Icom IC-E92D Service Manual

6 - 3
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[LOGIC UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
C328 4030018860 S.CER ECJ0EB0J105K B 50/26.2
C329 4030017710 S.CER ECJ0EC1H181J B 50.4/29
C330 4030017460 S.CER ECJ0EB1E102K B 55/31.1
C331 4550007690 S.TAN TEESVP 1C 105M8R B 55.6/36.4
C332 4030016790 S.CER ECJ0EB1C103K B 52.4/29.9
C333 4550007680 S.TAN TEESVP 0J 226M8R B 52.9/28.5
C334 4030018110 S.CER ECJ0EB1H272K B 46.9/35.3
C335 4030018140 S.CER ECJ0EB1H391K B 50.2/38.4
C336 4550007730 S.TAN TEESVJ 0J 106M8R B 45.2/34.1
C337 4030017920 S.CER ECJ0EB1A683K B 47.3/33
C338 4030017040 S.CER ECJ0EB1A333K B 46.1/31
C339 4030017460 S.CER ECJ0EB1E102K B 47.8/29.9
C340 4030017040 S.CER ECJ0EB1A333K B 17.2/2.4
C341 4030016960 S.CER ECJ0EB1C183K B 50.2/41.1
C342 4030017460 S.CER ECJ0EB1E102K B 19.3/5.8
C343 4030018860 S.CER ECJ0EB0J105K B 54.9/38.9
C344 4030017460 S.CER ECJ0EB1E102K B 14.7/6.4
C347 4030017460 S.CER ECJ0EB1E102K B 39.9/33.2
C400 4030017460 S.CER ECJ0EB1E102K B 52.2/6.8
C401 4030017460 S.CER ECJ0EB1E102K B 51.4/14.7
C403 4030017460 S.CER ECJ0EB1E102K B 53.5/15.8
C404 4030017460 S.CER ECJ0EB1E102K B 54.5/11.3
C405 4030018860 S.CER ECJ0EB0J105K B 55.4/11.3
C408 4030017460 S.CER ECJ0EB1E102K B 58/14
C409 4030016930 S.CER ECJ0EB1A104K B 23.3/2.1
C410 4030016780 S.CER ECJ0EB1C153K B 26.7/2.1
C411 4030016930 S.CER ECJ0EB1A104K B 26.3/3.3
C412 4550002960 S.TAN TEESVA 1C 155M8R B 25.1/5.2
C413 4030016930 S.CER ECJ0EB1A104K B 36.9/2.1
C414 4510008500 S.ELE EEE1CA101WP B 47.2/12.7
C415 4030016950 S.CER ECJ0EB1A473K B 37/8.2
C416 4510009020 S.ELE EEE0JA331P B 39.2/13.4
C417 4030017460 S.CER ECJ0EB1E102K B 38.7/18.9
C418 4030017460 S.CER ECJ0EB1E102K B 56.6/33.4
C419 4030017460 S.CER ECJ0EB1E102K B 57/16
C420 4510008040 S.ELE EEFCD 0K 330R B 56/6.2
C421 4030018520 S.CER C1608 JB 0J 225M-T B 54.7/16.2
C500 4030016930 S.CER ECJ0EB1A104K B 77.6/16.3
C501 4030017460 S.CER ECJ0EB1E102K B 72.3/16.2
C503 4030017460 S.CER ECJ0EB1E102K B 70.6/16.5
C504 4030016930 S.CER ECJ0EB1A104K B 69.1/16.2
C505 4030016930 S.CER ECJ0EB1A104K B 72.4/18.1
C506 4030017460 S.CER ECJ0EB1E102K B 70.1/24.6
C507 4030017400 S.CER ECJ0EC1H220J B 56.3/44.7
C508 4030018860 S.CER ECJ0EB0J105K B 56.4/46.8
C509 4030017460 S.CER ECJ0EB1E102K T 49.3/50.4
C510 4030016930 S.CER ECJ0EB1A104K T 47.7/50.6
