6 - 3
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
D1 1750001070 S.DIO DAN235ETL B 57.3/78.6
D2 1750001070 S.DIO DAN235ETL B 50/79.7
D3 1790001621 S.DIO 1SV308 (TPL3,F) B 69.3/94.8
D4 1790001621 S.DIO 1SV308 (TPL3,F) B 69.3/92.2
D5 1720000641 S.VCP 1SV284 (TPH3,F) B 29.9/120.1
D7 1720000791 S.VCP HVC321B1TRF-E B 28.6/125.1
D8 1720000791 S.VCP HVC321B1TRF-E B 26.5/113.3
D9 1720000791 S.VCP HVC321B1TRF-E B 84.7/59.8
D10 1720000791 S.VCP HVC321B1TRF-E B 86.4/51.2
D11 1790001621 S.DIO 1SV308 (TPL3,F) B 63.5/103.1
D12 1790001621 S.DIO 1SV308 (TPL3,F) B 62.4/101.1
D13 1720000791 S.VCP HVC321B1TRF-E B 84.9/61.8
D14 1720000791 S.VCP HVC321B1TRF-E B 84.4/52
D15 1720000791 S.VCP HVC321B1TRF-E B 28.6/122.6
D16 1720000791 S.VCP HVC321B1TRF-E B 26.5/114.6
D17 1720000641 S.VCP 1SV284 (TPH3,F) B 83.5/63.5
D18 1720000471 S.VCP 1SV239 (TPH3,F) B 96.3/66.7
D19 1750000520 S.DIO DAN222TL T 59.6/39.8
D20 1790001260 S.DIO MA2S077-(TX) T 39.5/57.9
D21 1750001610 S.VCP HVC365TRF-E B 63/139.4
D22 1750001610 S.VCP HVC365TRF-E B 59.8/136.7
D23 1750001610 S.VCP HVC365TRF-E B 63/136.7
D24 1750001610 S.VCP HVC365TRF-E B 59.8/139.4
D25 1750000370 S.DIO DA221 TL B 46.5/142.5
D26 1790001250 S.DIO MA2S111-(TX) B 48.3/142.5
D27 1790001250 S.DIO MA2S111-(TX) B 58.3/142.5
D28 1750001610 S.VCP HVC365TRF-E
[USA-01], [EXP-01] B 37.6/138.4
D29 1750001610 S.VCP HVC365TRF-E
[USA-01], [EXP-01] B 37.6/135.7
D30 1720000471 S.VCP 1SV239 (TPH3,F) B 95.6/56.8
D31 1750001610 S.VCP HVC365TRF-E B 34.4/135.7
D32 1750001610 S.VCP HVC365TRF-E B 34.4/138.4
D35 1750000351 S.DIO 1SV252 (TE85L,F) B 143.7/92.9
D36 1750001080 S.DIO RB886G T2R T 144.4/120.2
D37 1750001080 S.DIO RB886G T2R T 145.6/120.2
D38 1750001360 S.DIO L709CER (9401) B 84.7/134
D39 1750000581 S.DIO 1SV307 (TPH3,F) B 36/144.8
D40 1750000370 S.DIO DA221 TL T 114.3/77.8
D42 1720000641 S.VCP 1SV284 (TPH3,F) B 26.5/112
D44 1710001061 DIO L407CDB
D45 1790001211 S.DIO 1SS375-TL-E B 83.8/128
D46 1750000520 S.DIO DAN222TL T 13.3/131.1
D47 1750000520 S.DIO DAN222TL T 13.2/129.1
D48 1790001211 S.DIO 1SS375-TL-E B 119.6/144.5
D49 1790001211 S.DIO 1SS375-TL-E B 139.5/133.2
D51 1790001250 S.DIO MA2S111-(TX) T 10.5/127.1
D53 1790001810 S.VSR AVR-M1005C080MTABB T 32.5/11.7
D55 1790001810 S.VSR AVR-M1005C080MTABB T 30.5/11.7
D56 1790001810 S.VSR AVR-M1005C080MTABB T 36.6/11.7
D59 1790000700 DIO DSA3A1
D61 1750000520 S.DIO DAN222TL T 118.4/14.7
D62 1750000431 S.DIO HSB88WSTR-E B 68.3/123.3
