Icom IC-A25C Service Manual

Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
(Amended page)
REF
NO.
PART
NO.
DESCRIPTION M
.
H/V
LOCATION
REF
NO.
PART
NO.
DESCRIPTION M
.
H/V
LOCATION
March 2019
[LOGIC UNIT] (for #11, #12, #21, #22, and #31) [LOGIC UNIT] (for #11, #12, #21, #22, and #31)
5-3a
C5 4030021240 S.CER C1005 JB 1C 105K-T [#11] B 32.7/8.2
4030021240 S.CER C1005 JB 1C 105K-T [#12]
C6 4030021240 S.CER C1005 JB 1C 105K-T [#11] B 30.6/8.7
4030021240 S.CER C1005 JB 1C 105K-T [#12]
C7 4030021240 S.CER C1005 JB 1C 105K-T [#11] B 33.2/9.4
4030021240 S.CER C1005 JB 1C 105K-T [#12]
C8 4030023090 S.CER 0402B102K500CT B 24.7/70.4
C16 4030023090 S.CER 0402B102K500CT [#11] T 18.3/17.9
4030023090 S.CER 0402B102K500CT [#12]
C18 4030022640 S.CER 0402N101J500CT [#11] B 28.5/7.3
4030022640 S.CER 0402N101J500CT [#12]
C20 4030023090 S.CER 0402B102K500CT B 24.7/71.3
C21 4030022540 S.CER 0402N3R0B500CT [#11] B 27.6/7.3
4030022540 S.CER 0402N3R0B500CT [#12]
C22 4030023090 S.CER 0402B102K500CT B 27.4/72.0
C25 4030023010 S.CER 0402B104K160CT B 29.0/28.1
C31 4030023010 S.CER 0402B104K160CT B 25.7/34.5
C101 4030023090 S.CER 0402B102K500CT [#11] B 13.8/10.1
4030023090 S.CER 0402B102K500CT [#12]
C102 4030023200 S.CER 0402B471K500CT [#11] B 14.2/5.5
4030023200 S.CER 0402B471K500CT [#12]
C103 4030019560 S.CER GRM21BB31C106KE15L [#11] B 19.9/24.7
4030019560 S.CER GRM21BB31C106KE15L [#12]
C104 4030019560 S.CER GRM21BB31C106KE15L [#11] B 22.1/27.9
4030019560 S.CER GRM21BB31C106KE15L [#12]
C105 4030019560 S.CER GRM21BB31C106KE15L [#11] B 21.3/31.5
4030019560 S.CER GRM21BB31C106KE15L [#12]
C106 4030019560 S.CER GRM21BB31C106KE15L [#11] B 21.3/29.7
4030019560 S.CER GRM21BB31C106KE15L [#12]
C107 4030022940 S.CER 0402B104K100CT [#11] B 26.5/24.6
4030022940 S.CER 0402B104K100CT [#12]
C108 4030023090 S.CER 0402B102K500CT [#11] B 24.8/15.0
4030023090 S.CER 0402B102K500CT [#12]
C109 4030023090 S.CER 0402B102K500CT [#11] B 26.0/14.5
4030023090 S.CER 0402B102K500CT [#12]
C111 4550007300 S.TAN F931A335MAABMA [#11] B 14.4/24.7
4550007300 S.TAN F931A335MAABMA [#12]
C112 4550008210 S.TAN 267M3502 104MR [#11] B 20.3/20.1
4550008210 S.TAN 267M3502 104MR [#12]
C113 4550008210 S.TAN 267M3502 104MR [#11] B 18.2/20.1
4550008210 S.TAN 267M3502 104MR [#12]
C114 4550008210 S.TAN 267M3502 104MR [#11] B 8.0/2.0
4550008210 S.TAN 267M3502 104MR [#12]
C115 4550008210 S.TAN 267M3502 104MR [#11] B 8.0/4.1
4550008210 S.TAN 267M3502 104MR [#12]
C116 4030023090 S.CER 0402B102K500CT [#11] B 11.2/15.0
