SET MODE
5
D Self check function “SC”
The self check function checks the transceiver conditions by
itself, and informs you in case a problem is found. Self check
automatically and quickly runs through its diagnostic steps
each time the radio is turned ON. Afterwards, the radio
switches to normal operation mode.
• Temperature : Outside of –35°C to +80°C (approx.)
• Connected battery voltage
When error messages as shown below are displayed, see
troubleshooting for advice. (p. 21)
D Battery voltage indicator “bt”
This function controls display or non-display settings of the
connected battery pack’s voltage when the power is ON.
•
The voltage of the connected battery pack is displayed for 2 sec.
after power is turned ON.
D Signal strength indicator “Sl”
The signal strength indicator displays received signal
strength as “S-meter”. This function is convenient to check
the signal strength visually.
•
The strength is displayed at 4 steps.
• The antenna
mark and 3 bars appear
when receiving
strong
signals.
• The antenna mark only appears when receiving no signal.
Push
Self check OFF (default)
Self check ON
Temperature error
Battery voltage error
Push
Battery voltage
indication OFF
(default)
Battery voltage
indication ON
Push
Signal strength
indication OFF
(default)
Signal strength
indication ON