D63 1790001250 S.DIO MA2S111-(TX) B 34.2/20.8
D64 1750000370 S.DIO DA221 TL T 63.2/93.9
D65 1750000370 S.DIO DA221 TL T 65.2/93.9
D66 1750000370 S.DIO DA221 TL T 67.2/93.9
D67 1750000370 S.DIO DA221 TL T 61.9/105.9
D68 1750000370 S.DIO DA221 TL T 59.9/105.5
D69 1750000370 S.DIO DA221 TL T 69.2/93.9
D70 1750000370 S.DIO DA221 TL T 71.2/93.9
D71 1750000370 S.DIO DA221 TL T 69.1/109.5
D72 1750000370 S.DIO DA221 TL T 71.2/109.5
D73 1750000370 S.DIO DA221 TL T 73.3/109.5
D74 1750000370 S.DIO DA221 TL T 75.3/109.5
D75 1790001250 S.DIO MA2S111-(TX) B 41/38.6
D76 1790001250 S.DIO MA2S111-(TX) B 26.4/41.3
D77 1790001250 S.DIO MA2S111-(TX) B 49.2/29.9
D78 1730002360 S.ZEN MA8062-M (TX) B 52.3/29.9
D79 1720000641 S.VCP 1SV284 (TPH3,F) B 83.1/52
FI1 2020001520 CER CFWLA450KFFA-B0
FI2 2020001460 CER CFWLA450KHFA-B0
FI3 2030000500 S.MLH FL-401 (46.35 MHz) B 72/101
FI4 2030000670 S.MLH FL-420 (46.35 MHz) B 63.4/91.1
FI5 2040001440 S.LC NFE31PT152Z1E9L T 116.5/108.3
FI6 2040001440 S.LC NFE31PT152Z1E9L T 116.5/111.5
FI7 2040001440 S.LC NFE31PT152Z1E9L T 116.5/114.6
X1 6050012380 S.XTL CR-826 (15.3 MHz) B 128.6/45.3
X2 6050012380 S.XTL CR-826 (15.3 MHz) B 35.6/72.3
X3 6070000300 S.DCR JTBM450CX24 <JJE> B 63.5/83.5
X4 6050012350 S.XTL CR-817 (12.288 MHz) B 52.8/38.2
X5 6050012680 S.XTL CR-858 (SMD-49/18.432MHZ) T 46.9/52.7
L1 6200004660 S.COL MLF1608A 1R8K-T B 115.5/39.2
L2 6200004660 S.COL MLF1608A 1R8K-T B 23.6/82.4
L3 6200004480 S.COL MLF1608D R82K-T B 39.4/79.3
L4 6200003540 S.COL MLF1608D R22K-T B 36.9/76.9
L5 6200005691 S.COL ELJRE 18NGFA B 102.7/45.6
L6 6200005691 S.COL ELJRE 18NGFA B 47.3/101.1
L7 6200005661 S.COL ELJRE 10NGFA B 44/99.1
L8 6200007120 S.COL ELJND 1R0J B 27/124.1
L9 6200007120 S.COL ELJND 1R0J B 27/120.8
L10 6200007120 S.COL ELJND 1R0J B 25.9/116.8
L11 6200007120 S.COL ELJND 1R0J B 82.5/61.4
L12 6200007120 S.COL ELJND 1R0J B 83.1/49.9
L13 6200007120 S.COL ELJND 1R0J B 28.7/111.6
L14 6200007120 S.COL ELJND 1R0J B 85.3/66.4
L15 6200013220 S.COL C6342A-R13G-A B 88.6/54.6
L16 6200010600 S.COL C6342A-67NG-A B 33.8/122.7
S.=Surface mount
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
L17 6200007120 S.COL ELJND 1R0J B 28.7/116.8
L18 6200009910 S.COL C6342A-88NG-A B 88.8/63.9
L19 6200007120 S.COL ELJND 1R0J B 83.5/66.4
L20 6200007120 S.COL ELJND 1R0J B 30.2/124.7
L21 6200009910 S.COL C6342A-88NG-A B 33.1/114.4
L22 6200003550 S.COL MLF1608A 4R7K-T B 73.4/109.9
