Icom IC-M710

[CHASSIS UNIT]
S.=Surface mount
MF1001 2710000520 FAN SB0812H-ICOM-00 [Others]
2710000570 FAN VFA-8018-BH10-1000 [GMDSS]
W1003 8900006220 CABLE OPC-539
W1012 8900006082 CABLE OPC-567B
EP1001 6910013480 E.OTHER MGB12-07B
IC5001 1130007800 S.IC S-7116AF-TF B 25.5/6.2
Q5001 1530002690 S.TR 2SC4116-GR (TE85R) T 23.9/10.5
X5001 6060000150 S.CE CSAC3.58MGC300CD-TC T 14/2.6
R5001 7030003620 S.RE ERJ3GEYJ 333 V (33 k
Ω
) T 25.6/2.3
R5002 7030003640 S.RE ERJ3GEYJ 473 V (47 k
Ω
) T 21.6/2.3
R5003 7030003440 S.RE ERJ3GEYJ 102 V (1 k
Ω
) T 23.6/3.1
R5004 7030003640 S.RE ERJ3GEYJ 473 V (47 k
Ω
) T 16/10
R5005 7030003440 S.RE ERJ3GEYJ 102 V (1 k
Ω
T 17.3/10
R5006 7030003680 S.RE ERJ3GEYJ 104 V (100 k
Ω
) T 21/10.8
R5007 7030003710 S.RE ERJ3GEYJ 184 V (180 k
Ω
) T 25.4/8.6
R5008 7030003440 S.RE ERJ3GEYJ 102 V (1 k
Ω
) T 26.1/10.4
R5009 7030003440 S.RE ERJ3GEYJ 102 V (1 k
Ω
) T 14.1/17
R5010 7030003640 S.RE ERJ3GEYJ 473 V (47 k
Ω
) T 12.1/17.7
C5001 4550006140 S.TA ECST1EY474R T 20.5/9.1
C5002 4550006210 S.TA ECST1CX106R T 4.9/3.6
C5004 4030006880 S.CE C1608 JB 1H 472K-T T 14.7/10
C5005 4030007090 S.CE C1608 CH 1H 470J-T T 12.1/10
C5006 4030007090 S.CE C1608 CH 1H 470J-T T 13.4/10
C5007 4030006860 S.CE C1608 JB 1H 102K-T T 21.6/3.6
C5008 4030006850 S.CE C1608 JB 1H 471K-T T 12.1/16.2
J5001 6510018160 S.CO 4-175643-0 T 5/10
J5002 6510018170 S.CO 4-175643-4 T 31/10
EP5001 0910045602 PCB B 4368B
5 - 21
REF ORDER
DESCRIPTION
NO. NO.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[GEN]: [GEN-21], [GEN-22], [GEN-23] [EUR]: [EUR-21], [EUR-22]
[GMDSS]: [GEN-23], [EUR-22] [Others]: [GEN-21], [GEN-22], [EUR-21]
[ALARM BOARD] (except [GEN-21])
REF ORDER
DESCRIPTION M.
H/V
NO. NO. LOCATION