4030023090 S.CER 0402B102K500CT [#12]
C121 4030023030 S.CER 0402B103K250CT [#11] B 23.0/12.0
4030023030 S.CER 0402B103K250CT [#12]
C122 4030019560 S.CER GRM21BB31C106KE15L [#11] B 18.8/11.0
4030019560 S.CER GRM21BB31C106KE15L [#12]
C123 4030023090 S.CER 0402B102K500CT B 24.6/31.5
C125 4550007520 S.TAN F931A106MAABMA [#11] B 4.4/12.2
4550007520 S.TAN F931A106MAABMA [#12]
C155 4030023090 S.CER 0402B102K500CT T 11.8/2.4
C156 4030023090 S.CER 0402B102K500CT T 13.5/10.5
C157 4030023090 S.CER 0402B102K500CT T 13.7/4.0
C158 4030023090 S.CER 0402B102K500CT T 14.1/8.9
C159 4030023090 S.CER 0402B102K500CT T 9.9/2.4
C161 4030023090 S.CER 0402B102K500CT T 35.9/25.5
C600 4030023030 S.CER 0402B103K250CT [#11] B 21.5/10.8
4030023030 S.CER 0402B103K250CT [#12]
C629 4030023010 S.CER 0402B104K160CT [#11] B 24.8/26.6
4030023010 S.CER 0402B104K160CT [#12]
C630 4030022640 S.CER 0402N101J500CT [#11] B 19.3/90.9
4030022640 S.CER 0402N101J500CT [#12]
C631 4050000380 S.FEE NFM15PC104R1A3D [#11] B 18.2/89.2
4050000380 S.FEE NFM15PC104R1A3D [#12]
C632 4050000380 S.FEE NFM15PC104R1A3D [#11] B 33.6/94.1
4050000380 S.FEE NFM15PC104R1A3D [#12]
C633 4030019560 S.CER GRM21BB31C106KE15L [#11] B 33.7/92.4
4030019560 S.CER GRM21BB31C106KE15L [#12]
C634 4030023090 S.CER 0402B102K500CT [#11] B 32.6/94.0
4030023090 S.CER 0402B102K500CT [#12]
C637 4030023090 S.CER 0402B102K500CT [#11] B 28.7/88.4
4030023090 S.CER 0402B102K500CT [#12]
C638 4030023090 S.CER 0402B102K500CT [#11] B 19.2/84.1
4030023090 S.CER 0402B102K500CT [#12]
C639 4030023090 S.CER 0402B102K500CT [#11] B 22.5/79.2
4030023090 S.CER 0402B102K500CT [#12]
C640 4030023090 S.CER 0402B102K500CT [#11] B 29.9/87.9
4030023090 S.CER 0402B102K500CT [#12]
C641 4030023090 S.CER 0402B102K500CT [#11] B 18.3/84.1
4030023090 S.CER 0402B102K500CT [#12]
C642 4030023090 S.CER 0402B102K500CT [#11] B 19.6/78.7
4030023090 S.CER 0402B102K500CT [#12]
C643 4050000380 S.FEE NFM15PC104R1A3D [#11] T 20.1/13.2
4050000380 S.FEE NFM15PC104R1A3D [#12]
C645 4030021240 S.CER C1005 JB 1C 105K-T [#11] B 36.3/10.2
4030021240 S.CER C1005 JB 1C 105K-T [#12]
C648 4030022540 S.CER 0402N3R0B500CT [#11] T 25.0/16.5
4030022540 S.CER 0402N3R0B500CT [#12]
C649 4030022540 S.CER 0402N3R0B500CT [#11] T 23.6/18.8
4030022540 S.CER 0402N3R0B500CT [#12]
C650 4030023010 S.CER 0402B104K160CT [#11] B 40.4/5.5
4030023010 S.CER 0402B104K160CT [#12]
C651 4030019560 S.CER GRM21BB31C106KE15L [#11] B 36.7/7.1
4030019560 S.CER GRM21BB31C106KE15L [#12]
C652 4030022640 S.CER 0402N101J500CT [#11] B 39.0/3.3
