27
15
SPECIFICATIONS AND OPTIONS
■ Specifications
•GENERAL
•Frequency coverage : Transmit 156–157.5 MHz
Receive 156–163 MHz
•Mode : FM (16K0G3E)
•Channel spacing : 25 kHz
•Current drain (at 7.4 V) : TX at 5 W 1.5 A max.
Max.audio 200 mA max.
Power saved 20 mA typ.
•Power supply requirement : Icom battery pack; BP-215
•Frequency stability :
±10 ppm
(–20°C to +60°C; –4°F to +140°F)
•Dimensions (with BP-215) : 52.5(W)×129(H)×30(D) mm
(Projections not included) 2
1
⁄16(W)×5
3
⁄32(H)×1
3
⁄16(D) in
•Weight (with BP-215) : 280g (9.9 oz)
•TRANSMITTER
•Output power : 5 W, 1 W and 0.5 W
•Modulation system :
Variable reactance frequency modulation
•Max. frequency deviation : ±5.0 kHz
•Spurious emissions : Less than –65 dB
•RECEIVER
•Receive system :
Double conversion superheterodyne
•Sensitivity (12 dB SINAD) : Less than 0.35 µV
•Squelch sensitivity : Less than 0.35 µV (at threshold)
•
Intermodulation rejection ratio
: 70 dB typical
•
Spurious response rejection ratio
: 70 dB typical
•Adjacent channel selectivity : 70 dB typical
•Audio output power : 350 mW typical at 10% distortion
with an 8 Ω load
■ Options
•AD-95 BATTERY CHARGER + BC-122A/E AC ADAPTER
Used for regular charging of battery pack. The same as supplied
with the transceiver. Charging time: approx. 8 hours
•BP-215 BATTERY PACK
Long life, Li-ion battery pack allowing 12–14 hrs.* operation. The
same as supplied with the transceiver. 7.4 V/1600 mAh.
*Tx:Rx:Stand-by=5:5:90
•CP-17L CIGARETTE LIGHTER CABLE
Connects to a ship’s or vehicle’s cigarette lighter socket (12 V) for
use with the AD-95.
•FA-S57V FLEXIBLE ANTENNA
Same as supplied with the transceiver.
•HM-125 SPEAKER-MICROPHONE
Full-sized waterproof (JIS grade 7; 1m/30 min.) speaker-microphone
including alligator type clip to attach to your shirt or collar, etc.
•OPC-515L DC POWER CABLE
Used for charging a battery pack via an AD-95 with external power
supply.
•UT-98 VOICE SCRAMBLER UNIT
Ensures private communication. 128 scrambling codes are avail-
able. The scrambling system is not compatible with UT-112. Not
available in some countries. Version 02 (#02) only can be used with
the IC-M1V/M1EURO V (version 01 not compatible).
•UT-112 VOICE SCRAMBLER UNIT
Ensures private communication. 32 scrambling codes are available.
The scrambling system is not compatible with UT-98. Not available
in some countries.
All stated specifications are subject to change without notice or obligations.
