Icom IC-M710

[VR1 BOARD][REG BOARD]
S.=Surface mount
IC8001 1110003070 S.IC µPC494GS-E1
IC8002 1110001820 S.IC µPC1093T-E1
IC8003 1170000290 S.IC PS2701-1-F3
Q8001 1560001180 S.TRANSISTOR 2SK2266
Q8003 1510000800 S.TRANSISTOR 2SA1213-Y (TE12R,C)
D8002 1790001360 DIODE SF10SC6
D8003 1790001780 DIODE MA700
L8001 5920000450 COIL FK-080E-1020
L8003 5920000450 COIL FK-080E-1020
R8001 7030000430 S.RESISTOR MCR10EZHJ 2.7 k
Ω
R8002 7030000460 S.RESISTOR MCR10EZHJ 4.7 k
Ω
R8003 7030000490 S.RESISTOR MCR10EZHJ 8.2 k
Ω
R8004 7030000390 S.RESISTOR MCR10EZHJ 1.2 k
Ω
R8005 7030000460 S.RESISTOR MCR10EZHJ 4.7 k
Ω
R8006 7030000460 S.RESISTOR MCR10EZHJ 4.7 k
Ω
R8007 7030000480 S.RESISTOR MCR10EZHJ 6.8 k
Ω
R8008 7030000440 S.RESISTOR MCR10EZHJ 3.3 k
Ω
R8009 7030001090 S.RESISTOR MCR50JZHJ 47
Ω (470)
R8010 7030001210 S.RESISTOR MCR50JZHJ 470
Ω (471)
R8011 7030000460 S.RESISTOR MCR10EZHJ 4.7 k
Ω
R8012 7030000260 S.RESISTOR MCR10EZHJ 100
Ω (101)
R8013 7310005010 S.RESISTOR KVSF637AC 102
R8014 7030000450 S.RESISTOR MCR10EZHJ 3.9 k
Ω
R8015 7030000380 S.RESISTOR MCR10EZHJ 1 k
Ω
R8016 7030000200 S.RESISTOR MCR10EZHJ 33
Ω (330)
R8019 7030000340 S.RESISTOR MCR10EZHJ 470
Ω (471)
R8020 7030000380 S.RESISTOR MCR10EZHJ 1 k
Ω
C8001 4510004590 ELECTROLYTIC 16 MV 470 HC
C8002 4030005110 S.CERAMIC C2012 JB 1E 473K-T
C8003 4560000050 CERAMIC D67X5T 1E 684M51
C8004 4510007250 ELECTROLYTIC 25 MV 1000 AX
C8005 4510007250 ELECTROLYTIC 25 MV 1000 AX
C8006 4510006160 ELECTROLYTIC 25 MV 10 HC
C8007 4310000360 MYLAR 50 F2D 103J
C8008 4030004740 S.CERAMIC C2012 JB 1H 472K-T
C8009 4510007250 ELECTROLYTIC 25 MV 1000 AX
C8010 4510007250 ELECTROLYTIC 25 MV 1000 AX
C8011 4560000050 CERAMIC D67X5T 1E 684M51
C8012 4030004730 S.CERAMIC C2012 JB 1H 222K-T
C8013 4510006020 ELECTROLYTIC 16 MV 2200 HC
C8014 4560000050 CERAMIC D67X5T 1E 684M51
C8015 4560000050 CERAMIC D67X5T 1E 684M51
T8001 5920000440 TRANSFORMER TO-25
EP8001 0910045073 B4420C SX-1632
J2301 6510021050 CONNECTOR A28 SOCKET
J2302 6510018381 CONNECTOR 10FE-BT-VK-N
EP2301 0910044821 PCB B 4503A
R2401 7210002540 VARIABLE TP96N937-15F-10KB-1540
J2401 6510018391 CONNECTOR 06FE-BT-VK-N
EP2401 0910044832 PCB B 4367B
R2401 7210002730 VARIABLE TP96N944-15F-10KB-1632
J2501 6510018391 CONNECTOR 06FE-BT-VK-N
EP2501 0910044842 PCB B 4508B
IC3001 1140007880 S.IC TC190G08AF-0046-Z/SC-1246A
IC3002 1140004550 S.IC M65343FP/SC1287
IC3003 1180001070 S.IC TA7805F (TE16L)
IC3004 1130004830 S.IC TC7SU04F (TE85R)
IC3005 1130007660 S.IC LC7153M-TLM
IC3006 1130004830 S.IC TC7SU04F (TE85R)
IC3008 1130004830 S.IC TC7SU04F (TE85R)
IC3009 1180000420 S.IC TA78L05F (TE12R)
IC3010 1110000960 S.IC NJM4558M-TE1
Q3002 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q3003 1560000720 S.FET 2SK2171-4-TD
Q3004 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q3005 1560000330 S.FET 2SK210-GR (TE85R)
Q3006 1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
Q3007 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q3008 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q3009 1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
Q3010 1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
Q3011 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q3021 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q3022 1590001330 S.TRANSISTOR DTA114EUA T106
Q3024 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q3025 1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
Q3026 1590000680 S.TRANSISTOR DTC114EUA T106
D3001 1750000270 S.DIODE 1SS301 (TE85R)
D3002 1750000270 S.DIODE 1SS301 (TE85R)
D3003 1790000540 S.VARICAP MA338 (TX)
D3004 1720000670 S.VARICAP HVU17D3005
D3005 1750000070 S.DIODE 1SS226 (TE85R)
D3006 1790000620 S.DIODE MA77 (TX)
D3015 1790000490 S.DIODE HSM88AS-TR
D3016 1790000490 S.DIODE HSM88AS-TR
D3017 1750000270 S.DIODE 1SS301 (TE85R)
D3020 1720000670 S.VARICAP HVU17
FI3001 2020001140 S.CERAMIC SFECA10.7MA5-A-TC
X3002 6050011360 XTAL CR-612 POCO 30.00000 MHz
5 - 18
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
[MIC BOARD]
REF ORDER
DESCRIPTION
NO. NO.
[VR2 BOARD]
REF ORDER
DESCRIPTION
NO. NO.
[PLL-A UNIT] ([GMDSS] only)
PLL REF ORDER
DESCRIPTION
NO. NO.
[GEN]: [GEN-21], [GEN-22], [GEN-23] [EUR]: [EUR-21], [EUR-22]
[GMDSS]: [GEN-23], [EUR-22] [Others]: [GEN-21], [GEN-22], [EUR-21]
