6 - 2
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[FRONT UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
S506 2250000511 ECR RH70N1037E20-13F-2781
SP501 2510001221 SP C052SB500-14
W501 8900011800 CBL OPC-1199
W502 8900017540 CBL OPC-1785
EP501 8930065150 LCT SRCN-2781-SP-N-W (SHJ)
EP503 6910019600 SCR LM-5
EP504 6910019610 SCR LM-7 (SPACER)
S.=Surface mount
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
IC1 1110005330 S.IC NJM12904V-TE1-#ZZZB T 58.1/71.4
IC2 1110007290 S.IC AK2330P-L T 58.7/56.1
IC3 1130010100 S.IC LMX2352TMX/NOPB B 120.2/43.9
IC4 1130010100 S.IC LMX2352TMX/NOPB B 28/78.8
IC5 1110003491 S.IC TA31136FNG (D,EL) B 70.4/82.5
IC7 1110007280 S.IC NJM2716F-TE1-#ZZZB B 56.8/46.4
IC8 1130012910 S.IC AK4554VTP-E2/P B 36.2/59.9
IC9 1190002080 S.IC AD7476ARTZ-500RL7 B 49.6/46.4
IC10 1130013040 S.IC TC7WBD125AFK (T5L,F) B 46.6/49.2
IC11 1110006230 S.IC NJM2711F-TE1-#ZZZB B 53.1/35
IC12 1140013290 S.IC TMS320VC5509AZHH B 33.3/37.8
IC13 1180002590 S.REG XC6204B332MR T 80.9/21.3
IC14 1180003270 S.REG R1114Q161D-TR-F T 84.4/21.4
IC15 1180002590 S.REG XC6204B332MR T 87.8/21.3
IC17 1190001340 S.IC M62334FP 600C T 67.3/61.7
IC18 1110005771 S.IC S-80942CNMC-G9CT2G T 41.2/52.8
IC19 1180003210 S.REG NJM2831F10 B 111/26.2
IC20 1140014550 S.IC HD64F2506RFC26DV T 33.5/37.6
IC21 1140012950 S.IC 24LC512T-I/SM T 59.1/21.8
IC22 1150002042 IC RA30H1317M-121 [EUR-01]
1150002073 IC RA60H1317M-125
[USA-01], [EXP-01]
IC23 1110002751 S.IC TA75S01F (TE85R,F) T 141.7/125.1
IC25 1130008561 S.IC TC75S51F (TE85L,F) B 29/16.3
IC26 1120003070 S.IC MAX3232EIPWR T 42.7/70
IC27 1180001251 S.IC TA7808F (TE16L,Q) T 114.4/85
IC28 1110003091 IC LA4425A-E
IC29 1110002751 S.IC TA75S01F (TE85R,F) T 12/123.1
IC30 1110003390 S.IC AN8005M-(E1) T 98.3/91.4
IC31 1130011760 S.IC CD4094BPWR T 8.1/45.2
IC32 1130013360 S.IC AT25F2048N-10SU-2.7SL383 B 8.9/36.1
IC34 1110005340 S.IC NJM12902V-TE1-#ZZZB B 12.2/58.2
IC35 1140013200 S.IC CD4053BPWR B 20.6/58.2
IC36 1110005330 S.IC NJM12904V-TE1-#ZZZB B 27.8/55.4
IC37 1120002830 S.IC NJM2125F-TE1-#FZZB T 56.6/66.7
IC38 1110006380 S.IC LM2904PWR T 114.1/23.8
IC39 1180001071 S.IC TA7805F (TE16L,Q) T 101.2/24.3
IC40 1110005330 S.IC NJM12904V-TE1-#ZZZB B 50.6/57.2
IC41 1180001251 S.IC TA7808F (TE16L,Q) B 132/16.7
Q1 1590003230 S.TR UNR9113J-(TX) B 53.4/79.7
Q2 1530002851 S.TR 2SC4116-BL (TE85R,F) B 34.9/77.7
Q3 1560001360 S.FET 2SK3019 TL B 66.4/76.3
Q5 1560000541 S.FET 2SK880-Y (T5RICOM,F) B 35.7/107.1
Q7 1530002601 S.TR 2SC4215-O (TE85R,F) B 73/92.9
Q8 1560000541 S.FET 2SK880-Y (T5RICOM,F) B 89.5/46
Q9 1560001360 S.FET 2SK3019 TL B 39.6/103.6
Q10 1530002851 S.TR 2SC4116-BL (TE85R,F) B 89.5/43.5
