2-2
LOGIC/LOGIC-1 UNIT (BOTTOM VIEW)
GPS Module (IC17)*
Inside the shield case
J3*
CPU (IC27)
Under the shield plate
Clock Oscillator (X1)
Under the shield plate
5 V Regulator (IC40)
(for LCD Backlight)
J1
*Only for IC-A25N
