5 - 3
NOTE: The above screen is an example only.
Each transceiver has its own specific values for each setting.
q: Adjustment condition
w: Reference frequency
e: Transmit output power
r: FM deviation
t: Microphone sensitivity
y: Receive sensitivity
u: Squelch level
q
w
e
r
t
u
y
I/O check button
*; DO NOT put the cursor on these items and push the [ENTER] key. Otherwise
, these items
will not be adjusted properly.
(*)
(*)
(*)
• ADJUSTMENT SOFTWARE SCREEN
