*: Refer to “BOARD LAYOUTS” for the location.
**: Refer to “GENERAL WIRING” for the connection
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
7-2
REF PART
DESCRIPTION QTY.
NO. NO.
[MAIN UNIT]
REF PART
DESCRIPTION QTY.
NO. NO.
[RF UNIT]
J1* 6510011431 B3P-VH (LF) (SN) 1
J2* 6510031740 HEC3900-010110 1
J11* 6510022472 40FLT-SM2-TB (LF) (SN) (M) 1
J41* 6510021722 30FLT-SM2-TB (LF) (SN) (M) 1
J71* 6510021722 30FLT-SM2-TB (LF) (SN) (M) 1
J201* 6510018971 B4B-PH-SM4-TB (LF) (SN) 1
J241* 6510025940 PJ-3047S 1
J242* 6510014961 B2B-ZR-SM4-TF (LF) (SN) 1
J261* 6510023730 LGY6502-0600C 1
J290* 6510028210 SJ050010 (TMP-J01X-V6) 1
J321* 6510026540 UBB-4R-D14T-4D (LF) (SN) 1
J322* 6510025142 10FLT-SM2-TB (LF) (SN) (M) 1
J371* 6510023730 LGY6502-0600C 1
J392* 6510023730 LGY6502-0600C 1
J531* 6510028210 SJ050010 (TMP-J01X-V6) 1
J541* 6510028210 SJ050010 (TMP-J01X-V6) 1
J601* 6510025142 10FLT-SM2-TB (LF) (SN) (M) [#03] 1
6510025142 10FLT-SM2-TB (LF) (SN) (M) [#06] 1
J671* 6510025142 10FLT-SM2-TB (LF) (SN) (M) [#03] 1
6510025142 10FLT-SM2-TB (LF) (SN) (M) [#06] 1
J961* 6510025142 10FLT-SM2-TB (LF) (SN) (M) [#03] 1
6510025142 10FLT-SM2-TB (LF) (SN) (M) [#06] 1
J1001* 6510027111 08FLT-SM2-TB (LF) (SN) (M) [#03] 1
6510027111 08FLT-SM2-TB (LF) (SN) (M) [#06] 1
J1002* 6510025142 10FLT-SM2-TB (LF) (SN) (M) [#03] 1
6510025142 10FLT-SM2-TB (LF) (SN) (M) [#06] 1
J1361* 6510025142 10FLT-SM2-TB (LF) (SN) (M) [#03] 1
6510025142 10FLT-SM2-TB (LF) (SN) (M) [#06] 1
J1381* 6510027290 52808-0671 [#03] 1
6510027290 52808-0671 [#06] 1
J1401* 6510024040 TM11R-5M2-88-LP 1
J1451* 6510026540 UBB-4R-D14T-4D (LF) (SN) 1
J2022* 6510025142 10FLT-SM2-TB (LF) (SN) (M) 1
F1* 5220000400 FHA010-01F 1
F2* 5210001390 0297003.WXNV 1
S391* 2220000790 SSSS925800 1
S1301* 2230001480 LS37J2-T 1
T1401* 5920000990 H1102FNLT 1
BT1201* 3020000390 ML414HIV01E 1
MP41* 8930071160 2427 F-EARTH SPRING [#02] 1
8930071160 2427 F-EARTH SPRING [#04] 1
8930071160 2427 F-EARTH SPRING [#05] 1
MP101* 8510019340 3179 VCO CASE 1
MP102* 8510019350 3179 VCO COVER 1
MP121* 8510019340 3179 VCO CASE 1
MP122* 8510019350 3179 VCO COVER 1
MP131* 8930071160 2427 F-EARTH SPRING [#02] 1
8930071160 2427 F-EARTH SPRING [#04] 1
8930071160 2427 F-EARTH SPRING [#05] 1
MP141* 8510021680 3697 VCO CASE 1
MP142* 8510018160 2969 B-VCO COVER 1
MP143* 8930063971 SHIELD SPONGE (AM)-1 [#02] 1
8930063971 SHIELD SPONGE (AM)-1 [#04] 1
8930063971 SHIELD SPONGE (AM)-1 [#05] 1
MP241* 8510022080 3818 AF CASE 1
MP271* 8510022090 3818 IF CASE 1
MP401* 8510022100 3818 REF CASE 1
MP441* 8510021150 3621 VCO CASE 1
MP442* 8510021160 3621 VCO COVER 1
MP481* 8930094090 3768 ANT SPRING 1
MP541* 8510022090 3818 IF CASE 1
MP571* 8510019800 3183 FILTER CASE 1
J4* 6450002520 RL-1515-2 (B.B)-L 1
J6* 6510023730 LGY6502-0600C 1
J501* 6510032350 20279-001E-01 1
J571* 6510028210 SJ050010 (TMP-J01X-V6) 1
J591* 6510032350 20279-001E-01 1
J751* 6510032350 20279-001E-01 1
J801* 6510028210 SJ050010 (TMP-J01X-V6) 1
J810* 6510032350 20279-001E-01 1
J812* 6510032350 20279-001E-01 1
J813* 6510032350 20279-001E-01 1
J901* 6510022472 40FLT-SM2-TB (LF) (SN) (M) 1
