Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=
Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
(Amended page)
REF
NO.
PART
NO.
DESCRIPTION M
.
H/V
LOCATION
REF
NO.
PART
NO.
DESCRIPTION M
.
H/V
LOCATION
March 2019
[MAIN UNIT] (for #11, #12, #21, #22, and #31) [MAIN UNIT] (for #11, #12, #21, #22, and #31)
5-4a
IC1 1110007300 S.IC NJM2552V-TE1-#ZZZB B 35.6/72.6
IC2 1130009981 S.IC TC7W53FK (TE85LF) B 33.1/63.1
IC5 1130011760 S.IC CD4094BPWR B 39.9/44.3
IC14 1110006490 S.IC LMV321IDCKR T 7.7/69.0
IC22 1110006490 S.IC LMV321IDCKR B 23.9/64.7
IC24 1130007021 S.IC TC7S66FU (TE85LF) B 41.0/79.3
IC25 1110006490 S.IC LMV321IDCKR B 21.3/70.5
IC203 1130017460 S.IC AK1542A-L B 29.7/44.6
IC215 1110007630 S.IC NJM2783V-TE1-#ZZZH T 41.5/30.8
IC216 1110007291 S.IC AK2330P7-L T 24.7/60.1
IC219 1130007021 S.IC TC7S66FU (TE85LF) B 22.3/46.2
IC220 1110007291 S.IC AK2330P7-L T 28.4/37.4
IC221 1110008450 S.IC ISD8102SYI T&R B 30.6/26.5
IC222 1110008550 S.IC NJM2904CRB1-TE1-#HMZR B 24.9/59.2
IC223 1110008550 S.IC NJM2904CRB1-TE1-#HMZR B 9.9/30.9
IC224 1110008550 S.IC NJM2904CRB1-TE1-#HMZR B 10.0/25.6
IC225 1110008550 S.IC NJM2904CRB1-TE1-#HMZR B 10.0/21.1
IC226 1110008550 S.IC NJM2904CRB1-TE1-#HMZR B 10.0/15.8
IC228 1130009981 S.IC TC7W53FK (TE85LF) B 10.5/11.8
IC229 1110008680 S.IC NJU72341V-TE2-#UZZH T 38.6/39.5
IC231 1130009981 S.IC TC7W53FK (TE85LF) T 42.3/48.4
IC232 1110008550 S.IC NJM2904CRB1-TE1-#HMZR T 44.5/41.7
IC233 1110006490 S.IC LMV321IDCKR B 11.9/5.8
IC234 6910026630 S.DC XC9263B75DER-G B 30.6/8.3
IC235 1110008550 S.IC NJM2904CRB1-TE1-#HMZR T 17.6/15.9
IC238 1180004760 S.REG S-1200B33-M5T1U T 30.3/89.2
IC239 1180004420 S.REG NJM2830U1-08-TE1-#ZGZB T 10.4/18.2
IC240 1180005110 S.REG NJM2836DL3-05-TE1 T 29.3/96.4
IC241 1130007021 S.IC TC7S66FU (TE85LF) [#11] B 21.3/68.0
1130007021 S.IC TC7S66FU (TE85LF) [#12]
Q2 1560002350 S.FET RD12MVS1-T214 T 13.0/83.6
Q3 1560002420 S.FET RD01MUS2B-T513 T 12.3/74.7
Q4 1530004100 S.TRA MT3S20P (TE12LF) B 11.6/65.4
Q7 1520000201 S.TRA 2SB798-T1-AZ DK T 17.0/59.1
Q8 1590004410 S.TRA DMC501010R T 12.9/59.8
Q11 1580000731 S.FET 3SK293 (TE85LF) B 30.0/106.2
Q12 1580000731 S.FET 3SK293 (TE85LF) B 27.8/96.9
Q13 1530002381 S.TRA 2SC4215-Y (TE85LF) B 27.4/78.3
Q20 1590004300 S.TRA DRA9114T0L B 36.2/60.1
Q21 1590004100 S.TRA LDTC144TET1G B 29.3/61.3
