5 - 2
M ENTERING ADJUSTMENT MODE
q Turn the power OFF.
w Connect
the JIG cable to the [DATA/SP/MIC] jack.
e While pushing [SQL] and [8] keys, turn the power ON.
M
KEY ASSIGNMENTS FOR THE ADJUSTMENT MODE
M
QUITTING ADJUSTMENT MODE
q Turn the power OFF.
w While pushing [VFO], [MR] and [BAND] keys, turn the power ON. (All reset)
Adjusts the value for the item
Stores adjustment value
Starts automatic adjustment
Selects previous adjustment item
Selects next adjustment item
(without storing value)
(4
#(/
5.1
[SQL]
Adjustment frequency
Adjustment value
Adjustment item
[PWR]
[8]
(4
#(/
5.1
TX power
Band: Mode
During adjustment mode, the display shows adjustment conditions as above.
