Icom IC-M710 - Mechanical Parts and Disassembly

SECTION 6 MECHANICAL PARTS AND DISASSEMBLY
6 - 1
W1012 8900006082 Cable OPC-567B 1
MF1001 2710000520 Fan SB0812H-ICOM-00 [Others] 1
2710000570 Fan VFA-8018-BH10-1000 [GMDSS] 1
MP1003 8010015771 1632 main chassis-1 [Others] 1
8010017211 1632 G-main chassis-1 [GMDSS] 1
MP1005 8850000180 Flat washer M5 SUS 3
MP1006 8850000500 Spring washer M5 SUS 1
MP1007 8830000250 Nut M5 SUS 1
MP1008 8830000370 Wing nut M5 SUS 1
MP1010 8810008630 Screw PH BT M3 × 6 NI-ZU 7
MP1011 8810008630 Screw PH BT M3 × 6 NI-ZU 7
MP1015 8810009850 Screw PH BT M4 × 12 NI-ZU 4
MP1018 8110005511 1632 cover-1 [Others] 1
8110005560 1632 G-cover [GMDSS] 1
MP1020 8210012221 1632 rear panel-1 [Others] 1
8210015140 1632 rear panel (A)-1 [GMDSS] 1
MP1022 8930035780 1632 rear seal 1
MP1024 8930035750 1632 connector plate [Others] 1
8930036840 1632 G-connector plate [GMDSS] 1
MP1026 8930035740 1632 connector seal [GMDSS] 1
MP1027 8930035760 1632 fan seal [GMDSS] 1
MP1028 8930035730 1632 fan plate [GMDSS] 1
MP1029 8810003840 Screw BiH M3 × 8 ZK SUS 1
MP1030 8810003840 Screw BiH M3 × 8 ZK SUS [Others] 4
8810003840 Screw BiH M3 × 8 ZK SUS [GMDSS] 2
MP1031 8820000550 Cap bolt M4 × 8 ZK [Others] 4
8810008910 Screw PH M4 × 25 SUS [GMDSS] 4
MP1038 8810003840 Screw BiH M3 × 8 ZK SUS 9
MP1040 8810008790 Screw FH M3 × 6 NI 4
MP1043 8810003840 Screw BiH M3 × 8 ZK SUS [GMDSS] 4
MP1044 8930037050 1632 side seal [GMDSS] 4
MP1045 8930037030 1562 stand-off [Others] 2
8930037030 1562 stand-off [GMDSS] 4
MP1046 8930036390 1562 CA-plate [GMDSS] 2
MP1047 8810008800 Screw PH UNC NO.4 × 4 SUS [GMDSS] 4
MP1050 8930037900 Himelon sheet BB 1
MP1051 8930040020 Himelon sheet BJ 4
MP1055 8850001700 Insulation flat washer (Y) [GMDSS] 4
MP1056 8850001691 Insulation flat washer (X)-1 [GMDSS] 3
MP1057 8930045110 1632 G-A seal [GMDSS] 1
MP1058 8930045100 1632 G-B seal [GMDSS] 1
MP1059 8930050321 Thermally sheet (M)-1 1
MP1060 8930050331 Thermally sheet (N)-1 1
MP1061 8850001810 Sealing washer (V) [GMDSS] 13
[CHASSIS PARTS]
ORDER
NO.
REF.
NO.
DESCRIPTION QTY.
S2801 2260001580 Switch JPZ2120-0101 1
SP2801 2510000441 Speaker F77G08-6205 1
MP2801 8210012342 1632 front panel (A)-1 [Others] 1
8210012192 1632 front panel-1 [GMDSS] 1
MP2802 8310035581 1632 window plate 1
MP2803 8930035591 1632 3-key-1 1
MP2804 8930035600 1632 4-key 1
MP2805 8930035610 1632 14-key 1
MP2806 8930035640 1632 power key 1
MP2807 8930035650 1632 1-key 1
MP2808 8930035660 1632 2-key 1
MP2809 8610009750 Knob N232 2
MP2810 8610009760 Knob N233 2
MP2811 8210012200 1632 mask plate [GEN-21] 1
MP2812 8930035580 1632 sensor seal 2
MP2813 8930035571 1632 knob plate-1 1
MP2816 8930035630 1632 front seal 1
MP2817 8930031830 O ring SO-008-17 2
MP2818 8010016024 1632 sub chassis-4 1
MP2819 8810007410 Screw PH M3 × 6 NI 4
MP2820 8810008660 Screw PH BT M3 × 8 NI-ZU 7
MP2821 8930036350 1632 T-key 1
MP2822 8930036320 1632 key spacer 1
MP2823 8810008790 Screw FH M3 × 6 NI 2
MP2824 8610009240 Knob sprring NO.7800P 2
MP2825 8930032370 Shaft tape (A) 2
MP2831 8930045080 1632 clip 1
MP2832 8930050270 1632 LCD sponge 1
[FRONT PARTS]
ORDER
NO.
REF.
NO.
DESCRIPTION QTY.
DS2004 5010000180 LCD DLC-7978P 1
MP2001 8410002002 1632 heatsink plate-2 1
MP2002 8930035621 1632 LCD holder-1 1
MP2003 8930036280 1632 LCD-L filter 1
MP2004 8930036310 1632 LCD-U filter 1
MP2006 8810004300 Screw PH M3 × 10 ZK 1
MP2007 8830000190 Nut M3 NI BS 1
MP2008 8930036570 1632 lamp rubber 3
[LOGIC UNIT]
ORDER
NO.
REF.
NO.
DESCRIPTION QTY.
S2601 2250000020 Encoder SRB18100 25KC 1
[SENSOR1 BOARD]
ORDER
NO.
REF.
NO.
DESCRIPTION QTY.
S2701 2250000020 Encoder SRB18100 25KC 1
[SENSOR2 BOARD]
ORDER
NO.
REF.
NO.
DESCRIPTION QTY.
MP4301 8930014140 Earth spring (D) 1
[FILTER BOARD]
ORDER
NO.
REF.
NO.
DESCRIPTION QTY.
MP4001 8860000110 Earth lug B3 (M4) AG BS 1
MP4002 8860000110 Earth lug B3 (M4) AG BS 1
MP4004 6910008240 Clip 59TN4772 [EUR] 1
MP4005 6910008240 Clip 59TN4772 [EUR] 1
[PA150W BOARD]
ORDER
NO.
REF.
NO.
DESCRIPTION QTY.
J2301 6510021050 Connector A28 socket 1
[MIC BOARD]
ORDER
NO.
REF.
NO.
DESCRIPTION QTY.
R2401 7210002540
Variable resistor TP96N937-15F-10KB-1540 1
[VR1 BOARD]
ORDER
NO.
REF.
NO.
DESCRIPTION QTY.
R2501 7210002730 Variable resistor TP96N944-15F-10KB-1632 1
[VR2 BOARD]
ORDER
NO.
REF.
NO.
DESCRIPTION QTY.
