35.5/57.6
R1013 7030014400 S.RES MCR006YZPJ 100 (10) B 34.7/57.9
R1014 7030014400 S.RES MCR006YZPJ 100 (10) B 33.8/57.9
R1015 7030014400 S.RES MCR006YZPJ 100 (10) B 32.2/57.7
R1016 7030014400 S.RES MCR006YZPJ 100 (10) B 31.6/57.7
R1017 7030014400 S.RES MCR006YZPJ 100 (10) B 31.0/57.7
R1018 7030014400 S.RES MCR006YZPJ 100 (10) B 29.5/57.7
R1019 7030014400 S.RES MCR006YZPJ 100 (10) B 24.1/58.1
R1020 7030014400 S.RES MCR006YZPJ 100 (10) B 24.1/57.5
R1021 7030014400 S.RES MCR006YZPJ 100 (10) B 35.0/59.5
R1022 7030014400 S.RES MCR006YZPJ 100 (10) B 32.2/59.5
R1023 7030014400 S.RES MCR006YZPJ 100 (10) B 31.6/59.6
R1024 7030014400 S.RES MCR006YZPJ 100 (10) B 30.1/58.8
R1025 7030014400 S.RES MCR006YZPJ 100 (10) B 28.0/57.3
R1026 7030014400 S.RES MCR006YZPJ 100 (10) B 24.1/56.9
R1027 7030014400 S.RES MCR006YZPJ 100 (10) B 37.7/58.5
R1028 7030014400 S.RES MCR006YZPJ 100 (10) B 34.3/59.5
R1029 7030014400 S.RES MCR006YZPJ 100 (10) B 33.2/60.1
R1030 7030014400 S.RES MCR006YZPJ 100 (10) B 28.5/62.4
R1031 7030014400 S.RES MCR006YZPJ 100 (10) B 44.3/55.4
R1032 7030014400 S.RES MCR006YZPJ 100 (10) B 36.8/57.8
R1033 7030014400 S.RES MCR006YZPJ 100 (10) B 34.3/61.9
R1034 7030014400 S.RES MCR006YZPJ 100 (10) B 31.6/62.0
R1035 7030014400 S.RES MCR006YZPJ 100 (10) B 30.4/57.7
R1036 7030014400 S.RES MCR006YZPJ 100 (10) B 20.6/63.1
R1037 7030014390 S.RES MCR006YZPJ 102 (1 k) B 24.1/56.3
R1038 7030014400 S.RES MCR006YZPJ 100 (10) B 24.1/55.1
R1039 7030014390 S.RES MCR006YZPJ 102 (1 k) B 26.0/54.7
R1040 7030014400 S.RES MCR006YZPJ 100 (10) B 44.9/55.4
R1041 7030014400 S.RES MCR006YZPJ 100 (10) B 24.1/54.3
R1042 7030014400 S.RES MCR006YZPJ 100 (10) B 26.0/53.9
R1043 7030014400 S.RES MCR006YZPJ 100 (10) B 24.1/53.5
R1044 7030014400 S.RES MCR006YZPJ 100 (10) B 20.7/68.3
R1045 7030014400 S.RES MCR006YZPJ 100 (10) B 43.9/52.0
R1046 7030014400 S.RES MCR006YZPJ 100 (10) B 23.5/61.7
R1047 7030014400 S.RES MCR006YZPJ 100 (10) B 44.0/51.4
R1050 7030014400 S.RES MCR006YZPJ 100 (10) B 24.1/46.6
R1053 7030015970 S.RES RMC1/16S-103JTH (10 k) T 14.7/11.9
R1054 7030015970 S.RES RMC1/16S-103JTH (10 k) T 15.0/18.6
R1055 7030015970 S.RES RMC1/16S-103JTH (10 k) T 15.0/10.2
R1056 7030015970 S.RES RMC1/16S-103JTH (10 k) T 14.6/17.0
R1057 7030016150 S.RES RMC1/16S-100JTH (10) B 41.0/40.6
R1059 7030016560 S.RES RMC1/16SJPTH [#11] B 29.7/96.2
7030016560 S.RES RMC1/16SJPTH [#12]
R1060 7030016560 S.RES RMC1/16SJPTH [#11] T 16.6/13.6
7030016560 S.RES RMC1/16SJPTH [#12]
R1061 7210003820 VAR TP76D1190E20-20.5F
-10KB-3699
R1062 7030016560 S.RES RMC1/16SJPTH B 40.3/89.6
