SECTION 7
SECTION 7 MECHANICAL PARTS
7-1
REF PART
DESCRIPTION QTY.
NO. NO.
[CHASSIS PARTS]
REF PART
DESCRIPTION QTY.
NO. NO.
*: Refer to “BOARD LAYOUTS” for the location.
**: Refer to “GENERAL WIRING” for the connection
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
[CHASSIS PARTS]
J1 6510000330 NR-DS-01 1
J2 6510028411 MR-DS-01-2 1
J3 6510030620 MR-BNC-01 1
J4 6510030620 MR-BNC-01 1
SP1 2510002100 3818 SP BOX 1
W101** 8910000530 FFC-1057 (P0.5N30L65 S) 1
W102** 8910000530 FFC-1057 (P0.5N30L65 S) 1
W103** 8910000520 FFC-1056 (P0.5N40L100 S) TJM 1
W201** 8970025700 1.5D 200MMC31/C31 3818-3-1 [#02] 1
8970024982 1.5DCOAXIAL200MM-2 C31/C31 [#03] 1
8970025700 1.5D 200MMC31/C31 3818-3-1 [#04] 1
8970024982 1.5DCOAXIAL200MM-2 C31/C31 [#05] 1
8970024982 1.5DCOAXIAL200MM-2 C31/C31 [#06] 1
W203** 8970025671 1.5D 280MMC31/C31 3818-5-1 [#02] 1
8970025671 1.5D 280MMC31/C31 3818-5-1 [#03] 1
8970025671 1.5D 280MMC31/C31 3818-5-1 [#04] 1
8970025670 1.5DCOAXIAL280MM C31/C31 3818-5 [#05] 1
8970025671 1.5D 280MMC31/C31 3818-5-1 [#06] 1
W205** 8970025680 1.5DCOAXIAL155MM C31/W17D3818-4 1
W301** 8600037670 RX3818 P30 1 P302 (3818-1) [#02] 1
8600037600 SX3765 P1 1 P12CH (3765-1) [#03] 1
8600037600 SX3765 P1 1 P12CH (3765-1) [#04] 1
8600037600 SX3765 P1 1 P12CH (3765-1) [#05] 1
8600037600 SX3765 P1 1 P12CH (3765-1) [#06] 1
W321** 8920002391 CAB-1254-1 [#02] 1
8920002390 CAB-1254 (3818-2) [#03] 1
8920002391 CAB-1254-1 [#04] 1
8920002390 CAB-1254 (3818-2) [#05] 1
8920002390 CAB-1254 (3818-2) [#06] 1
EP201* 6910000630 FSRH070140RN000B (FSOH070RN) Only [#02] 1
EP203* 6910000630 FSRH070140RN000B (FSOH070RN) Only [#02] 1
EP301* 6910000630 FSRH070140RN000B (FSOH070RN) Only [#02] 1
MP1 8010023870 3818 CHASSIS M200 1
MP2 8210032140 3818 REAR PANEL 1
MP3* 8110011090 3818 RF COVER 1
MP5 8110011080 3818 L-COVER 1
MP6 8110011070 3818 U-COVER 1
MP7 8930095531 3818 A-STAND HOLDER-1 [#02] 1
8930095530 3818 A-STAND HOLDER [#03] 1
8930095531 3818 A-STAND HOLDER-1 [#04] 1
8930095531 3818 A-STAND HOLDER-1 [#05] 1
8930095530 3818 A-STAND HOLDER [#06] 1
MP8 8930095541 3818 B-STAND HOLDER-1 [#02] 1
8930095540 3818 B-STAND HOLDER [#03] 1
8930095541 3818 B-STAND HOLDER-1 [#04] 1
8930095541 3818 B-STAND HOLDER-1 [#05] 1
8930095540 3818 B-STAND HOLDER [#06] 1
MP9 8930095550 3818 STAND SHEET 2
MP10 8930095520 3818 STAND 1
MP11 8930095560 3818 RUBBER (TOP) 4
MP12 8930095570 3818 SPACER 4
MP13 8930002900 RUBBER LEG (A) SK1912A 2
MP14 8930049050 2263 ANT PLATE Y441 1
MP15* 8930055842 2490 EARTH SPRING-2 1
MP16* 8930082150 SPONGE (KZ) 1
MP20 8930090910 THERMAL SHEET (CL) TC-200CAS (26X37) 1
