Icom IC-FR3000 Service Manual

S.=Surface mount
[TX UNIT][TX UNIT]
R45 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R50 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R51 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R52 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R53 7030003300 S.RESISTOR ERJ3GEYJ 680 V (68 Ω)
R54 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
R55 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R56 7030003240 S.RESISTOR ERJ3GEYJ 220 V (22 Ω)
R57 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R61 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R64 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R66 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R67 7030003770 S.RESISTOR ERJ3GEYJ 564 V (560 kΩ)
R68 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R69 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R70 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R71 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R76 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R77 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R78 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R79 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R80 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R81 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R83 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
R84 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R85 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R86 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R87 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R88 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R90 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R91 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R92 7030004040 S.RESISTOR ERJ3GEYJ 4R7 V (4.7 Ω)
R93 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R94 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R95 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R96 7030003530 S.RESISTOR ERJ3GEYJ 562 V (5.6 kΩ)
R97 7030003530 S.RESISTOR ERJ3GEYJ 562 V (5.6 kΩ)
R98 7030003530 S.RESISTOR ERJ3GEYJ 562 V (5.6 kΩ)
R99 7030003530 S.RESISTOR ERJ3GEYJ 562 V (5.6 kΩ)
C1 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C2 4030007130 S.CERAMIC C1608 CH 1H 101J-T
C3 4030006980 S.CERAMIC C1608 CH 1H 070D-T
C4 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C5 4030007130 S.CERAMIC C1608 CH 1H 101J-T
C6 4030006990 S.CERAMIC C1608 CH 1H 080D-T
C8 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C9 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C10 4030007010 S.CERAMIC C1608 CH 1H 100D-T
C15 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C16 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C17 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C18 4030007130 S.CERAMIC C1608 CH 1H 101J-T
C19 4030006980 S.CERAMIC C1608 CH 1H 070D-T
C20 4030007130 S.CERAMIC C1608 CH 1H 101J-T
C21 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C22 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C24 4030007130 S.CERAMIC C1608 CH 1H 101J-T
C26 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C27 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C28 4510004640
S.ELECTROLYTIC ECEV1CA470SP
C29 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C32 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C33 4510004640
S.ELECTROLYTIC ECEV1CA470SP
C34 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C35 4030006870 S.CERAMIC C1608 JB 1H 222K-T
C36 4550006390 S.TANTALUM TEMSVA 1C 335M-8L
C37 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C38 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C39 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C40 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C41 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C42 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C43 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C44 4510004630
S.ELECTROLYTIC ECEV1CA100SR
C45 4030007010 S.CERAMIC C1608 CH 1H 100D-T
C46 4030007010 S.CERAMIC C1608 CH 1H 100D-T
C47 4030007010 S.CERAMIC C1608 CH 1H 100D-T
C48 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C49 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C50 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C51 4550006250 S.TANTALUM TEMSVA 1A 106M-8L
C52 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C56 4510004630
S.ELECTROLYTIC ECEV1CA100SR
C57 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C58 4030011600 S.CERAMIC C1608 JB 1E 104K-T
C59 4030008920 S.CERAMIC C1608 JB 1H 473K-T
C60 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C61 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C65 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C67 4550002980 S.TANTALUM TEMSVA 1C 225M-8L
C68 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C69 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C72 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C73 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C74 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C75 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C76 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C77 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C78 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C79 4030006850 S.CERAMIC C1608 JB 1H 471K-T
C80 4030011600 S.CERAMIC C1608 JB 1E 104K-T
C82 4550006250 S.TANTALUM TEMSVA 1A 106M-8L
C85 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C89 4030009920 S.CERAMIC C1608 CH 1H 050B-T
C90 4030007010 S.CERAMIC C1608 CH 1H 100D-T
C91 4030009920 S.CERAMIC C1608 CH 1H 050B-T
C92 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C93 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C96 4510004630
S.ELECTROLYTIC ECEV1CA100SR
C97 4510004630
S.ELECTROLYTIC ECEV1CA100SR
C98 4510004640 S.ELECTROLYTIC ECEV1CA470SP
C99 4550000460 S.TANTALUM TESVA 1C 105M1-8L
C100 4510004630
S.ELECTROLYTIC ECEV1CA100SR
C103 4030006900 S.CERAMIC C1608 JB 1H 103K-T
C104 4030011600 S.CERAMIC C1608 JB 1E 104K-T
C105 4510004630
S.ELECTROLYTIC ECEV1CA100SR
C107 4030007130 S.CERAMIC C1608 CH 1H 101J-T
C108 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C109 4550006250 S.TANTALUM TEMSVA 1A 106M-8L
C110 4030007130 S.CERAMIC C1608 CH 1H 101J-T
C111 4030011600 S.CERAMIC C1608 JB 1E 104K-T
C112 4030007130 S.CERAMIC C1608 CH 1H 101J-T
C113 4550006250 S.TANTALUM TEMSVA 1A 106M-8L
C114 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C115 4030007130 S.CERAMIC C1608 CH 1H 101J-T
C116 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C117 4030007130 S.CERAMIC C1608 CH 1H 101J-T
C118 4030007130 S.CERAMIC C1608 CH 1H 101J-T
C119 4550000460 S.TANTALUM TESVA 1C 105M1-8L
C120 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C121 4030007000 S.CERAMIC C1608 CH 1H 090D-T
C122 4550006250 S.TANTALUM TEMSVA 1A 106M-8L
J3 6510022590 S.CONNECTOR 22FMN-BMTTR-A-TBT
J4 6510022800 S.CONNECTOR B10B-PH-SM3-TB
W1 9018970060 WIRE 62/99/070/C24/C31
W2 7030003860 S.JUMPER ERJ3GE JPW V
W3 7030003860 S.JUMPER ERJ3GE JPW V
W4 7030003860 S.JUMPER ERJ3GE JPW V
W5 7030003860 S.JUMPER ERJ3GE JPW V
WS1 8970024070 FX2368 1.5D COAXIAL TUBE (1)/TX
EP1 0910056155 PCB B 5660E
5 - 12
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