C511 4030016930 S.CER ECJ0EB1A104K B 45.1/51.1
C512 4030017030 S.CER ECJ0EB1A273K B 45.5/44.5
C513 4030017030 S.CER ECJ0EB1A273K B 44.6/46.1
C514 4030017460 S.CER ECJ0EB1E102K B 45.8/37.3
C515 4030016930 S.CER ECJ0EB1A104K B 43.6/41.8
C516 4030017760 S.CER ECJ0EB1H222K B 50.9/42.3
C517 4030016930 S.CER ECJ0EB1A104K B 70/41
C518 4030016930 S.CER ECJ0EB1A104K B 81/43.4
C519 4550006930 S.TAN TEESVP 0J 225M8R B 81.1/42
C520 4030017420 S.CER ECJ0EC1H470J B 72.8/40.6
C521 4550007730 S.TAN TEESVJ 0J 106M8R B 68.6/43
C522 4030016930 S.CER ECJ0EB1A104K B 76.6/50.9
C523 4030016930 S.CER ECJ0EB1A104K B 77.5/50.9
C524 4030016970 S.CER ECJ0EB1C223K B 71.5/50.9
C525 4030016950 S.CER ECJ0EB1A473K B 74.3/50.9
C526 4030016930 S.CER ECJ0EB1A104K B 69.6/43.4
C527 4030016930 S.CER ECJ0EB1A104K B 58.3/47.4
C528 4030018860 S.CER ECJ0EB0J105K B 57.2/43.5
C529 4030016930 S.CER ECJ0EB1A104K T 62.8/47
C530 4030016930 S.CER ECJ0EB1A104K B 75.3/18.8
C531 4030016930 S.CER ECJ0EB1A104K B 81.2/18.7
C532 4030017460 S.CER ECJ0EB1E102K B 79.2/19.7
C534 4030017460 S.CER ECJ0EB1E102K B 80.9/19.7
C535 4030016930 S.CER ECJ0EB1A104K B 80.9/20.6
C536 4030016930 S.CER ECJ0EB1A104K B 85.7/17.4
C537 4030016930 S.CER ECJ0EB1A104K B 83.7/22.4
C538 4030016930 S.CER ECJ0EB1A104K B 80.6/22.4
C539 4030016930 S.CER ECJ0EB1A104K B 79/22.4
C540 4030016930 S.CER ECJ0EB1A104K B 69.1/30.7
C541 4030016930 S.CER ECJ0EB1A104K B 69.1/38.1
C542 4030016930 S.CER ECJ0EB1A104K B 81.4/40.6
C543 4030016930 S.CER ECJ0EB1A104K B 79.3/40.5
C544 4030016930 S.CER ECJ0EB1A104K B 77.2/40.5
C545 4030016930 S.CER ECJ0EB1A104K B 86.4/39.5
C546 4030017420 S.CER ECJ0EC1H470J B 85.5/39.5
C547 4030017460 S.CER ECJ0EB1E102K B 64.7/28.8
C548 4550006930 S.TAN TEESVP 0J 225M8R T 66.9/29.4
C549 4030017460 S.CER ECJ0EB1E102K T 66.9/31.5
C550 4030017460 S.CER ECJ0EB1E102K T 66.4/35.2
C551 4030012610 S.CER C2012 JB 1C 474K-T B 64.8/11.1
C552 4030018860 S.CER ECJ0EB0J105K B 62.7/14.9
C553 4030018860 S.CER ECJ0EB0J105K B 63.6/14.9
C554 4550007680 S.TAN TEESVP 0J 226M8R B 64.8/17.3
C555 4550006250 S.TAN TEESVA 1A 106M8R B 64.7/25.8
C556 4030016930 S.CER ECJ0EB1A104K B 63.1/24.9
C557 4030017460 S.CER ECJ0EB1E102K B 21.7/15.9
C600 4030017420 S.CER ECJ0EC1H470J B 14.1/42.6
C602 4030017460 S.CER ECJ0EB1E102K B 36.5/52.2
C603 4030017460 S.CER ECJ0EB1E102K B 39.8/52.5