MP21 8930090910 THERMAL SHEET (CL) TC-200CAS (26X37) 1
MP23 8930096190 3818 NET 1
MP24 8930096170 3818 SP ANGLE Y2213 1
MP25 8930096181 3818 SP SPONGE-1 1
MP26 8930097420 INSULATION SHEET (OG) 4
MP27 8930097430 SPONGE (PE) 1
MP28 8930064320 SPONGE (HW) 2
MP31 8810009061 FLAT M3 X 6 ZK3 20
MP32 8810009311 FLAT BT M3 X 6 NI-ZC3 4
MP33 8810008661 PHBT M3 X 8 NI-ZC3 13
MP34 8810008661 PHBT M3 X 8 NI-ZC3 17
MP36 8810007231 SET SCREWH M3 X 8 ZC3 [#02] 4
8810007131 SET SCREWH M3 X 6 ZC3 2K [#03] 4
8810007231 SET SCREWH M3 X 8 ZC3 [#04] 4
8810007231 SET SCREWH M3 X 8 ZC3 [#05] 4
8810007131 SET SCREWH M3 X 6 ZC3 2K [#06] 4
MP37 8810011180 SET SCREW (H) 3X20 ZK3 4
MP38 8810008631 PHBT M3 X 6 NI-ZC3 6
MP39 8810008631 PHBT M3 X 6 NI-ZC3 2
MP40 8810008631 PHBT M3 X 6 NI-ZC3 2
MP41 8810008631 PHBT M3 X 6 NI-ZC3 2
MP42 8810008631 PHBT M3 X 6 NI-ZC3 2
MP43 8810004301 PH M3 X10 ZK3 2
MP44 8810004301 PH M3 X10 ZK3 2
MP45 8810009991 PHBT M3 X 8 NI-ZK3 1
MP46 8810008661 PHBT M3 X 8 NI-ZC3 8
MP51 8820000530 FLANGE BOLT M4 X 8 NI 1
MP52 8850000430 S-WASHER M 4 NI 1
MP53 8850000140 FLAT WASHER M 4 NI BS 2
MP61 8930071700 PJ-21B 1
MP62* 8930074741 SHIELD SPONGE (CE)-1 1
MP63* 8930074741 SHIELD SPONGE (CE)-1 1
MP64* 8930074741 SHIELD SPONGE (CE)-1 1
MP65 8930097450 FERRITE SHEET (BI) 1
MP66* 8930094900 SHIELD SPONGE (DY) 1
MP67* 8930094900 SHIELD SPONGE (DY) 1
MP68 8930063971 SHIELD SPONGE (AM)-1 1
MP71 8930074741 SHIELD SPONGE (CE)-1 [#02] 2
8930074741 SHIELD SPONGE (CE)-1 [#04] 2
8930074741 SHIELD SPONGE (CE)-1 [#05] 2
MP72 8930097540 SHIELD SPONGE (EI) [#02] 2
8930097540 SHIELD SPONGE (EI) [#04] 2
8930097540 SHIELD SPONGE (EI) [#05] 2
MP73 8930078841 SHIELD SPONGE (CM)-1 [#02] 1
8930078841 SHIELD SPONGE (CM)-1 [#04] 1
8930078841 SHIELD SPONGE (CM)-1 [#05] 1
MP74 8930078841 SHIELD SPONGE (CM)-1 [#02] 3
8930078841 SHIELD SPONGE (CM)-1 [#04] 3
8930078841 SHIELD SPONGE (CM)-1 [#05] 3
MP75 8930097340 FERRITE SHEET (BG) [#02] 2
8930097340 FERRITE SHEET (BG) [#04] 2
8930097340 FERRITE SHEET (BG) [#05] 2
MP76 8930092020 SPONGE (NH) [#02] 1
8930092020 SPONGE (NH) [#04] 1
8930092020 SPONGE (NH) [#05] 1
MP77* 8930091690 SPONGE (NB) [#02] 1
8930091690 SPONGE (NB) [#04] 1
8930091690 SPONGE (NB) [#05] 1
MP78 8930092020 SPONGE (NH) [#02] 1
8930092020 SPONGE (NH) [#04] 1
8930092020 SPONGE (NH) [#05] 1
MP79* 8510022300 3818 MAIN SHIELD PLATE [#02] 1
8510022300 3818 MAIN SHIELD PLATE [#04] 1
8510022300 3818 MAIN SHIELD PLATE [#05] 1
MP80* 8930093690 SHIELD SPONGE (DR) [#02] 2
8930093690 SHIELD SPONGE (DR) [#04] 2
8930093690 SHIELD SPONGE (DR) [#05] 2
