Icom IC-FR3100 Service Manual

[VARISTOR UNIT] IC-FR4000 ONLY[50PA UNIT] IC-FR4000 ONLY
C74 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C75 4030006850 S.CERAMIC C1608 JB 1H 471K-T B
C76 4030006850 S.CERAMIC C1608 JB 1H 471K-T B
C80 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C81 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C83 4030007130 S.CERAMIC C1608 CH 1H 101J-T T
C85 4030018290 S.CERAMIC ERF22X 6C2H 390J D01L T
C86 4030018450 S.CERAMIC ERF22X 6C2H 8R0D D01L T
C87 4030018430 S.CERAMIC ERF22X 6C2H 6R0D D01L [H] T
4030018450 S.CERAMIC ERF22X 6C2H 8R0D D01L [M] T
4030018540 S.CERAMIC ERF22X 6C2H 7R0D D01L [L] T
C88 4030009500 S.CERAMIC C1608 CH 1H 0R5B-T B
C89 4030009530 S.CERAMIC C1608 CH 1H 030B-T B
C90 4030006850 S.CERAMIC C1608 JB 1H 471K-T T
C91 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C93 4030006850 S.CERAMIC C1608 JB 1H 471K-T T
C94 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C95 4030006850 S.CERAMIC C1608 JB 1H 471K-T T
C96 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C97 4510007940 ELECTROLYTIC KMY25VB100 T
C98 4030011730 S.CERAMIC GRM31M2C2H101JV01L T
C99 4510007570 S.ELECTROLYTIC EEVHB1C220UR T
C100 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C101 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C102 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C103 4030011600 S.CERAMIC C1608 JB 1E 104K-T T
C104 4510007570 S.ELECTROLYTIC EEVHB1C220UR T
C105 4030006850 S.CERAMIC C1608 JB 1H 471K-T T
C106 4030006850 S.CERAMIC C1608 JB 1H 471K-T T
C107 4030006900 S.CERAMIC C1608 JB 1H 103K-T B
C108 4030006900 S.CERAMIC C1608 JB 1H 103K-T B
C109 4510007670 S.ELECTROLYTIC EEVHB1C100R T
C110 4510007670 S.ELECTROLYTIC EEVHB1C100R T
C111 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C112 4030017890 S.CERAMIC ERF22X 6C2H 101J D01L T
C113 4550006250 S.TANTALUM TEESVA 1A 106M8L T
C119 4030018170 S.CERAMIC ERF22X 6C2H 4R0C D01L [H] T
4030018410 S.CERAMIC ERF22X 6C2H 2R0C D01L
[L], [M] T
C125 4030018470 S.CERAMIC ERF22X 6C2H 220J D01L T
C126 4030018470 S.CERAMIC ERF22X 6C2H 220J D01L T
C134 4030017490 S.CERAMIC C1608 JB 1A 105K-T T
C135 4030010760 S.CERAMIC C1608 CH 1H 331J-T [L], [M] only T
J1 6510022800 S.CONNECTOR B10B-PH-SM3-TB T
J2 6510007020 CONNECTOR TMP-J01X-V6 T
J5 6510021390 CONNECTOR IMSA-9230B-1-03Z024-T T
T2 5910001000 TRANSFORMER TC-7 T
W2 7030003860 S.RESISTOR ERJ3GE JPW V T
W3 7030003860 S.RESISTOR ERJ3GE JPW V B
W4 7030003860 S.RESISTOR ERJ3GE JPW V [H] only B
W5 7030003860 S.RESISTOR ERJ3GE JPW V T
W6 7030003860 S.RESISTOR ERJ3GE JPW V T
W10 7030003860 S.RESISTOR ERJ3GE JPW V T
W11 7030003860 S.RESISTOR ERJ3GE JPW V [L], [M] only T
W12 7030003860 S.RESISTOR ERJ3GE JPW V [L], [M] only T
W13 7030003860 S.RESISTOR ERJ3GE JPW V [H] only T
W14 7030003860 S.RESISTOR ERJ3GE JPW V [L], [M] only T
EP1 6910014490 TERMINAL OP-100 M3 T
EP2 6910014490 TERMINAL OP-100 M3 T
EP3 0910056178 PCB B 5663H
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
D1 1790000720 DIODE MA29W-B T
EP1 6910012350 S.BEAD MMZ1608Y 102BT B
EP2 0910056182 PCB B 5662B
L1 6200009940 S.COIL BLM21PG221SN1 T
L2 6200009940 S.COIL BLM21PG221SN1 T
L3 6200009940 S.COIL BLM21PG221SN1 T
L4 6200009940 S.COIL BLM21PG221SN1 T
L5 6200009940 S.COIL BLM21PG221SN1 T
L6 6200009940 S.COIL BLM21PG221SN1 T
L7 6200009940 S.COIL BLM21PG221SN1 T
L8 6200009940 S.COIL BLM21PG221SN1 T
R1 7540000210 S.ABSORBER KU15N14-4063 T
R2 7540000210 S.ABSORBER KU15N14-4063 T
R3 7540000210 S.ABSORBER KU15N14-4063 T
R4 7540000210 S.ABSORBER KU15N14-4063 T
R5 7540000210 S.ABSORBER KU15N14-4063 T
R6 7540000210 S.ABSORBER KU15N14-4063 T
R7 7540000210 S.ABSORBER KU15N14-4063 T
R8 7540000210 S.ABSORBER KU15N14-4063 T
R9 7540000210 S.ABSORBER KU15N14-4063 T
R10 7540000210 S.ABSORBER KU15N14-4063 T
C1 4030007170 S.CERAMIC C1608 CH 1H 221J-T B
C2 4030007170 S.CERAMIC C1608 CH 1H 221J-T B
C3 4030007170 S.CERAMIC C1608 CH 1H 221J-T B
C4 4030007170 S.CERAMIC C1608 CH 1H 221J-T B
C5 4030007170 S.CERAMIC C1608 CH 1H 221J-T B
C6 4030007170 S.CERAMIC C1608 CH 1H 221J-T B
C7 4030007170 S.CERAMIC C1608 CH 1H 221J-T B
C8 4030007170 S.CERAMIC C1608 CH 1H 221J-T B
C9 4030007170 S.CERAMIC C1608 CH 1H 221J-T B
C10 4030007170 S.CERAMIC C1608 CH 1H 221J-T B
C11 4030007090 S.CERAMIC C1608 CH 1H 470J-T
[FR4100] only T
C12 4030007090 S.CERAMIC C1608 CH 1H 470J-T
[FR4100] only T
C13 4030007090 S.CERAMIC C1608 CH 1H 470J-T
[FR4100] only T
C14 4030006860 S.CERAMIC C1608 JB 1H 102K-T
[FR4100] only T
J1 6450001650 CONNECTOR HSJ0836-01-500 T
J2 6510016170 CONNECTOR 52018-8835 T
J3 6510022730 S.CONNECTOR S13B-PH-SM3-TB T
EP1 0910056113 PCB B 5655C [FR4000]
0910057031 PCB B 6000A [FR4100]
5 - 16
REF ORDER
DESCRIPTION M.
NO. NO.
REF ORDER
DESCRIPTION M.
NO. NO.
[L]: LOW BAND, [M]: MIDDLE BAND, [H]: HIGH BAND
REF ORDER
DESCRIPTION M.
NO. NO.
[JACK1 UNIT]
