ADJUSTMENT ADJUSTMENT ITEM DISPLAY CONDITION OPERATION
VU12-flat
(continued)
51 VU12 BPF8 flat ( M) • Set the test equipment to:
Frequency: 925.0215 MHz
Touch [SET].
(A beep sounds, and then
another beeps sound 1
seconds later.)
52 VU12 BPF8 flat (L) • Set the test equipment to:
Frequency: 750.0215 MHz
53 VU12 BPF8 flat (M1) • Set the test equipment to:
Frequency: 850.0215 MHz
54 VU12 BPF8 flat (M2) • Set the test equipment to:
Frequency: 1020.0215 MHz
55 VU12 BPF8 flat (H) • Set the test equipment to:
Frequency: 1099.9815 MHz
VU12-flat
(Preamp ON)
56 VU12 PRE flat (40 M) • Set the test equipment to:
Frequency: 40.0215 MHz
57 VU12 PRE flat (65 M) • Set the test equipment to:
Frequency: 65.0215 MHz
58 VU12 PRE flat (105 M) • Set the test equipment to:
Frequency: 105.0215 MHz
59 VU12 PRE flat (165 M) • Set the test equipment to:
Frequency: 165.0215 MHz
60 VU12 PRE flat (260 M) • Set the test equipment to:
Frequency: 260.0215 MHz
61 VU12 PRE flat (410 M) • Set the test equipment to:
Frequency: 410.0215 MHz
62 VU12 PRE flat (500 M) • Set the test equipment to:
Frequency: 500.0215 MHz
63 VU12 PRE flat (625 M) • Set the test equipment to:
Frequency: 625.0215 MHz
64 VU12 PRE flat (749 M) • Set the test equipment to:
Frequency: 749.9815 MHz
65 VU12 PRE flat (750 M) • Set the test equipment to:
Frequency: 750.0215 MHz
66 VU12 PRE flat (925 M) • Set the test equipment to:
Frequency: 925.0215 MHz
67 VU12 PRE flat (1099 M) • Set the test equipment to:
Frequency: 1099.9815 MHz
VU12-flat
(ATT 10dB)
68 VU12 ATT 10dB flat (40 M) • Set the test equipment to:
Frequency: 40.0215 MHz
69 VU12 ATT 10dB flat (65 M) • Set the test equipment to:
Frequency: 65.0215 MHz
70 VU12 ATT 10dB flat (105 M) • Set the test equipment to:
Frequency: 105.0215 MHz
71 VU12 ATT 10dB flat (165 M) • Set the test equipment to:
Frequency: 165.0215 MHz
72 VU12 ATT 10dB flat (260 M) • Set the test equipment to:
Frequency: 260.0215 MHz
73 VU12 ATT 10dB flat (410 M) • Set the test equipment to:
Frequency: 410.0215 MHz
74 VU12 ATT 10dB flat (625 M) • Set the test equipment to:
Frequency: 625.0215 MHz
75 VU12 ATT 10dB flat (925 M) • Set the test equipment to:
Frequency: 925.0215 MHz
VU12-flat
(ATT 20dB)
76 VU12 ATT 20dB flat (40 M) • Set the test equipment to:
Frequency: 40.0215 MHz
77 VU12 ATT 20dB flat (65 M) • Set the test equipment to:
Frequency: 65.0215 MHz
78 VU12 ATT 20dB flat (105 M) • Set the test equipment to:
Frequency: 105.0215 MHz
79 VU12 ATT 20dB flat (165 M) • Set the test equipment to:
Frequency: 165.0215 MHz
80 VU12 ATT 20dB flat (260 M) • Set the test equipment to:
Frequency: 260.0215 MHz
81 VU12 ATT 20dB flat (410 M) • Set the test equipment to:
Frequency: 410.0215 MHz
82 VU12 ATT 20dB flat (625 M) • Set the test equipment to:
Frequency: 625.0215 MHz
83 VU12 ATT 20dB flat (925 M) • Set the test equipment to:
Frequency: 925.0215 MHz
5-4 VU RECEIVE ADJUSTMENT (CONTINUED)
†
: The output level of the standard signal generator (SSG) is indicated as the SSG’s open circuit.