C604 4030017460 S.CER ECJ0EB1E102K B 40.7/29.7
C605 4030017460 S.CER ECJ0EB1E102K B 40.9/26.9
J1 6510025370 S.CNR AXK816145YG B 84.2/47.3
J200 6510025170 S.CNR IMSA-9631S-27Y-921 B 30.6/27.4
J600 6510024131 S.CNR IMSA-9637S-40Y905 B 22/11.4
J601 6510026410 S.CNR SM10B-SRSS-TB (LF) (SN) B 6.8/41.6
S.=Surface mount
[LOGIC UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
DS1 5030002880 LCD HLM7972-010100
DS201 5040002670 S.LED CL-165HR/YG T 39.1/7.1
DS202 5040003280 S.LED RY-SP192UYG24-5M <VKH> T 87.8/13.9
DS203 5040003280 S.LED RY-SP192UYG24-5M <VKH> T 87.8/22.9
DS204 5040003280 S.LED RY-SP192UYG24-5M <VKH> T 87.8/40.9
DS205 5040003280 S.LED RY-SP192UYG24-5M <VKH> T 80.1/13.9
DS206 5040003280 S.LED RY-SP192UYG24-5M <VKH> T 80.1/22.9
DS207 5040003280 S.LED RY-SP192UYG24-5M <VKH> T 72.4/40.9
DS208 5040003280 S.LED RY-SP192UYG24-5M <VKH> T 54.6/11.4
DS209 5040003280 S.LED RY-SP192UYG24-5M <VKH> T 62.4/15.4
DS210 5040002961 S.LED SML-A12MT T86J T 4.4/18.4
DS211 5040002961 S.LED SML-A12MT T86J T 4.4/36.4
MC300 7700002850 MIC EM6022P-65B-G <HOR>
SP1 2510001420 SP PSC-2849PA <PRI>
W1 7120000470 JMP ERDS2T0
W2 8900007682 CBL OPC-741A-1 (P0.5,N40,L55)
EP50 6910018460 S.BEA MMZ1005Y102C-T B 23.5/45.2
EP51 6910018460 S.BEA MMZ1005Y102C-T B 12.7/45.5
EP52 6910018460 S.BEA MMZ1005Y102C-T B 11.3/45.8
EP53 6910018460 S.BEA MMZ1005Y102C-T B 13.1/44.3
EP100 6910018460 S.BEA MMZ1005Y102C-T B 98.5/46.9
EP101 6910018460 S.BEA MMZ1005Y102C-T B 92.6/38.5
EP102 6910018460 S.BEA MMZ1005Y102C-T B 96.7/26.2
EP500 6910018460 S.BEA MMZ1005Y102C-T B 78.5/16.3
EP501 6910018460 S.BEA MMZ1005Y102C-T B 72.9/21.2
EP502 6910018460 S.BEA MMZ1005Y102C-T T 57.4/51
EP503 6910018460 S.BEA MMZ1005Y102C-T B 43.6/40.2
EP504 6910018460 S.BEA MMZ1005Y102C-T B 70.4/39.8
EP505 6910018460 S.BEA MMZ1005Y102C-T B 74.4/40.6
EP506 6910018460 S.BEA MMZ1005Y102C-T B 70/44.6
EP507 6910018460 S.BEA MMZ1005Y102C-T T 60.6/47.5
EP508 6910018460 S.BEA MMZ1005Y102C-T B 73.4/19.5
EP509 6910018460 S.BEA MMZ1005Y102C-T B 64.6/22.9
EP511 6910018460 S.BEA MMZ1005Y102C-T B 10.9/38.1
EP512 6910018460 S.BEA MMZ1005Y102C-T B 11.8/38.2
EP514 6910018460 S.BEA MMZ1005Y102C-T B 11.6/41.5
EP515 6910018460 S.BEA MMZ1005Y102C-T B 12.9/42.3
EP516 6910018460 S.BEA MMZ1005Y102C-T B 11.4/43.1
EP517 6910018460 S.BEA MMZ1005Y102C-T B 16.3/43.2
