7
3
BATTERY PACKS
■ Battery charging
D Rapid charging with the BC-144N
The optional BC-144N provides rapid charging of the battery pack.
The following items are additionally required:
• AD-99N* and an AC adapter (not supplied with some versions).
*Supplied with the charger.
BC-144N
+ AD-99N
Insert together with
the AD-99N.
Check the orienta-
tion of the AD-99N
for correct charging.
Turn power OFF.
D Spacer combination.
• Be sure to attach the spacer (Spacer B/
C) to the adapter (Spacer A) with the
orientation as illustrated in the diagram
at right.
• Attach the spacer (Spacer B/C) to
the adaptor with the orientation of the
stamp “ ” pointing up.
NOTE: Push the notch carefully when
removing the spacer from the adaptor.
The BC-144N cannot
be used in a vehicle,
because the charger
requires 16 V DC
input.
Check orientation
and
Spacer A
Spacer B/C
To Next Page
