SPECIFICATIONS
All stated specifi cations are subject to change without notice or obligation.
[USA], [EXP] [AUS]
[CHN], [EUR], [UK],
[FRG], [HOL]
GENERAL
• Frequency coverage
TX
156.025–157.425 MHz 156.000–161.450 MHz
RX
156.050–163.275 MHz 156.300–162.025 MHz 156.000–163.425 MHz
• Mode FM (16K0G3E), DSC (16K0G2B)
• Operating temperature range –20°C to +60°C
(–4°F to +140°F)
–10°C to +55°C –15°C to +55°C
• Power supply requirement
7.4 V DC nominal (negative ground)
• Current drain
(approximately)
TX
at 5.0 W
1.5 A
at 1.0 W
0.7 A
at 0.5 W
– 0.6 A
RX Max.audio
0.50 A
• Antenna impedance
50
Ω
nominal
• Dimensions (approximately)
(Projections not included)
61.2(W) × 141.4(H) × 43.2(D) mm
2.4(W) × 5.6(H) × 1.7(D) inches
• Weight (approximately) 287 g; 10.1 oz (with BP-275)
318 g; 11.2 oz (with BP-275, FA-SC59V and MB-109)
TRANSMITTER
• Transmit output power
5 W (High power), 1 W (Low power)
5 W (High power)
1 W (Low power)
0.5 W* (E_Low power)
*German version only
• Modulation
Variable reactance frequency modulation
• Maximum frequency deviation
±5 kHz
• Frequency error
±10 ppm ±1.5 kHz
• Spurious emission
–68 dBc (typical) 0.25 µW
• Adjacent channel power
70 dB
• Audio harmonic distortion
10% (at 60% deviation)
• Audio frequency response
+1 dB to –3 dB of 6 dB octave from 300 Hz to 3000 Hz
• Residual modulation
40 dB
• Microphone impedance
2 k
Ω
RECEIVER
• Intermediate frequencies
1st 21.7 MHz, 2nd 450 kHz
• Sensitivity (typical)
0.25 µV (12 dB SINAD)
–5 dBµ emf
(20 dB SINAD)
–4 dBµ emf at 20 dB SINAD
• Squelch sensitivity (at threshold)
(typical)
–9 dBµ (0.35 µV) –6 dBµ emf –5 dBµ emf
• Adjacent channel selectivity
70 dB (typical) 65 dB 70 dB
• Spurious response
70 dB (typical) 65 dB 70 dB
• Intermodulation
70 dB (typical) 65 dB 68 dB
• Audio output power
(at 10% distortion with an 8
Ω
load)
0.35 W typical (External)
0.7 W typical (Internal)
0.2 W (External)
0.7 W typical at 1 kHz (Internal)
• Hum and noise
40 dB
• Audio frequency response
+1 dB to –3 dB of –6 dB octave from 300 Hz to 3000 Hz
• Audio output impedance
8
Ω