Q25 1520000201 S.TRA 2SB798-T1-AZ DK T 44.2/113.7
Q26 1590004330 S.TRA DRC9114E0L T 31.5/105.3
Q28 1530003322 S.TRA 2SC5108-YLF B 11.3/53.4
Q29 1530003322 S.TRA 2SC5108-YLF B 12.4/48.4
Q33 1530002851 S.TRA 2SC4116-BL (TE85RF) B 6.2/52.5
Q35 1520000651 S.TRA 2SB1201S-TL-E T 16.1/26.9
Q36 1590004410 S.TRA DMC501010R B 20.9/26.1
Q50 1510001151 S.TRA L2SA1576AST1G B 42.5/115.6
Q52 1590004530 S.TRA DMG564050R T 37.5/27.8
Q53 1590004070 S.TRA LDTC144EET1G B 25.9/71.5
Q54 1590004050 S.TRA LDTA144EET1G T 33.8/68.6
Q57 1590004520 S.TRA DMA561030R B 13.6/45.6
Q58 1530004610 S.TRA 2SC5086-OLF T 17.7/47.5
Q59 1530004610 S.TRA 2SC5086-OLF T 10.6/46.9
Q60 1530003322 S.TRA 2SC5108-YLF T 14.3/49.3
Q62 1530004190 S.TRA L2SC4617ST1G B 43.4/71.2
Q66 1590004070 S.TRA LDTC144EET1G B 40.1/56.7
Q68 1590004070 S.TRA LDTC144EET1G B 43.0/82.9
Q212 1550000241 S.FET TPCF8107LF T 21.7/122.8
Q213 1550000241 S.FET TPCF8107LF T 24.6/122.1
Q215 1560000531 S.FET 2SK880-GR (TE85RF) B 22.5/41.6
Q216 1590004070 S.TRA LDTC144EET1G B 24.0/50.7
Q217 1590004070 S.TRA LDTC144EET1G B 15.6/43.9
Q218 1590004070 S.TRA LDTC144EET1G T 30.7/60.7
Q220 1590004070 S.TRA LDTC144EET1G T 18.7/7.2
Q223 1550000090 S.FET RSQ035P03TR T 32.2/11.4
Q224 1590004070 S.TRA LDTC144EET1G T 34.1/14.3
Q226 1590004070 S.TRA LDTC144EET1G B 39.7/20.3
Q232 1560001330 S.FET RSR025N03 T 36.5/23.0
Q233 1590004060 S.TRA LDTC114EET1G T 34.9/26.1
Q234 1520000651 S.TRA 2SB1201S-TL-E T 33.9/4.4
Q235 1530002280 S.TRA 2SC4081 T106 S T 25.9/12.9
Q236 1590004070 S.TRA LDTC144EET1G B 38.1/50.8
Q238 1590004070 S.TRA LDTC144EET1G B 29.2/15.5
Q239 1510000671 S.TRA 2SA1588-GR (TE85R F) T 24.4/7.6
Q240 1590004070 S.TRA LDTC144EET1G T 22.0/6.9
Q243 1590004070 S.TRA LDTC144EET1G T 31.6/71.6
Q245 1590004050 S.TRA LDTA144EET1G T 31.3/31.0
Q246 1590004070 S.TRA LDTC144EET1G T 33.5/31.0
D1 1750000581 S.DIO 1SV307 (TPH3F) T 5.4/19.4
D2 1750001800 S.DIO RB886CS T2RA T 13.2/102.7
D3 1750001800 S.DIO RB886CS T2RA T 12.4/99.6
D4 1750001800 S.DIO RB886CS T2RA T 13.2/103.8
D5 1750001800 S.DIO RB886CS T2RA T 5.1/12.1
D6 1750001790 S.DIO 1SS390 TE61 T 5.1/9.6
D8 1750000581 S.DIO 1SV307 (TPH3F) T 10.3/110.7
D11 1750001790 S.DIO 1SS390 TE61 T 27.8/85.7
D12 1750001790 S.DIO 1SS390 TE61 T 37.4/71.0
D13 1720000702 S.VAR 1SV305H3F B 19.9/103.3
D14 1790001622 S.DIO 1SV308L3F B 11.8/108.5
D15 1720000702 S.VAR 1SV305H3F B 31.2/102.2
