■ Panel description
q VOLUME CONTROLS [VOL] (p. 5)
Turns power ON and adjusts the audio level.
w PTT SWITCH [PTT] (p. 5)
Push and hold to transmit; release to receive.
e CHANNEL UP/DOWN SWITCHES [Y]/[Z]
➥ Push to select the operating channel or frequency. (p. 5)
➥ Select item conditions in set mode.
r LOCK SWITCH [ ]
➥ Push and hold 2 sec. to toggle the key lock function ON
or OFF. (p. 6)
- “
” appears on the display.
t VFO/MEMORY SWITCH [V/M]
➥ Push to select VFO mode or memory mode. (pgs. 5, 8)
- “X” appears when memory mode is selected.
- The transceiver has 19 memory channels.
y MEMORY WRITE SWITCH [MW]
➥ Push and hold for 5 sec. to write information into mem-
ory channels. (p. 9)
u SCAN SWITCH [SCAN]
➥ Starts and stops the scan function:
VFO mode: VFO scan function.
MEMORY mode: Memory channel scan function. (p. 10)
2
2
PANEL DESCRIPTION
