Icom IC-FR3000 - Page 57

9 - 12
JACK1 UNIT
¡BOTTOM VIEW
JACK2 UNIT
¡BOTTOM VIEW
to PA UNIT
EP2
to PA UNIT
EP1
PS 0VPS 15V
BATTERY
–
PS 15V
BATTERY
+
PS 0V
to LOGIC UNIT J10
AF GND DISC OUT DC GND AF OUT AF GND E MODG E MOD2 E MOD3 E MODG E DTCS E MODG RSSI
131
J3
+E15V
¡BOTTOM VIEW
REG UNIT
The combination of this page and the previous page
shows the unit layout in the same configuration as the
actual P.C. Board.
