5 - 10
5-3 FREQUENCY ADJUSTMENT
Select an adjustment item using [2]
/ [8] keys, then set the adjustment value as specifi ed using [DIAL].
ADJUSTMENT ADJUSTMENT CONDITION OPERATION
ADJUSTMENT
ITEM
VALUE
REFERENCE
FREQUENCY
1 • Displayed freq. : "
"
• Transmitting
1) Connect an RF to the
antenna connector.
2) Loose couple a Frequency
Counter to the antenna
connector.
3) Adjust the frequency using
[DIAL], then release the PTT
and push [BAND] to store the
adjustment value.
[
(T
]
(Displayed
frequency)
(Loose Coupling)
FREQUENCY COUNTER
(0.1–600 MHz)
RF POWER METER
(10 W/50 Ω)
JIG cable
(See the page 5-1)
7.4 V
Fusese
(3A)
DC power supply
⊕
−
–
+
Be sure the polarity.
(4
#(/
5.1
To the battery contact pins
To Next Page