D16 1720000702 S.VAR 1SV305H3F B 30.3/99.5
D17 1750001790 S.DIO 1SS390 TE61 B 13.7/55.8
D18 1750002170 S.DIO DB2S31400L B 29.6/64.6
D23 1790001980 S.DIO DA3S101F0L T 32.2/109.1
D24 1750001790 S.DIO 1SS390 TE61 T 33.7/67.0
D25 1750001790 S.DIO 1SS390 TE61 T 37.3/66.8
D27 1750001810 S.DIO L1SS400T1G T 37.2/110.1
D29 1790001622 S.DIO 1SV308L3F B 12.8/104.9
D30 1750001810 S.DIO L1SS400T1G T 34.3/17.6
D31 1750001810 S.DIO L1SS400T1G T 18.4/109.1
D36 1750001810 S.DIO L1SS400T1G B 42.2/112.7
D38 1750001771 S.VAR 1SV323H3F T 19.4/41.5
D40 1750002170 S.DIO DB2S31400L B 27.3/69.9
D44 1790001622 S.DIO 1SV308L3F B 13.2/102.3
D45 1750001771 S.VAR 1SV323H3F T 11.5/40.1
D46 1750001771 S.VAR 1SV323H3F T 12.2/38.0
D48 1750001771 S.VAR 1SV323H3F T 19.4/40.2
D49 1750001800 S.DIO RB886CS T2RA T 12.0/113.6
D50 1720000702 S.VAR 1SV305H3F B 28.0/105.4
D51 1750001800 S.DIO RB886CS T2RA T 12.0/112.5
D52 1750001810 S.DIO L1SS400T1G B 36.0/86.2
D55 1750001790 S.DIO 1SS390 TE61 B 28.9/80.3
D56 1750001790 S.DIO 1SS390 TE61 B 26.1/92.2
D57 1750001790 S.DIO 1SS390 TE61 B 27.1/81.3
D58 1750001790 S.DIO 1SS390 TE61 B 28.9/91.4
D59 1750001800 S.DIO RB886CS T2RA B 40.3/85.4
D62 1750002170 S.DIO DB2S31400L T 31.5/70.0
D66 1750000520 S.DIO DAN222TL T 31.3/62.7
D67 1750001810 S.DIO L1SS400T1G T 31.7/119.3
D68 1750001690 S.DIO RB050LA-40 T 27.9/119.4
D71 1730002830 S.ZEN DZ2J051M0L B 40.9/26.0
D72 1790002160 S.VAR TPD1E10B06DPYR B 42.3/96.4
D74 1750001800 S.DIO RB886CS T2RA T 44.8/37.5
D78 1750001810 S.DIO L1SS400T1G T 21.0/96.5
D80 1750001810 S.DIO L1SS400T1G T 26.9/11.0
D81 1750001810 S.DIO L1SS400T1G T 24.2/11.0
D82 1750001810 S.DIO L1SS400T1G T 14.2/19.1
D83 1750001810 S.DIO L1SS400T1G T 30.7/91.6
D85 1790002160 S.VAR TPD1E10B06DPYR T 28.2/122.1
D86 1790001622 S.DIO 1SV308L3F B 30.3/77.2
D87 1750001810 S.DIO L1SS400T1G T 24.2/9.8
D88 1750001810 S.DIO L1SS400T1G T 26.8/9.8
D89 1750001790 S.DIO 1SS390 TE61 [#11] T 36.5/68.6
1750001790 S.DIO 1SS390 TE61 [#12]
D90 1750001790 S.DIO 1SS390 TE61 [#11] T 30.4/85.7
1750001790 S.DIO 1SS390 TE61 [#12]
D91 1750001810 S.DIO L1SS400T1G T 33.2/70.8
D92 1750001810 S.DIO L1SS400T1G T 33.2/73.3
D93 1750002170 S.DIO DB2S31400L T 23.8/85.7
D94 1750002170 S.DIO DB2S31400L B 27.7/90.5
FI1 2030000970 S.MON FL-455 (46.35 MHz) B 23.4/86.8
FI2 2020002720 S.CER LTWC450D T 28.1/79.0
FI3 2030000860 S.MON FL-439 (46.350 MHz) B 30.2/85.7
