Icom IC-FR3000 - Page 99

S.=Surface mount
[RX UNIT][LOGIC UNIT]
W4 8900009230 CABLE OPC-908 (P=1 N=10 L=60)
W5 8900008740 CABLE OPC-867 (P=1 N=24 L=60)
W7 7030003860 S.JUMPER ERJ3GE JPW V
W8 7030007150 S.JUMPER MCR50JZHJ JPW
W10 8900009270 CABLE OPC-912 (P=1 N=22 L=70)
W11 8900009270 CABLE OPC-912 (P=1 N=22 L=70)
W12 7030003860 S.JUMPER ERJ3GE JPW V
W13 7030003860 S.JUMPER ERJ3GE JPW V
W14 7030003860 S.JUMPER ERJ3GE JPW V
W15 7030003860 S.JUMPER ERJ3GE JPW V
W16 7030003860 S.JUMPER ERJ3GE JPW V
W17 7030003860 S.JUMPER ERJ3GE JPW V
W18 7030003860 S.JUMPER ERJ3GE JPW V
W19 7030003860 S.JUMPER ERJ3GE JPW V
W20 7030003860 S.JUMPER ERJ3GE JPW V
EP1 0910056104 PCB B 5654D
EP2 6910014900 BEAD FRC-50-12-6.5
EP3 6910014890 E.OTHER FRC-WC1
IC1 1190000450 S.IC GN2011-Q (TX)
IC2 1110003490 S.IC TA31136FN (D,EL)
IC3 1180000420 S.IC TA78L05F (TE12R)
IC4 1140005990 S.IC MB15A02PFV1-G-BND-ER
IC5 1110002750 S.IC TA75S01F (TE85R)
IC6 1180000420 S.IC TA78L05F (TE12R)
IC7 1180000430 S.IC TA78L06F (TE12L)
Q1 1530003820 S.TRANSISTOR 2SC5337QS-T1
Q3 1560000670 S.FET 2SK1771 (TE85R)
Q6 1530001950 S.TRANSISTOR 2SC2712-GR (TE85R)
Q7 1530001950 S.TRANSISTOR 2SC2712-GR (TE85R)
Q8 1530002920 S.TRANSISTOR 2SC4226-T1 R25
Q9 1530003270 S.TRANSISTOR 2SC4703-T2 SF
Q14 1530002920 S.TRANSISTOR 2SC4226-T1 R25
Q15 1520000270 S.TRANSISTOR 2SB1182 TL Q
Q16 1530002060 S.TRANSISTOR 2SC4081 T106 R
Q18 1560000540 S.FET 2SK880-Y (TE85R)
Q19 1590000440 S.TRANSISTOR DTA143ZUA T106
Q20 1510000510 S.TRANSISTOR 2SA1576A T106R
Q21 1530002060 S.TRANSISTOR 2SC4081 T106 R
D1 1750000070 S.DIODE 1SS226 (TE85R)
D3 1720000640 S.VARICAP 1SV284 (TPH3)
D4 1720000640 S.VARICAP 1SV284 (TPH3)
D6 1720000640 S.VARICAP 1SV284 (TPH3)
D7 1720000640 S.VARICAP 1SV284 (TPH3)
D15 1750000140 S.DIODE 1SS268 (TE85R)
D16 1750000140 S.DIODE 1SS268 (TE85R)
FI1 2030000201 S.MONOLITH FL-349A (70.00 MHz)
FI5 2020001030 CERAMIC CFWLA455KGFA-B0
FI6 2020001040 CERAMIC CFWLA455KEFA-B0
X1 6070000150
S.DISCRIMINATOR CDBCB455KCAY24-R0
X2 6050011470 XTAL CR-729 (69.545 MHz)
X3 6050011480 S.XTAL CR-732 (12.800 MHz)
L1 6200007670 S.COIL LQW2BHN10NJ01L
L2 6200010290 S.COIL C6328A-22NG-A
L3 6200010290 S.COIL C6328A-22NG-A
L4 6200007700 S.COIL LQW2BHN22NJ01L
L6 6200010290 S.COIL C6328A-22NG-A
L7 6200010290 S.COIL C6328A-22NG-A
L8 6200010490 S.COIL 458DB-1011=P3
L9 6200010490 S.COIL 458DB-1011=P3
L10 6200010490 S.COIL 458DB-1011=P3
L11 6200008730 S.COIL ELJND R10J 0.1U
L14 6200005510 S.COIL ELJND R27J-F
L20 6200010300 S.COIL ELJND R68JF 0.68U
L21 6200007230 S.COIL LQW2BHN15NJ01L
L22 6200007710 S.COIL LQW2BHN27NJ01L
L23 6200007680 S.COIL LQW2BHN12NJ01L
L24 6200007680 S.COIL LQW2BHN12NJ01L
L25 6200007230 S.COIL LQW2BHN15NJ01L
L27 6200007230 S.COIL LQW2BHN15NJ01L
L29 6200007230 S.COIL LQW2BHN15NJ01L
L30 6200007230 S.COIL LQW2BHN15NJ01L
L31 6200010300 S.COIL ELJND R68JF 0.68U
L32 6200007670 S.COIL LQW2BHN10NJ01L
L33 6200007340 S.COIL ELJND R22J 0.22U
L35 6200007820 S.COIL ELJND R33J 0.33U
L39 6200007680 S.COIL LQW2BHN12NJ01L
L40 6200010300 S.COIL ELJND R68JF 0.68U
L41 6200009940 S.COIL BLM21PG221SN1
L42 6910011690 S.COIL ACB1608M-600-T
L43 6910011690 S.COIL ACB1608M-600-T
L44 6910011690 S.COIL ACB1608M-600-T
L45 6910011690 S.COIL ACB1608M-600-T
L46 6910011690 S.COIL ACB1608M-600-T
L47 6910011690 S.COIL ACB1608M-600-T
L48 6910011690 S.COIL ACB1608M-600-T
L49 6910011690 S.COIL ACB1608M-600-T
L50 6910011690 S.COIL ACB1608M-600-T
L51 6910011690 S.COIL ACB1608M-600-T
L52 6200007680 S.COIL LQW2BHN12NJ01L
L53 6200007680 S.COIL LQW2BHN12NJ01L