Q11 1530002851 S.TR 2SC4116-BL (TE85R,F) B 30.6/104.2
Q12 1590003230 S.TR UNR9113J-(TX) B 66.1/100.3
Q13 1530002851 S.TR 2SC4116-BL (TE85R,F) B 84.7/43.5
Q14 1530002851 S.TR 2SC4116-BL (TE85R,F) B 30.6/107.1
Q15 1530002851 S.TR 2SC4116-BL (TE85R,F) B 96.9/44.4
Q16 1530002851 S.TR 2SC4116-BL (TE85R,F) T 35.2/108.3
Q19 1530002601 S.TR 2SC4215-O (TE85R,F) B 63.2/106.8
Q20 1530002920 S.TR 2SC4226-T1 R25 B 39.9/123.1
Q21 1530002920 S.TR 2SC4226-T1 R25 B 39.6/114.5
Q22 1530002920 S.TR 2SC4226-T1 R25 B 95.2/64.3
Q23 1530002920 S.TR 2SC4226-T1 R25 B 95.2/54.5
Q24 1530003311 S.TR 2SC5107-O (TE85R,F) B 100.6/58.6
Q25 1530003311 S.TR 2SC5107-O (TE85R,F) B 44.9/117.4
Q26 1590001400 S.TR XP1214 (TX) B 40.5/117.8
Q27 1590001400 S.TR XP1214 (TX) B 96/59.6
Q28 1590003290 S.TR UNR9213J-(TX) B 93.3/59.6
Q29 1590003290 S.TR UNR9213J-(TX) T 57.2/41.9
Q30 1590003290 S.TR UNR9213J-(TX) B 37.8/117.8
Q31 1590003230 S.TR UNR9113J-(TX) T 57.2/39.8
Q32 1530003311 S.TR 2SC5107-O (TE85R,F) B 46.2/111.7
Q33 1530003311 S.TR 2SC5107-O (TE85R,F) B 101.9/53
Q34 1530003311 S.TR 2SC5107-O (TE85R,F) B 46.2/123.1
Q35 1530003311 S.TR 2SC5107-O (TE85R,F) B 101.9/64.4
Q36 1580000731 S.FET 3SK293 (TE85L,F) B 48.3/136.6
Q37 1530003311 S.TR 2SC5107-O (TE85R,F) B 132.4/84.5
Q38 1530002680 S.TR 2SC3357-T1 B 139.5/86
Q39 1560000841 S.FET 2SK1829 (TE85R,F) B 54.2/142.5
Q40 1590001190 S.TR XP6501-(TX) .AB T 101.6/87.4
Q41 1520000460 S.TR 2SB1132 T100 R T 101.6/82.8
Q42 1590003290 S.TR UNR9213J-(TX) T 13.3/67.6
Q43 1590003290 S.TR UNR9213J-(TX) T 137.3/125
Q44 1590003290 S.TR UNR9213J-(TX) T 114.3/80.1
Q45 1540000550 S.TR 2SD1664 T100Q T 118.4/75.2
Q46 1530002851 S.TR 2SC4116-BL (TE85R,F) T 137.3/120.2
Q48 1510000920 S.TR 2SA1577 T106 Q T 101.5/77.8
Q49 1590003290 S.TR UNR9213J-(TX) T 102.2/73.7
Q52 1590003290 S.TR UNR9213J-(TX) T 10.9/131.6
Q53 1590003290 S.TR UNR9213J-(TX) T 10.9/129.6
Q56 1590003321 S.FET TPC6103 (TE85L,F) T 7.6/132.6
Q57 1550000100 S.FET 2SJ377 (TE16L1,NQ) T 123.3/99.6
Q58 1590003290 S.TR UNR9213J-(TX) T 129.4/102.2
Q59 1590000990 S.TR DTC363EK T146 T 7.6/127.6
Q61 1530002851 S.TR 2SC4116-BL (TE85R,F) T 6.8/118.4
Q62 1540000441 S.TR 2SD1619T-TD-E T 118.4/18.6
Q63 1560000990 S.FET PMBFJ310 B 66.3/110
Q64 1560000990 S.FET PMBFJ310 B 63.4/110
Q65 1530003311 S.TR 2SC5107-O (TE85R,F) B 59.6/123.7
Q66 1590003290 S.TR UNR9213J-(TX) B 94.9/4.7
Q67 1590003290 S.TR UNR9213J-(TX) B 124.9/4.7
Q68 1590003290 S.TR UNR9213J-(TX) B 109.9/4.7
Q69 1590003290 S.TR UNR9213J-(TX) T 9.5/53.3
Q70 1590003230 S.TR UNR9113J-(TX) T 9.5/51
Q71 1560000990 S.FET PMBFJ310 B 60.5/110
Q72 1530002851 S.TR 2SC4116-BL (TE85R,F) B 107/26.3
