Icom IC-M506

5-10
REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[CONNECT UNIT]
C1 4030016790 S.CER C1005 JB 1E 103K-T B 7.8/13.5
J1 6510030290 CON ICOM-CCBPM08MCC <ODS>
J2 6510025142 S.CON 10FLT-SM2-TB(LF)(SN)(M) B 8.5/18.3
EP2 6910019100 S.BEA MPZ1608S101AT B 6.3/13.1
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
Eqv.= This component is equivalent to the REF No. component listed above, and
may be substituted on parts orders and repairs.
REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
• NMEA2000 UNIT (UX-232)
[MAIN UNIT]
IC1 1140017121 S.IC STM32F103RCT6(EX3572A1)
<TOMEN> T 22.5/33.5
IC2 1110007780 S.IC NJU7704F3-28A-TE1-#ZZZH T 24.5/12.2
IC3 1130016110 S.IC TC7WH14FK(TE85LF) *0 T 11.5/12.2
Q1 1510001090 S.TRA KTA2015Y-RTK/P T 24.5/8.2
Q2 1590004070 S.TRA LDTC144EET1G <SLVJ> T 23.3/4.4
Q3 1510001151 S.TRA L2SA1576AST1G <SLVJ> T 10.3/8.2
Q4 1530004140 S.TRA L2SC4081RT1G <SLVJ> T 11.5/4.3
D1 1750001810 S.DIO L1SS400T1G <SLVJ> T 9.6/2.8
X1 6050013880 S.XTA CR-984 (TQU5594) 8.0 MHz T 21.9/22.1
R1 7030005050 S.RES ERJ2GEJ 103 X (10K) T 24.1/10.2
R3 7030005240 S.RES ERJ2GEJ 473 X (47K) T 22.7/7.7
R4 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 23.1/6.2
R5 7410001230 S.ARR EXB28V101JX T 19.8/14.9
R11 7030009140 S.RES ERJ2GEJ 272 X (2.7K) T 21.8/25.2
R12 7030005090 S.RES ERJ2GEJ 104 X (100K) T 11.2/16.1
R13 7030005050 S.RES ERJ2GEJ 103 X (10K) T 10.4/39.7
R14 7030005050 S.RES ERJ2GEJ 103 X (10K) T 12.8/17.9
R15 7030005090 S.RES ERJ2GEJ 104 X (100K) T 12.8/18.8
R16 7030005090 S.RES ERJ2GEJ 104 X (100K) T 30.8/35.4
R17 7410001330 S.ARR EXB24V101JX T 17.8/14.9
R19 7030010040 S.RES ERJ2GEJ-JPW T 13.3/43.6
R21 7030005050 S.RES ERJ2GEJ 103 X (10K) T 10.0/6.3
R22 7030008290 S.RES ERJ2GEJ 183 X (18K) T 9.6/5.0
R23 7030005530 S.RES ERJ2GEJ 100 X (10) T 14.4/2.7
R24 7030008290 S.RES ERJ2GEJ 183 X (18K) T 12.2/6.8
R25 7030005240 S.RES ERJ2GEJ 473 X (47K) T 8.5/8.2
C1 4030016930 S.CER C1005 JB 1A 104K-T T 14.2/30.0
C2 4030016930 S.CER C1005 JB 1A 104K-T T 26.1/25.2
C3 4030016930 S.CER C1005 JB 1A 104K-T T 30.8/30.3
C4 4030016930 S.CER C1005 JB 1A 104K-T T 30.8/37.1
C5 4030016930 S.CER C1005 JB 1A 104K-T T 19.2/41.8
C6 4030016930 S.CER C1005 JB 1A 104K-T T 1.8/43.4
C7 4030017460 S.CER C1005 JB 1H 102K-T T 1.7/28.2
C8 4030019500 S.CER GRM21BB31A106KE18
(GRM40 B) T 27.7/9.3
C9 4030017460 S.CER C1005 JB 1H 102K-T T 26.3/8.6
C10 4030016930 S.CER C1005 JB 1A 104K-T T 13.3/11.8
C11 4030017660 S.CER C1005 CH 1H 330J-T T 20.3/18.9
C12 4030017660 S.CER C1005 CH 1H 330J-T T 23.3/18.9
C13 4030017460 S.CER C1005 JB 1H 102K-T T 14.4/1.8
C25 4030017460 S.CER C1005 JB 1H 102K-T T 16.2/10.7
J1 6510022692 S.CON 06FLT-SM2-TB(LF)(SN)(M) T 13.0/47.3
J2 6510022022 S.CON 14FLT-SM2-TB(LF)(SN)(M) T 17.5/6.5
J3 6510021441 S.CON B6B-ZR-SM4-TF(LF)(SN) T 7.6/37.0
J4 6510019421 S.CON B8B-ZR-SM4-TF(LF)(SN) T 7.6/20.0
