Icom IC-M506

5-11
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
Eqv.= This component is equivalent to the REF No. component listed above, and
may be substituted on parts orders and repairs.
REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[CONNECT UNIT]
IC1 1180001862 S.IC TA78M05F(TE16L1NQ) T 7.4/7.0
IC2 1130014420 S.IC HA13721FPKEL-E T 18.5/10.8
IC3 1130011930 S.IC SN74LVC1G04DCKR T 18.3/3.5
IC4 1190002840 S.IC PC410L0NIP0F T 23.5/7.2
IC5 1190002840 S.IC PC410L0NIP0F T 27.7/7.2
IC6 1130017240 S.IC SN74AHCT1G04DCKR T 27.0/13.7
D1 1750001670 S.DIO RR264M-400TR T 10.0/19.1
R1 7030010540 S.RES ERJ1TYJ 330U (33) T 4.6/21.9
R2 7030010540 S.RES ERJ1TYJ 330U (33) T 4.6/18.2
R3 7030007280 S.RES ERJ2GEJ 331 X (330) T 21.8/2.0
R4 7030008370 S.RES ERJ2GEJ 561 X (560) T 23.8/14.8
R5 7030008370 S.RES ERJ2GEJ 561 X (560) T 18.8/5.3
R6 7030007280 S.RES ERJ2GEJ 331 X (330) T 27.8/11.7
R12 7030010040 S.RES ERJ2GEJ-JPW T 32.7/12.4
C1 4030007090 S.CER C1608 CH 1H 470J-T T 10.3/22.2
C3 4510009810 S.ELE EEEFK1E220R T 5.6/13.4
C4 4030018980 S.CER C1608 JB 1H 104K-T ATEX T 2.0/8.4
C5 4030018980 S.CER C1608 JB 1H 104K-T ATEX T 2.0/5.6
C6 4030020310 S.CER GRM31CB31C106KA88L T 7.8/2.4
C7 4030020310 S.CER GRM31CB31C106KA88L T 14.9/2.9
C8 4030018980 S.CER C1608 JB 1H 104K-T ATEX T 25.0/2.1
C9 4030018980 S.CER C1608 JB 1H 104K-T ATEX T 18.4/6.4
C10 4030018980 S.CER C1608 JB 1H 104K-T ATEX T 20.5/3.5
C11 4030018980 S.CER C1608 JB 1H 104K-T ATEX T 27.0/15.9
C12 4030018980 S.CER C1608 JB 1H 104K-T ATEX T 24.2/15.9
J1 6510030360 CON ICOM-MMAPM05MCC <ODS>
J2 6510022692 S.CON 06FLT-SM2-TB(LF)(SN)(M) T 26.5/19.7
EP2 6910018270 S.BEA MMZ1608Y301CT T 10.3/23.5
EP3 6910018270 S.BEA MMZ1608Y301CT1 T 23.1/19.0
REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
• AIS UNIT (UX-231)
[MAIN UNIT]
IC2 1110007320 S.IC NJM2591V-TE1-#ZZZB T 32.2/10.7
IC3 1130015790 S.IC EN25F10-100GIP <MSK> T 18.2/52.0
IC4 1180002561 S.REG XC6202P352PR-G T 22.0/44.5
IC5 1130014980 S.IC BU4331G-TR T 16.2/44.6
IC6 1130006551 S.IC TC7S08FU(TE85RF) T 9.6/24.0
IC7 1130008821 S.IC TC7S86F(TE85RF) *0 T 13.6/25.3
IC8 1190002850 S.IC CMX7032L9/TR (FI-2.0) T 9.6/35.5
Q1 1580000731 S.FET 3SK293(TE85LF) T 33.2/34.3
Q2 1530002601 S.TRA 2SC4215-O(TE85RF) T 22.8/30.6
Q3 1530002060 S.TRA 2SC4081 T106 R T 23.0/36.8
D2 1750002010 S.DIO DA2J10100L T 25.7/48.6
FI1 2040002130 S.SAW LBT16201 <EVT> T 37.0/41.1
FI2 2030001070 S.MON TMK5286 38.85 MHz (FL-470) T 28.0/27.7
FI3 2030001070 S.MON TMK5286 38.85 MHz (FL-470) T 28.0/19.0
FI4 2020002480 S.CER LTWC450E1 <JJE> T 5.3/14.1
FI5 2030001080 S.MON TMK5287 38.8 MHz (FL-473) T 37.0/27.0
FI6 2030001080 S.MON TMK5287 38.8 MHz (FL-473) T 39.3/19.0
FI7 2020002480 S.CER LTWC450E1 <JJE> T 23.8/7.7
X1 6050013660 S.XTA CR-963 DSB321SCM
41.058333 MHz T 22.1/23.0
X2 6070000310 S.DIS JTBM450CX70 <JJE> T 13.5/11.0
X3 6050013730 S.XTA CR-968 DSX321G 38.35 MHz T 34.8/15.4
X4 6070000310 S.DIS JTBM450CX70 <JJE> T 32.0/4.6
X5 6050013960 S.XTA CR-869A DSA321SCH 19.2 MHz T 4.9/24.5
L1 6200009930 S.COI C2012C-68NG-A T 37.2/48.1
L2 6200011220 S.COI C2012C-R47J-A T 30.8/34.8
L3 6200002651 S.COI NLV25T-R18J T 23.1/25.8
L4 6200009560 S.COI MLG1608B R10J-T T 20.8/30.5
L5 6200009560 S.COI MLG1608B R10J-T T 20.4/36.4