J1101* 6510032350 20279-001E-01 1
J1102* 6510027290 52808-0671 1
J1951* 6510032350 20279-001E-01 1
W501** 8920002370 CAB-1168A (8229JQ120000000101) 1
W812** 8920002370 CAB-1168A (8229JQ120000000101) 1
W813** 8920002310 CAB-1299 (822EKQ075000000101) 1
W1101** 8920002380 CAB-1306 (8229JQ045000000101) 1
W1102** 8900019300 OPC-2032 (P1N6L50) 1
W1951** 8920002310 CAB-1299 (822EKQ075000000101) 1
EP501* 6910000630 FSRH070140RN000B (FSOH070RN) 1
EP502* 6910000630 FSRH070140RN000B (FSOH070RN) 1
MP1* 8930094090 3768 ANT SPRING 1
MP2* 8510022220 3818 ANT COVER 1
MP3* 8510002280 VCOSHIELD PLATE (A) FX 15 1
MP4* 8930082601 SHIELD SPONGE (CT)-1 1
MP5* 8930071160 2427 F-EARTH SPRING 1
MP6 8930097540 SHIELD SPONGE (EI) 1
MP8 8930097450 FERRITE SHEET (BI) [#02] 1
8930097460 FERRITE SHEET (BJ) [#03] 1
8930097450 FERRITE SHEET (BI) [#04] 1
8930097450 FERRITE SHEET (BI) [#05] 1
8930097460 FERRITE SHEET (BJ) [#06] 1
MP9* 8930071160 2427 F-EARTH SPRING 1
MP51* 8930049131 SHIELD TAPE (D)-1 [#02] 1
8930049131 SHIELD TAPE (D)-1 [#04] 1
8930049131 SHIELD TAPE (D)-1 [#05] 1
MP101* 8510022190 3818 BPF-A CASE 1
MP501* 8510018880 2355 P-VCO CASE 1
MP502* 8930071160 2427 F-EARTH SPRING 1
MP503* 8930071160 2427 F-EARTH SPRING 1
MP504* 8930071160 2427 F-EARTH SPRING 1
MP505* 8930097520 DOUBLE SIDE TAPE (CG) 1
MP506* 8930097520 DOUBLE SIDE TAPE (CG) 1
MP511* 8510018880 2355 P-VCO CASE 1
MP551* 8510014870 2577 RX-VCO CASE 1
MP601* 8510018880 2355 P-VCO CASE 1
MP701* 8510018940 2356 A-VCO CASE 1
MP702* 8930097540 SHIELD SPONGE (EI) [#02] 1
8930097540 SHIELD SPONGE (EI) [#04] 1
8930097540 SHIELD SPONGE (EI) [#05] 1
MP1001* 8510022230 3818 RELAY CASE 1
MP1002* 8930071160 2427 F-EARTH SPRING 1
MP1011* 8510022230 3818 RELAY CASE 1
MP1012* 8930071160 2427 F-EARTH SPRING 1
MP1013* 8930071160 2427 F-EARTH SPRING 1
MP1014* 8930071160 2427 F-EARTH SPRING 1
MP1015* 8930063971 SHIELD SPONGE (AM)-1 1
MP1016* 8930097310 FERRITE SHEET (BE) 1
MP1017* 8930069610 SPONGE (IV) 1
MP1021 8510012400 2177 D/A CASE Y454 1
MP1031* 8510018880 2355 P-VCO CASE 1
MP1101* 8510022200 3818 CONV-BPF CASE 1
MP1102* 8510022210 3818 CONV-BPF COVER 1
MP1103 8810007131 SET SCREWH M3 X 6 ZC3 2K 5
MP1104 8510022240 3818 RF PLATE Y1415 1
MP1105* 8930071160 2427 F-EARTH SPRING 1
MP1106* 8930071160 2427 F-EARTH SPRING 1
MP1107* 8930097300 FERRITE SHEET (BD) 1
MP1108* 8930097300 FERRITE SHEET (BD) 1
MP1109* 8930097320 FERRITE SHEET (BF) 1
MP1151 8930074741 SHIELD SPONGE (CE)-1 1
MP1152 8930074741 SHIELD SPONGE (CE)-1 1
MP1153 8930097170 FERRITE SHEET (BC) 1
MP1154 8930092020 SPONGE (NH) 1
MP1155 8930092020 SPONGE (NH) 1
MP1156 8930071551 SHIELD SPONGE (BM)-1 1
MP1201* 8510018930 2356 A-PLL CASE 1
MP1261* 8510018880 2355 P-VCO CASE 1
MP1281* 8510018880 2355 P-VCO CASE 1
MP1291* 8930097540 SHIELD SPONGE (EI) 1
MP1292* 8930097540 SHIELD SPONGE (EI) 1
MP1293* 8930097330 3818 FERRITE SHEET 1
MP1301* 8510022180 3818 BPF CASE Y1413 1
MP1302* 8930097340 FERRITE SHEET (BG) 1
MP1303* 8930097440 FERRITE SHEET (BH) 1
MP1511* 8510018880 2355 P-VCO CASE 1
MP1521* 8510018880 2355 P-VCO CASE 1
To Next Page