R1063 7030015970 S.RES RMC1/16S-103JTH (10 k) [#11] T 21.8/15.1
7030015970 S.RES RMC1/16S-103JTH (10 k) [#12]
R1064 7030016560 S.RES RMC1/16SJPTH T 13.7/4.9
R1065 7030016560 S.RES RMC1/16SJPTH T 13.7/7.7
R1066 7030016560 S.RES RMC1/16SJPTH T 11.3/3.6
R1067 7030016560 S.RES RMC1/16SJPTH T 12.6/10.5
R1068 7030016560 S.RES RMC1/16SJPTH T 10.3/3.6
R1069 7030016560 S.RES RMC1/16SJPTH T 5.6/21.3
R1070 7030016560 S.RES RMC1/16SJPTH T 9.4/4.5
R1071 7030016560 S.RES RMC1/16SJPTH T 5.4/17.4
R1072 7030016560 S.RES RMC1/16SJPTH T 8.2/3.9
R1073 7030016560 S.RES RMC1/16SJPTH T 13.7/6.7
R1074 7030016020 S.RES RMC1/16S-104JTH (100 k) B 28.5/46.5
R1075 7030014400 S.RES MCR006YZPJ 100 (10) B 37.3/51.2
R1076 7030014400 S.RES MCR006YZPJ 100 (10) B 30.9/47.9
R1077 7030016560 S.RES RMC1/16SJPTH [#11] T 32.4/20.7
7030016560 S.RES RMC1/16SJPTH [#12]
R1078 7030016090 S.RES RMC1/16S-223JTH (22 k) B 30.9/16.4
R1079 7030016290 S.RES RMC1/16S-222JTH (2.2 k) B 38.0/29.0
R1081 7030016060 S.RES RMC1/16S-105JTH (1 M) B 33.5/63.6
R1082 7030016050 S.RES RMC1/16S-102JTH (1 k) B 36.6/42.0
R1083 7030016110 S.RES RMC1/16S-473JTH (47 k) B 23.2/46.4
R1084 7410001340 S.ARR EXB28V473JX B 25.3/45.0
R1085 7030014380 S.RES MCR006YZPJ 103 (10 k) [#21] B 45.2/50.3
7030014380 S.RES MCR006YZPJ 103 (10 k) [#22]
7030014380 S.RES MCR006YZPJ 103 (10 k) [#31]
R1086 7030014380 S.RES MCR006YZPJ 103 (10 k) [#21] B 45.2/51.4
7030014380 S.RES MCR006YZPJ 103 (10 k) [#22]
7030014380 S.RES MCR006YZPJ 103 (10 k) [#31]
R1087 7030016320 S.RES RMC1/16S-225JTH (2.2 M) B 33.2/64.8
R1088 7030016240 S.RES RMC1/16S-684JTH (680 k) B 31.9/64.1
R1089 7030016110 S.RES RMC1/16S-473JTH (47 k) B 25.2/63.3
R1090 7030016000 S.RES RMC1/16S-823JTH (82 k) [#11] B 5.4/18.4
7030016000 S.RES RMC1/16S-823JTH (82 k) [#12]
R1091 7030016040 S.RES RMC1/16S-224JTH (220 k) [#11] B 9.0/17.1
7030016040 S.RES RMC1/16S-224JTH (220 k) [#12]
R1092 7030016050 S.RES RMC1/16S-102JTH (1 k) [#11] B 42.4/8.0
7030016050 S.RES RMC1/16S-102JTH (1 k) [#12]
R1093 7030016410 S.RES RMC1/16S-561JTH (560) [#11] B 41.9/6.8
7030016410 S.RES RMC1/16S-561JTH (560) [#12]
R1097 7030016020 S.RES RMC1/16S-104JTH (100 k) B 28.9/15.6
R1098 7030016020 S.RES RMC1/16S-104JTH (100 k) B 40.5/30.0
C1 4030021240 S.CER C1005 JB 1C 105K-T [#11] T 23.6/17.9
4030021240 S.CER C1005 JB 1C 105K-T [#12]
C2 4030021240 S.CER C1005 JB 1C 105K-T [#11] T 24.1/16.5
4030021240 S.CER C1005 JB 1C 105K-T [#12]
The underlined parts have been updated from the previous version of the addendum, or the original page.
To Next Page
Loading...