L6 6200015290 S.COI C2012H-5N6D-R-0231 T 22.8/39.6
L7 6200015290 S.COI C2012H-5N6D-R-0231 T 27.8/39.6
L10 6200003941 S.COI NLV25T-5R6J T 14.1/21.2
L11 6200009970 S.COI C2012C-R39G-A T 25.3/39.6
L12 6200009970 S.COI C2012C-R39G-A T 30.6/38.4
L13 6200015250 S.COI C2012H-27NH-R-0231 T 41.1/34.3
R1 7030008280 S.RES ERJ2GEJ 271 X (270) T 38.6/35.1
R2 7030007350 S.RES ERJ2GEJ 393 X (39K) T 35.0/33.5
R3 7030008300 S.RES ERJ2GEJ 184 X (180K) T 36.8/33.5
R4 7030007350 S.RES ERJ2GEJ 393 X (39K) T 35.0/35.1
R5 7030008300 S.RES ERJ2GEJ 184 X (180K) T 35.9/35.1
R6 7030005530 S.RES ERJ2GEJ 100 X (10) T 36.8/35.1
R7 7030007300 S.RES ERJ2GEJ 332 X (3.3K) T 28.3/35.1
R8 7030005530 S.RES ERJ2GEJ 100 X (10) T 26.9/33.9
R9 7030007280 S.RES ERJ2GEJ 331 X (330) T 19.6/23.8
R10 7030007290 S.RES ERJ2GEJ 222 X (2.2K) T 23.4/27.8
R11 7030008010 S.RES ERJ2GEJ 123 X (12K) T 23.4/28.8
R12 7030004980 S.RES ERJ2GEJ 101 X (100) T 23.4/33.3
R13 7030005530 S.RES ERJ2GEJ 100 X (10) T 21.1/32.2
R14 7030005720 S.RES ERJ2GEJ 563 X (56K) T 23.5/35.1
R15 7030004990 S.RES ERJ2GEJ 221 X (220) T 21.1/33.1
R16 7030009280 S.RES ERJ2GEJ 391 X T 32.2/30.7
R17 7030005030 S.RES ERJ2GEJ 152 X (1.5K) T 23.9/17.5
R23 7030005120 S.RES ERJ2GEJ 102 X (1K) T 11.6/20.4
R24 7030008410 S.RES ERJ2GEJ 392 X (3.9K) T 18.1/12.3
R25 7030004970 S.RES ERJ2GEJ 470 X (47) T 11.6/22.2
R26 7030009280 S.RES ERJ2GEJ 391 X T 33.1/30.7
R27 7030005030 S.RES ERJ2GEJ 152 X (1.5K) T 39.3/13.4
R33 7030010040 S.RES ERJ2GEJ-JPW T 32.5/15.8
R34 7030007350 S.RES ERJ2GEJ 393 X (39K) T 32.5/14.9
R35 7030008410 S.RES ERJ2GEJ 392 X (3.9K) T 36.7/5.9
R36 7030004970 S.RES ERJ2GEJ 470 X (47) T 25.2/14.3
R37 7030005120 S.RES ERJ2GEJ 102 X (1K) T 17.7/48.7
R38 7030009320 S.RES ERJ2GEJ 4R7 X (4.7) T 14.5/48.7
R40 7030009320 S.RES ERJ2GEJ 4R7 X (4.7) T 26.9/46.9
R41 7030005170 S.RES ERJ2GEJ 474 X (470K) T 14.0/45.4
R42 7030009710 S.RES ERJ2GEJ 203 X (20K) T 7.8/26.4
R43 7030007340 S.RES ERJ2GEJ 153 X (15K) T 2.9/25.3
R44 7030005530 S.RES ERJ2GEJ 100 X (10) T 6.9/24.8
R45 7030005240 S.RES ERJ2GEJ 473 X (47K) T 7.8/24.8
R46 7030005240 S.RES ERJ2GEJ 473 X (47K) T 7.8/23.2
R47 7030005530 S.RES ERJ2GEJ 100 X (10) T 9.0/26.3
R48 7030005000 S.RES ERJ2GEJ 471 X (470) T 11.4/25.8
R49 7030005530 S.RES ERJ2GEJ 100 X (10) T 16.7/25.5
R50 7030005120 S.RES ERJ2GEJ 102 X (1K) T 16.2/24.2
R51 7030005120 S.RES ERJ2GEJ 102 X (1K) T 17.1/22.6
R52 7030005530 S.RES ERJ2GEJ 100 X (10) T 18.6/41.9
R53 7030005090 S.RES ERJ2GEJ 104 X (100K) T 2.2/41.9
R54 7030005120 S.RES ERJ2GEJ 102 X (1K) T 2.2/43.7
R55 7030005120 S.RES ERJ2GEJ 102 X (1K) T 2.2/42.8
R56 7030007260 S.RES ERJ2GEJ 330 X (33) T 18.6/28.7
R57 7030005090 S.RES ERJ2GEJ 104 X (100K) T 15.8/28.7
R58 7030005090 S.RES ERJ2GEJ 104 X (100K) T 16.0/5.2
R59 7030005090 S.RES ERJ2GEJ 104 X (100K) T 16.7/27.1
R60 7030005090 S.RES ERJ2GEJ 104 X (100K) T 15.0/5.2
R61 7030009140 S.RES ERJ2GEJ 272 X (2.7K) T 16.0/3.6
R62 7030009140 S.RES ERJ2GEJ 272 X (2.7K) T 15.0/3.6
R64 7030010040 S.RES ERJ2GEJ-JPW T 2.2/40.1
R67 7030005120 S.RES ERJ2GEJ 102 X (1K) T 10.1/46.9
R68 7030005120 S.RES ERJ2GEJ 102 X (1K) T 8.5/46.9
R69 7030004980 S.RES ERJ2GEJ 101 X (100) T 6.9/46.9
R70 7030005120 S.RES ERJ2GEJ 102 X (1K) T 5.3/46.9