L23 6200005011 S.COL NLV25T-100J B 60.5/113.3
L24 6200010740 S.COL C2520C-R27G-A B 70/109.1
L25 6200007120 S.COL ELJND 1R0J B 97.4/62.5
L26 6200007120 S.COL ELJND 1R0J B 98/56.1
L27 6130002961 S.COL #617DB-1327=P3 B 68.3/117
L28 6200007001 S.COL ELJRE 82NGFA B 62.3/123.6
L29 6200006981 S.COL ELJRE R10GFA B 102.6/58.6
L30 6200006981 S.COL ELJRE R10GFA B 46.9/117.4
L31 6200002861 S.COL NLV25T-4R7J T 91.2/20
L32 6130002961 S.COL #617DB-1327=P3 B 68.3/128.7
L33 6200005691 S.COL ELJRE 18NGFA B 47.3/109.2
L34 6200005721 S.COL ELJRE 33NGFA B 61.1/117.5
L35 6200005691 S.COL ELJRE 18NGFA B 102.7/50.5
L36 6200007001 S.COL ELJRE 82NGFA B 44.3/123.1
L37 6200005721 S.COL ELJRE 33NGFA B 61.1/120.1
L38 6200007001 S.COL ELJRE 82NGFA B 100/64.4
L39 6200010610 S.COL C6342A-50NG-A B 67.4/138.5
L41 6200010610 S.COL C6342A-50NG-A B 53.7/136.7
L42 6200006981 S.COL ELJRE R10GFA B 134.5/84.5
L43 6200006671 S.COL ELJRE 68NGFA B 138.9/90.1
L44 6200010610 S.COL C6342A-50NG-A
[USA-01], [EXP-01] B 41.9/137.3
L45 6200005741 S.COL ELJRE 47NGFA B 142.8/87.4
L46 6200005741 S.COL ELJRE 47NGFA B 142.8/90.1
L47 6200010610 S.COL C6342A-50NG-A B 29.9/136.7
L48 6200007750 S.COL LQW2BHN56NJ03L
[USA-01], [EXP-01] B 33.3/141.2
6200010000 S.COL C2012C-56NG-A [EUR-01] B 33.3/141.2
L49 6200010050 S.COL AS080547-47N B 97.2/119.2
L50 6200007750 S.COL LQW2BHN56NJ03L B 85.5/137.4
L51 6200007750 S.COL LQW2BHN56NJ03L
[USA-01], [EXP-01] B 25.1/142.9
6200010000 S.COL C2012C-56NG-A [EUR-01] B 25.1/142.9
L52 6200010420 S.COL FHW1210HC 1R0JGT <JJE> B 86.6/122.3
L53 6200010050 S.COL AS080547-47N B 90.1/135.3
L55 6200010050 S.COL AS080547-47N B 107.6/135
L56 6200010050 S.COL AS080547-47N B 115.2/138.8
L57 6200010050 S.COL AS080547-47N B 143.7/140.9
L58 6200002861 S.COL NLV25T-4R7J T 55.4/37.5
L59 6200010420 S.COL FHW1210HC 1R0JGT <JJE> B 147.1/146.2
L60 6200010420 S.COL FHW1210HC 1R0JGT <JJE> B 24.5/147
L61 6200002961 S.COL NLV32T-4R7J T 118.4/23.8
L62 6200013530 S.COL MLF2012E 100K-T B 83.7/56.6
L63 6200010000 S.COL C2012C-56NG-A B 72.3/137.8
L64 6200007120 S.COL ELJND 1R0J B 81.8/54.9
L65 6200007120 S.COL ELJND 1R0J B 41.7/120.7
L66 6200007120 S.COL ELJND 1R0J B 42.4/115.2
L68 6200003960 S.COL MLF1608A 1R0K-T B 140.7/94.7
L69 6200005661 S.COL ELJRE 10NGFA B 102.7/42.3
R1 7030005310 S.RES ERJ2GEJ 124 X (120 k) T 54.9/64.1
R2 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 58.7/61.7
R3 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 62.4/69.6
