SCAN OPERATION
■ Memory (lockout) scan
Memory scan repeatedly scans all programmed memory
channels, except those set as lockout channels.
q Push [V/M] to select memory mode, if necessary.
• “ ” appears.
w Puch [SCAN] to start scan.
- To change the scan direction, push [Y] or [Z].
e Push [SCAN] again to stop the scan.
MR
MEMORY LOCKOUT(SKIP) SCAN
SKIP
SKIP
Mch 1
Mch 7
Mch 2 Mch 4
Mch 3 Mch 5 Mch 6
Mch 8
Mch 19 Mch 11 Mch 10 Mch 9
■ VFO (Full) scan
VFO scan repeatedly scans between the VFO’s lowest
frequency and its highest frequency.
- To change the scan direction, push [Y] or [Z] during
scanning.
D Scan resume condition
When a signal is received during scanning, the scan pauses
on the signal until it disappears, then resumes.
VFO SCAN (Full scan)
Scan
Jump
Start
highest
frequency
lowest
frequency