FI4 2020002520 S.CER LTWC450H T 41.1/77.1
FI5 2020002770 S.CER LTUCG450C [#11] T 38.7/86.0
2020002770 S.CER LTUCG450C [#12]
X1 6070000300 S.DIS JTBM450CX24 T 42.1/63.4
X2 6050013940 S.XTA CR-994 (12.8 MHz) B 32.8/38.8
X203 6050013930 S.XTA CR-993 (15.3 MHz) B 42.5/65.4
L2 6200013110 S.COI 0.35-1.6-9TL 52.0N T 8.6/115.9
L3 6200013110 S.COI 0.35-1.6-9TL 52.0N T 6.2/111.0
L4 6200004480 S.COI MLF1608D R82K-T T 9.0/105.0
L5 6200012460 S.COI 0.30-1.7-8TL 54N T 9.8/101.2
L6 6200012850 S.COI 0.40-0.8-2TL 2.5N T 8.1/90.2
L7 6200013030 S.COI 0.35-1.6-6TL 31.0N T 15.5/88.5
L8 6200009280 S.COI LQW18AN27NG00D
(LQW1608A27NG00) T 11.0/78.0
L10 6200013800 S.COI MLK1005S39NJT T 15.4/77.8
L11 6200013790 S.COI MLK1005S47NJT T 15.5/71.2
L12 6200013780 S.COI MLK1005S56NJT B 15.5/66.5
L15 6200012460 S.COI 0.30-1.7-8TL 54N T 8.3/107.2
L18 6200009890 S.COI C2012C-82NG-A B 15.0/102.0
L21 6200009890 S.COI C2012C-82NG-A B 33.8/104.6
L22 6200009930 S.COI C2012C-68NG-A B 17.7/102.5
L23 6200009890 S.COI C2012C-82NG-A B 33.3/100.5
L24 6200011090 S.COI C2012C-R56J-A B 31.4/95.2
L25 6200004600 S.COI MLF1608D R15K-T B 27.6/75.6
L38 6200014760 S.COI MLK1005SR22JT B 13.0/54.6
L45 6200012910 S.COI 0.35-1.6-8TL 45.5N T 11.1/119.6
L46 6200012870 S.COI 0.30-1.4-5TR 23.5N T 10.6/94.2
L56 6200013760 S.COI MLK1005S82NJT B 8.4/61.7
L57 6200010540 S.COI C2012C-47NG-A T 17.2/40.9
L58 6200003550 S.COI MLF1608A 4R7K-T T 13.3/41.6
L63 6200011050 S.COI C2012C-R12G-A T 20.4/44.8
L64 6200011050 S.COI C2012C-R12G-A T 8.9/42.4
L67 6200013760 S.COI MLK1005S82NJT T 15.9/50.2
L69 6200009890 S.COI C2012C-82NG-A B 21.6/102.8
L71 6200003640 S.COI MLF1608E 100K-T T 8.8/40.2
L72 6200003640 S.COI MLF1608E 100K-T T 21.2/40.8
L85 6200004600 S.COI MLF1608D R15K-T B 43.8/77.3
L86 6200004590 S.COI MLF1608D R18K-T B 41.7/76.7
L87 6200003960 S.COI MLF1608A 1R0K-T B 45.0/74.5
L88 6200004590 S.COI MLF1608D R18K-T B 41.8/72.8
L91 6200003550 S.COI MLF1608A 4R7K-T T 15.4/40.9
L92 6200011050 S.COI C2012C-R12G-A T 9.2/38.4
L93 6200014370 S.COI MLF1005L 2R2K-T B 26.3/91.2
L94 6200014370 S.COI MLF1005L 2R2K-T B 25.3/81.3
L95 6200014370 S.COI MLF1005L 2R2K-T B 31.0/79.2
L96 6200014370 S.COI MLF1005L 2R2K-T B 32.4/91.3
L97 6200011650 S.COI LQW18AN68NG00D B 25.3/95.7
L99 6200014260 S.COI LQM2MPN2R2NG0L B 27.5/7.7
L100 6200014260 S.COI LQM2MPN2R2NG0L B 37.0/7.4