4030022640 S.CER 0402N101J500CT [#12]
C653 4030023010 S.CER 0402B104K160CT [#11] B 42.2/5.1
4030023010 S.CER 0402B104K160CT [#12]
C654 4030023090 S.CER 0402B102K500CT B 41.3/89.6
C655 4030023090 S.CER 0402B102K500CT B 39.3/89.6
C656 4030023090 S.CER 0402B102K500CT B 38.3/89.7
C657 4030023090 S.CER 0402B102K500CT B 42.3/89.6
C659 4030023010 S.CER 0402B104K160CT B 28.6/10.3
C660 4030023010 S.CER 0402B104K160CT B 34.2/30.5
C661 4030019560 S.CER GRM21BB31C106KE15L B 43.4/44.6
C662 4030021520 S.CER GRM31CB31H106KA12L T 31.4/24.4
C663 4030021520 S.CER GRM31CB31H106KA12L T 32.4/28.2
C664 4030021520 S.CER GRM31CB31H106KA12L T 32.4/30.4
C666 4030023010 S.CER 0402B104K160CT T 33.3/22.3
C667 4030023010 S.CER 0402B104K160CT T 33.7/23.8
C669 4030022630 S.CER 0402N100C500CT B 37.1/54.5
C670 4030022520 S.CER 0402N1R0B500CT B 42.0/53.9
C671 4030022640 S.CER 0402N101J500CT B 42.1/56.8
C672 4030023010 S.CER 0402B104K160CT B 39.3/58.5
C674 4030023030 S.CER 0402B103K250CT B 26.9/68.8
C677 4030022940 S.CER 0402B104K100CT B 27.5/43.2
C678 4030023090 S.CER 0402B102K500CT B 31.5/41.9
C679 4030023090 S.CER 0402B102K500CT B 37.1/56.1
C680 4030023090 S.CER 0402B102K500CT B 36.2/56.2
C681 4030022940 S.CER 0402B104K100CT B 35.3/56.2
C682 4030023000 S.CER 0402B683K100CT B 22.8/65.8
C683 4030022940 S.CER 0402B104K100CT B 24.1/68.2
C684 4030023010 S.CER 0402B104K160CT B 36.2/54.5
C687 4030023010 S.CER 0402B104K160CT B 25.2/36.6
C688 4030019560 S.CER GRM21BB31C106KE15L B 23.8/36.4
C689 4030023090 S.CER 0402B102K500CT B 29.0/27.2
C693 4030022940 S.CER 0402B104K100CT T 16.4/15.5
C694 4030023090 S.CER 0402B102K500CT [#11] B 18.8/82.1
4030023090 S.CER 0402B102K500CT [#12]
C695 4030023010 S.CER 0402B104K160CT T 18.8/7.4
C696 4030023010 S.CER 0402B104K160CT T 15.9/11.4
C698 4030023010 S.CER 0402B104K160CT B 39.9/47.0
C699 4030023010 S.CER 0402B104K160CT B 43.2/42.2
C700 4030023090 S.CER 0402B102K500CT B 44.2/42.2
C701 4030023090 S.CER 0402B102K500CT B 25.7/33.6
C703 4030023000 S.CER 0402B683K100CT [#11] T 21.7/11.2
4030023000 S.CER 0402B683K100CT [#12]
C704 4030023090 S.CER 0402B102K500CT [#11] T 22.8/17.0
4030023090 S.CER 0402B102K500CT [#12]
C705 4030023090 S.CER 0402B102K500CT [#11] T 24.9/13.7
4030023090 S.CER 0402B102K500CT [#12]
C708 4030023090 S.CER 0402B102K500CT T 26.6/20.9
C709 4030021240 S.CER C1005 JB 1C 105K-T [#11] B 36.3/4.4
4030021240 S.CER C1005 JB 1C 105K-T [#12]
C711 4030023090 S.CER 0402B102K500CT B 39.1/33.8
C712 4030022920 S.CER 0402N820J500CT B 31.1/45.6
