Icom IC-M423GE

92
11
SPECIFICATIONS AND OPTIONS
• Intermodulation rejection ratio:
FM IC-M423/IC-M423G/IC-M423GE
More than 68 dB
IC-M424/IC-M424G More than 70 dB
IC-M423
(CHN/AUS version) More than 70 dB
DSC More than 68 dBµ emf (1% BER)
• Spurious response rejection ratio:
FM More than 70 dB
DSC More than 73 dBµ emf (1% BER)
• Adjacent channel selectivity:
FM More than 70 dB
DSC More than 73 dBµ emf (1% BER)
• Audio output power:
IC-M423/IC-M423G/IC-M423GE
More than 10 W at 10% distortion
into a 4 Ω load
IC-M424/IC-M424G 10 W at 10% distortion into a 4 Ω load
IC-M423 (CHN/AUS version) 10 W at 10% distortion into a 4 Ω load
D GPS (IC-M423GE)
• Frequency: 1575.42 MHz
• Channel: 66 ch
D Dimensions
■ Options
• MB-132 flush mount kit
To mount the transceiver to a panel.
• MA-500TR/MA-510TR*
class b ais transponder
To transmit individual DSC calls to a selected AIS targets.
* Unreleased as of April 2020.
• HM-195 commandmicIV™
External microphone-type controller. Provides optional
intercom operation. A 6 m (20 ft) microphone cable and
mounting base are included.
HM-195B: Black
HM-195SW: Super White
• OPC-1541
microphone extension cable
A 6 m (20 ft) microphone extension cable for the optional
HM-195
commandmicIV™. Up to two OPC-1541s can be
connected. Maximum usable length is 18 m (60 ft).
82 (3.2)
119.9 (4.7)
164.1 (6.5)
25.3
(1)
109.7 (4.3)
61.4 (2.4)
Unit: mm (inch)
180 (7.1)
■ Specifications
D Receiver (continued)