R4 7030007340 S.RES ERJ2GEJ 153 X (15 k) B 57.3/80.1
R6 7030007300 S.RES ERJ2GEJ 332 X (3.3 k) T 9.5/57.1
R7 7030010040 S.RES ERJ2GEJ-JPW T 61.6/66.3
R8 7030005160 S.RES ERJ2GEJ 105 X (1 M) T 24.9/70.4
R9 7030005160 S.RES ERJ2GEJ 105 X (1 M) T 25.8/70.4
R10 7030005160 S.RES ERJ2GEJ 105 X (1 M) T 26.7/70.4
R12 7510001730 S.TMR ERTJOEP 473J B 129.1/49.3
R13 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 130.8/49.3
R15 7030007340 S.RES ERJ2GEJ 153 X (15 k) B 54.5/78.3
R17 7030004980 S.RES ERJ2GEJ 101 X (100) T 19.8/68.8
R18 7030007340 S.RES ERJ2GEJ 153 X (15 k) B 55.3/79.2
R20 7030009150 S.RES ERJ2GEJ 824 X (820 k) T 56.1/63.5
R22 7410001130 S.ARY EXB28V102JX B 122.6/39
R23 7410001130 S.ARY EXB28V102JX B 23.1/76.3
R24 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 115.5/42.2
R25 7030004970 S.RES ERJ2GEJ 470 X (47) B 65.3/79.4
R26 7030010040 S.RES ERJ2GEJ-JPW T 57.7/64.5
R27 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 57.8/51
R29 7030007570 S.RES ERJ2GEJ 122 X (1.2 k) B 38.5/75.9
R30 7030007340 S.RES ERJ2GEJ 153 X (15 k) B 52.8/81.1
R32 7030007340 S.RES ERJ2GEJ 153 X (15 k) B 51.2/78.3
R33 7030007340 S.RES ERJ2GEJ 153 X (15 k) B 48.4/78.2
R34 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 27.1/68.1
R35 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 28/68.1
R36 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 28.9/68.1
R38 7030005230 S.RES ERJ2GEJ 334 X (330 k) T 27.6/70.4
R39 7030005230 S.RES ERJ2GEJ 334 X (330 k) T 28.6/70.4
R40 7030005230 S.RES ERJ2GEJ 334 X (330 k) T 29.5/70.4
R41 7030005110 S.RES ERJ2GEJ 224 X (220 k) B 68.2/78.2
R42 7030006610 S.RES ERJ2GEJ 394 X (390 k) B 34.4/75.5
R43 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) B 62.8/77.3
R44 7030005030 S.RES ERJ2GEJ 152 X (1.5 k) B 71.4/78.2
R45 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 64.6/75.5
R46 7030005000 S.RES ERJ2GEJ 471 X (470) T 52.7/57.1
R47 7030005720 S.RES ERJ2GEJ 563 X (56 k) B 64.6/76.4
R48 7030005030 S.RES ERJ2GEJ 152 X (1.5 k) B 62.8/76.4
R49 7030010040 S.RES ERJ2GEJ-JPW T 55.6/57.3
R52 7030004980 S.RES ERJ2GEJ 101 X (100) B 34.1/56.4
R53 7030005210 S.RES ERJ2GEJ 822 X (8.2 k) B 16.8/57.6
R54 7030005000 S.RES ERJ2GEJ 471 X (470) B 19.4/64.3
R56 7030004970 S.RES ERJ2GEJ 470 X (47) B 121.9/50.4
R57 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 62.8/75.5
R58 7030008290 S.RES ERJ2GEJ 183 X (18 k) B 56.5/49
R59 7030008290 S.RES ERJ2GEJ 183 X (18 k) B 57.4/49