C713 4030022920 S.CER 0402N820J500CT B 24.5/42.4
C714 4030020000 S.CER C1005 JB 1A 105K-T B 31.3/65.3
C715 4030023820 S.CER 0603B104K250CT B 26.7/63.6
C716 4030023210 S.CER 0402B472K500CT B 34.1/64.8
C717 4030023210 S.CER 0402B472K500CT B 26.9/58.1
C718 4030023210 S.CER 0402B472K500CT B 31.5/27.6
C719 4030023210 S.CER 0402B472K500CT B 40.0/18.9
C720 4550008210 S.TAN 267M3502 104MR [#11] B 5.8/15.6
4550008210 S.TAN 267M3502 104MR [#12]
C721 4550008210 S.TAN 267M3502 104MR [#11] B 9.1/20.4
4550008210 S.TAN 267M3502 104MR [#12]
C722 4030021240 S.CER C1005 JB 1C 105K-T [#11] B 34.5/15.4
4030021240 S.CER C1005 JB 1C 105K-T [#12]
C723 4030021240 S.CER C1005 JB 1C 105K-T B 26.5/72.0
C724 4030023090 S.CER 0402B102K500CT B 35.9/58.6
J1 6510030220 S.CON 50RF-JMCS-G-1B-TF
(N) (LF) (SN) B 35.5/23.0
J2 6510031390 S.CON 15FXVL-RSM1-GAN-TF-1 (HF) T 9.4/7.9
J3 6510023480 S.CON AYU1-1P-02676-120-TF [#11] B 23.2/96.1
6510023480 S.CON AYU1-1P-02676-120-TF [#12]
J4 6510031380 S.CON 31FXVL-RSM1-GAN-TF-1 (HF) T 24.4/24.8
DS2 5040003550 S.LED NSSW208T T 13.8/35.5
DS3 5040003550 S.LED NSSW208T T 24.8/35.5
DS4 5040003550 S.LED NSSW208T T 35.8/35.5
DS5 5030004360 LCD TM128160D1CIWUGND
S23 2260003320 S.SWI SKRTLAE010 B 2.1/83.2
S24 2260003320 S.SWI SKRTLAE010 B 2.1/44.4
S25 2260003320 S.SWI SKRTLAE010 B 2.1/34.4
EP3 6910023920 S.BEA BLM15GA750SN1D [#11] B 38.5/16.4
6910023920 S.BEA BLM15GA750SN1D [#12]
EP4 6910023920 S.BEA BLM15GA750SN1D [#11] B 36.9/15.3
6910023920 S.BEA BLM15GA750SN1D [#12]
EP9 6910020610 S.BEA BLM15BD102SN1D [#11] B 18.4/90.9
6910020610 S.BEA BLM15BD102SN1D [#12]
EP10 6910020610 S.BEA BLM15BD102SN1D T 34.7/22.6
EP11 6910020610 S.BEA BLM15BD102SN1D T 30.8/20.7
EP12 6910020610 S.BEA BLM15BD102SN1D T 25.0/21.2
EP13 6910020610 S.BEA BLM15BD102SN1D T 17.7/28.7
EP14 6910020610 S.BEA BLM15BD102SN1D T 23.2/21.2
EP16 6910020610 S.BEA BLM15BD102SN1D T 17.7/27.8
EP19 6910020610 S.BEA BLM15BD102SN1D T 22.3/21.2
The underlined parts have been updated from the previous version of the addendum, or the original page.

Icom IC-A25C Specifications

General

Purpose	Aviation Service (Air Band)
Operating frequency	118.000 – 136.992 MHz
Display type	LCD
Display diagonal	2.3 \
Battery type	BP-288
Battery life (max)	10.5 h
Battery low indication	Yes
Number of batteries supported	1
Product color	Black
Operating temperature (T-T)	-10 - 60 °C
Number of batteries included	1 pc(s)
Antenna connector type	FA-B02AR

Weight and Dimensions

Depth	31.8 mm
Width	58.9 mm
Height	148.4 mm
Weight	384 g
