Icom IC-M2A - Battery Charging; Optional Battery Chargers

19
7
BATTERY CHARGING
D Rapid charging with the BC-121N+AD-103
The optional BC-121N allows up to 6 battery packs to be
charged simultaneously. The following are additionally re-
quired.
• Six AD-103.
• An AC adapter (BC-124) or the DC power cable (OPC-656).
AC adapter
(purchased
separately)
AD-103 charger
adapters are installed
in each slot.
BP-224
IC-M2A
DC power cable
(Connect with the DC power supply;
13.8 V/at least 7 A)
■ Optional battery chargers
D Rapid charging with the BC-119N+AD-103
The optional BC-119N provides rapid charging of battery
packs. The following are additionally required.
• AD-103
• An AC adapter (may be supplied with BC-119N depending
on version).
AC adapter
(Not supplied with some
versions.)
OPC-515L or
CP-17L
AD-103 charger
adapter is installed
in BC-119N.
BP-224
IC-M2A
