5-4
ADJUSTMENT ADJUSTMENT ITEM DISPLAY CONDITION OPERATION
HF-flat 16 HF BPF0 flat • Set the test equipment to:
Frequency: 0.2515 MHz
Modulation: None
Level: +40 dBμ
†
(–67 dBm)
Touch [SET].
(A beep sounds, and then
another beeps sound 1
second later.)
17 HF BPF1 flat • Set the test equipment to:
Frequency: 1.1015 MHz
18 HF BPF2 flat • Set the test equipment to:
Frequency: 1.8215 MHz
19 HF BPF3 flat • Set the test equipment to:
Frequency: 2.6015 MHz
20 HF BPF4 flat • Set the test equipment to:
Frequency: 3.6015 MHz
21 HF BPF5 flat • Set the test equipment to:
Frequency: 5.1015 MHz
22 HF BPF6 flat • Set the test equipment to:
Frequency: 7.0815 MHz
23 HF BPF7 flat • Set the test equipment to:
Frequency: 10.1015 MHz
24 HF BPF9 flat • Set the test equipment to:
Frequency: 18.1515 MHz
25 HF BPF10 flat • Set the test equipment to:
Frequency: 28.1015 MHz
26 HF BPF11 flat (L) Set the test equipment to:
Frequency: 0.5015 MHz
27 HF BPF11 flat ( M) • Set the test equipment to:
Frequency: 14.1515 MHz
28 HF BPF11 flat (H) • Set the test equipment to:
Frequency: 29.9015 MHz
HF-flat
(Preamp ON)
29 HF PRE flat (L) • Set the test equipment to:
Frequency: 0.5015 MHz
30 HF PRE flat ( M) • Set the test equipment to:
Frequency: 14.1515 MHz
31 HF PRE flat (H) • Set the test equipment to:
Frequency: 29.9015 MHz
HF-flat
(ATT)
32 HF ATT 10dB flat • Set the test equipment to:
Frequency: 14.1515 MHz
Modulation: None
Level: +40 dBμ
†
(–67 dBm)
33 HF ATT 20dB flat
• After the adjustment, the receiver shows the HF receive adjustment menu.
• Push [EXIT] to return to the main menu screen.
5-3 HF RECEIVE ADJUSTMENT (CONTINUED)
†
: The output level of the standard signal generator (SSG) is indicated as the SSG’s open circuit.
