6 DSC OPERATION
New2001
DD
Programming Group ID
q Push [MENU] to enter the DSC menu.
w Push [▲] or [▼] to select “Set up,” and push [ENT].
e Push [▲] or [▼]
to select “Add:Group ID,” push
[ENT]
.
r Push [▲] or [▼]
to s
et the Group ID.
• 1st digit ‘0’ is fixed for a group ID.
• Push [CH•DUAL] or [16•C] to move the cursor forward or back-
ward, respectively.
• Push [SCAN•TAG] to clear the ID.
• Push [CLR] to cancel and exit the condition to the set up menu.
• “Full ID” appears when 100 DSC address IDs are already
set.
t After input the 8-digit code, push [ENT] to input up to a 10-
character ID name using [▲] or [▼].
• Push [CH•DUAL] or [16•C] to move the cursor forward or back-
ward, respectively.
• Push [SCAN•TAG] to clear the ID name.
• Push [CLR] to cancel and exit the condition to the set up menu.
y Push [ENT] to program.
u Push [CLR] or [▼] to select “Exit,” push [ENT].
• Returns to the DSC menu.
• Repeat again to return to the normal operation condition.
