■ DTMF PAGER/CODE SQUELCH
When you install optional the UT-108 DTMF DECODER UNIT into
the transceiver, DTMF pager function or code squelch function will
be available.
D DTMF pager
This function uses DTMF tones for calling and can be used as a
“common pager” to inform you that one of your group has called
even if the operator is temporarily away from the transceiver.
• When the connection code is received, a beep sounds, then “
”
flashes and shows the called stations code number.
• Called stations code number are memorised automatically, and
are easy to re-call with “ID-MR select function”.
D Code squelch
This conveniently eliminates unwanted audio and is useful in group
activities or security related activities where unwanted output can
be a problem. The function is similar to a CTCSS tone squelch.
In order to use the above functions, cloning is necessary via a PC
using the optional CS-F3G cloning software. Using this software,
the transceiver’s model, individual RX Code CH, TX Code CH,
Special Tone Link2 (must be ‘E’) on 5Tone screen, 5Tone Signaling
Form on Memory-CH screen, Log, RX C-No, Key&Display, Com-
mon AutoReset TimerB, and other settings related to operation can
be set. Refer to the HELP file that comes with the CS-F3G CLON-
ING SOFTWARE for available settings.
19
6
OTHER FUNCTIONS
