5
3
BATTERY PACKS
■ Battery pack replacement
Before replacing the battery pack, the volume control MUST be ro-
tated fully counterclockwise, until a click is heard, to turn the power
OFF.
• Slide the battery release forward, then pull the battery pack up
-
ward with the transceiver facing away from you.
D BATTERY PACKS
Battery
pack
Voltage Capacity
Charging period
Battery life*
1
BC-146
BC-119N or
BC-121N
with AD-101
BP-208N*
2
Battery case for AA
(LR6) × 6 alkaline
N/A N/A —*
3
BP-209N 7.2 V 1100 mAh 12 hrs. 1.5 hrs. 8 hrs.
BP-210N 7.2 V
1500 mAh
(minimum)
18.5 hrs. 2.0 hrs. 11 hrs.
1650 mAh
(typical)
BP-222N 7.2 V 600 mAh 6.5 hrs. 1.0 hrs. 4.5 hrs.
*
1
Operating periods are calculated under the following conditions;
Tx : Rx : standby = 5 : 5 : 90
*
2
Output power is automatically reduced to 1 W to retains sufficient power
in case of emergency, etc.
*
3
Operating period depends on the alkaline cells used.
To Next Page
